STKR TRi-MOBILE 12681 Quick Start Manual

Item # 12681
UPC: 850026126815
PACKAGE CONTENTS
[1] TRi-MOBILE Light
[1] Tripod Stand
[1] USB-A 2A Charger
[1] USB-A to USB-C Cable
Specifications
LIGHT
Light Source: LED
Total Max Light Output: 2000 Lumens
FLOOD LIGHT
- Output: 667 Lumens / head
- Color Temperature: 5400K or 4000K
- Beam Distance: 50m
- Beam Angle: 140 degrees
OPERATION
POWER/MODE BUTTON
- Press to turn ON
- Press to change brightness:
- After 5 seconds of no brightness change, next button
press is OFF
Light Brightness Modes: 3
1. High
2. Medium
3. Low
4. Off
LIGHT COLOR BUTTON
When light is ON press the sun button to change the
color temperature of the light.
Light Color Temperature Modes: 2
1. 5400K (Cool White)
2. 4000K (Warm White)
BATTERY LEVEL INDICATOR
- Battery level indicator LEDs turn on when light is
turned on
- (1) 0-24% (2) 25-49% (3) 50-74% (4) 75-100%
RUNTIME
High: 1.5 hours
Low: 3 hours
BATTERY
Type: 18650 Lithium-ion
Quantity: 2
Integrated - Soldered
Total Voltage: 7.4V
Total Capacity: 2000 mAh
Total Watt Hours: 14.8Wh
Total Weight: 4.1oz (115g)
Total Lithium Content: 1.2g
CHARGING
Rechargeable: Yes, via USB-C port
Charge Time: 3 hours (with supplied charger)
Charger Voltage: 5V
Charger Amps: 2A
TRi-MOBILE
Charging Indication:
- Battery level indicator light blinks while charging
- All 4 battery level indicator lights are on when fully
charged
Recommended: charge stored unit every four months to
maintain optimum performance of lithium-ion battery and
maximize charging levels.
DURABILITY
Waterproof Rating: IPX4
Indoor/Outdoor Use
Impact Resistance: 1m
MATERIALS
- Aluminum light housing & tripod
- ABS plastic body & hook
- Acrylic lens
- Neodymium magnet
- Aluminum tripod thread mount M20x1.5
DIMENSIONS
Extended:
56" x 21.5" x 21.5" (1422mm x 546mm x 546mm)
Collapsed (with Light):
26" x 3.2" x 3.1" (660mm x 82mm x 79mm)
Tripod (collapsed):
18.5" x 2.75" x 2.75" (470mm x 70mm x 70mm)
Light:
3.2" x 3.1" x 8.2" (82mm x 79mm x 208mm)
Tripod Weight: 2lb 9oz (1.17kg)
Light Weight: 1lb 7oz (0.64kg)
Total Weight: 4lb (1.81kg)
PACKAGING
Dimensions: 19.25" x 3.5" x 7" (487mm x 89mm x
178mm)
Weight: 5lb (2.25kg)
OTHER
Manufactured in China
WARRANTY
Length: 1 year
STKRconcepts.com
