"RADAR NEW TXF"
101-050
FAMILY CODE
USER AND
MAINTENANCE MANUAL
Multi-channel transmitter for RADAR II
radio remote controls
pag.3
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d'Iseo (Brescia) Italy Tel.: +39.030.9830611
Fax: +39.030.9839207-208 Internet:www.omfb.it e-mail:info@omfb.it
Advertisement
Table of Contents
Summary of Contents for OMFB RADAR NEW TXF
- Page 1 “RADAR NEW TXF” 101-050 FAMILY CODE USER AND MAINTENANCE MANUAL Multi-channel transmitter for RADAR II radio remote controls pag.3 O.M.F.B. S.p.A. Hydraulic Components We reserve the right to make any changes without notice. Edition 2017.05 No reproduction, however partial, is permitted.
-
Page 2: Table Of Contents
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 General comments ....................5 1.1 Description of individual push-button and LED functions ........... 5 1.2 Distinguishing features ..................... 6 1.3 Standard supplies ..................... 6 1.4 Technical specifications .................... 6 1.5 Specific features ...................... 6 Replacing the batteries .................... -
Page 3: General Comments
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 1. General comments 1.1 Description of individual push-button and LED functions STOP/EMERGENCY button Battery charge status LED Active transmission feedback LED Function buttons Column for selec- ting the A, B or C receiver pag.5... -
Page 4: Distinguishing Features
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 1.2 Distinguishing features • Compatible with the receivers: RADAR II 2CH, 4CH, 8CH, 12CH • Transmitting commands: up to 12 (2 Channels x 2 Functions x 3 Banks selectable) • Equipped with STOP/Emergency command 1.3 Standard supplies... -
Page 5: Replacing The Batteries
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 1.6 Replacing the batteries The power batteries have to be replaced immediately when the BATT LED switches on and flashes quickly while the function button is active and the TX LED is off. -
Page 6: Use In Combination With The Radar Ii 2Ch And 4Ch Receiver
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 2. Use in combination with the RADAR II 2CH and 4CH receiver 2.1 Programming This procedure is necessary if you have received a transmitter and receiver(s) separately. Before using a new TXF transmitter, communication has to be created between the transmitter and the receiver(s). -
Page 7: Use In Combination With The Radar Ii 8Ch Receiver
“RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 2.2 Use 1. Power up the receiver (insert the battery disconnector and any other switch that may be installed in series with the receiver power supply); 2. On the transmitter: press the desired functions, remembering that, if you are controlling a RADAR... - Page 8 “RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 4. Use in combination with the RADAR II 12CH receiver RADAR II 12CH radio remote control systems are configured thusly: • Qty. 3 4CH Receivers; • Qty. 1 Transmitter. The TXF transmitter controls, respectively, the first 4CH receiver on “Receiver A”, the second 4CH receiver on “Receiver B”, and the third 4CH receiver on “Receiver C”: in other words, to activate the devices connected...
- Page 9 “RADAR NEW TXF” USER AND MAINTENANCE MANUAL 101-050 5. Product Markings and certification RADAR II radio remote controls meets the rules set forth in the following harmonised technical standards: Directive 99/5/EC article: Harmonised standards: Art. 3.1 (a) - HEALTH Art. 3.1 (a) - SAFETY...
