Aritech RF352I4 Installation Sheet

RF352I4 2-Button Keychain Touchpad
Installation Sheet

Product Summary

The Keychain Touchpad is an alkaline battery-powered,
wireless touchpad designed to fit on a keychain, in a pocket or
purse. It provides users a convenient option for the following
system operations:
•
Arming the system
•
Arming the system with no delay
•
Disarming the system
•
Police Panic alarm

Installation Considerations

Use the following guidelines when adding Keychain Touchpads
to the system, and refer to the panel installation manual for
detailed instructions.
•
Keychain Touchpads are added (learned into) the panel
as sensors or wireless touchpads.
•
Each learned Keychain Touchpad uses one of the
available sensor numbers or one of the four wireless
touchpad numbers.
•
Keychain Touchpads learned as sensors are programmed
into unsupervised groups (since they don't send
supervisory signals) that determine how the panel
responds when both Keychain Touchpad buttons are
pressed together.
•
When learned as sensors, Keychain Touchpads can be
bypassed or deleted. This helps prevent lost or stolen
Keychain Touchpads from operating the system.
•
Keychain Touchpads learned as sensors use the sensor
number as the user number for central station reports that
include a user number.

Testing Keychain Touchpad Operation

Test Keychain Touchpad operation by pressing the buttons as
described below.
1. Press the disarm (unlock) button and the panel disarms to
level 1.
© 2021 Carrier
2. Press the arm (lock) button. Depending upon the panel
programming, the panel attempts arming from level 1 to
level 2
OR
the panel attempts arming from level 2 to level 3
OR
the panel arms directly to level 3, with no delay
OR
if protesting, the panel responds as if BYPASS was
pressed.
3. Press the arm and disarm buttons together and the panel
responds with either a police panic alarm or other alarm
condition (depending upon how the panel is programmed).

Replacing and Disposing of Batteries

The Keychain Touchpad is powered by one 12V Duracell
MN21 Alkaline battery.
Caution: Replace only with a 12V Duracell MN21 Alkaline
battery. Observe polarity when installing a new battery.
Installing the battery backward may cause damage to the
sensor.
WARNING: Risk of explosion if the battery is replaced by an
incorrect type
Dispose of used batteries according to the manufacturer's
instructions and local government authorities.

Specifications

Compatibility
Wireless operating frequency
Maximum power output
Power Source
Range
Dimensions (W × H × D)
Approved for use in the countries marked with a check mark:
(✓) Austria
( )Belgium
(✓) Denmark
( ) Finland
(✓) France
(✓) Germany
( ) Greece
( ) Iceland
(✓) Ireland
(✓) Italy
1 / 2
All ITI 433 MHz Receivers and Learn
Mode™ Panels
433.050 MHz - 434.790 MHz
10 dBm E.R.P.
12V Duracell MN21 alkaline battery
At least 152.4 m open air
5.8 x 3.7 x 1.2 cm
( ) Liechtenstein
( ) Luxembourg
(✓) Netherlands
( )Norway
( ) Poland
(✓) Portugal
(✓) Spain
(✓) Sweden
( ) Switzerland
( ) United Kingdom
P/N 466-1760 • REV E • ISS 17MAR21
