- Page 1 LT268x/LT269 U a r t T F T C o n t r o l l e r Serial Uart TFT Panel Solution LT_VCOM_GUI Programming Manual V1.0 www.levetop.cn Levetop Semiconductor Co., Ltd.
- Page 2 This manual is to illustrate how users may utilize a VCOM programming tool, namely LT_VCOM_GUI, to program MCU_Code.bin and UartTFT_Flash.bin to LT develop board. Upgrade Procedure Please contact Levetop for the programming tool, or go to official website: https://www.levetop.cn/UartTFT/LT_Vcom_GUI_Vx.xx.rar Please refer to the programming procedure as listed below: Step 1: Connect “BUSY”...
- Page 3 LT develop board, users may install the driver to solve the issue. Figure 0-3: Diver For LT Develop Board Step 4: Click on [Open Comm] to connect with LT develop board LT_VCOM_GUI Programming_V1.0_ENG © Levetop Semiconductor Co., Ltd. Page -3-...
- Page 4 [Update Flash] – Program UartTFT_Flash.bin Please refer to Figure 1-4 for more detail. Update both MCU & Flash Update MCU_Code.bin Update UartTFT_Flash.bin Erase flash chip before programming Flash information Figure 0-4: Programming Operation LT_VCOM_GUI Programming_V1.0_ENG © Levetop Semiconductor Co., Ltd. Page -4-...
- Page 5 Note: Once [Run Uart Application] is clicked, LT develop board will exit the upgrading mode, and the connected COM port will not be recognized by LT_VCOM_GUI. Users may press the reset key on the LT develop board to enter the upgrading mode again. LT_VCOM_GUI Programming_V1.0_ENG © Levetop Semiconductor Co., Ltd. Page -5-...
- Page 6 Levetop's products are not authorized for use as critical components in life support devices or systems. Levetop reserves the right to alter its products without prior notification.
