- Page 1 PoE to Wi-Fi Bridge Quick Start Guide ADC-W110...
-
Page 3: Pre-Installation Checklist
Pre-installation checklist • ADC-W110 PoE to Wi-Fi Bridge (included) • Standard non-switched electrical outlet • Broadband (Cable, DSL or Fiber Optic) Internet connection with router • A computer, tablet, or smartphone with Internet access is required if the router does not have the Wi-Fi Protected Setup (WPS) feature •... - Page 4 Connect the PoE to Wi-Fi Bridge to the Wireless Network AP Mode Complete these steps to connect the W110 to a wireless network using AP mode. 1. Plug the W110 into an electrical outlet that is within range of the customer’s Wi-Fi network. Wait for the Wi-Fi LED to begin blinking white.
- Page 5 Connect the PoE to Wi-Fi Bridge to the Wireless Network WPS Mode Complete these steps to connect the W110 to a wireless network using WPS mode. 1. Plug the W110 into a non-switched electrical outlet that is within range of the customer’s Wi-Fi network. Wait for the Wi-Fi LED to begin blinking white.
- Page 6 LED reference guide ❶ Communication Button ❷ Power LED ❸ Wi-Fi LED ❹ Communication LED ❺ PoE Camera Port ❷ ❶ ❸ ❹ ❺ Device power Device powered on Solid Green Device powered off Status Successfully connected to the wireless network Solid White Solid Green Local network connection only, connecting to Internet...
- Page 7 WPS mode Blinking Green AP mode Blinking White Error No network found. See troubleshooting section. Blinking Red Factory reset Blinking Red Blinking Red...
-
Page 8: Troubleshooting
Troubleshooting If the W110 has already been added to a wireless network (indicated by the W110 not entering AP mode after powering on) and you want to change networks: • To enter WPS mode, press and hold the Communication button until the Communication LED begins blinking green (approximately 2 to 6 seconds). - Page 9 WARNING: This will restore factory-default settings to the device. Any associated Wi-Fi networks will be removed. The W110 is specifically designed for use with Alarm.com Power over Ethernet video cameras. Use with other devices is not recommended. Questions? Visit: www.alarm.com/supportcenter...
- Page 10 Notices Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 12 8281 Greensboro Drive 190103 Suite 100 © 2019 Alarm.com. All rights reserved. Tysons, VA 22102 Made in China.
