TM
AS740
2019 Operator's Manual
DO NOT OPERATE THIS EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD.
ONLY PROPERLY TRAINED PERSONS SHOULD OPERATE THIS MACHINE.
FORM # 580510004
COPYRIGHT 2018
EQUIPMENT TECHNOLOGIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APACHE AS740 and is the answer not in the manual?

Questions and answers

Summary of Contents for Equipment Technologies APACHE AS740

  • Page 1 AS740 2019 Operator’s Manual DO NOT OPERATE THIS EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD. ONLY PROPERLY TRAINED PERSONS SHOULD OPERATE THIS MACHINE. FORM # 580510004 COPYRIGHT 2018 EQUIPMENT TECHNOLOGIES...
  • Page 2 Apache Sprayer Information The password for the locked screens on the ET Pilot Touchscreen is “2201”. Machine Model: ________________________ Dealer: _________________________ Machine Serial #:________________________ Main Phone # _______________ Engine Serial #: _________________________ Service Contact: __________________ Rate Controller Model:_____________________ Phone # ___________________ Aux Controller/Display:____________________ Parts Contact:____________________ Phone# ___________________...
  • Page 3 Dear Valued Customer, Congratulations on the purchase of your new Apache Sprayer, and welcome to the Apache family of owners! We hope that your new Apache Sprayer exceeds your expectations, and gives you years of satisfaction. We invite you to visit us at www.etsprayers.com or in person at our plant in Mooresville, Indiana.
  • Page 4 This includes driving on an A-B line for roughly 20 minutes after automatic calibration is complet- ed to allow the yaw sensor to learn how to acquire the line properly. Trademark Information Caterpillar® Equipment Technologies (ET) • Cat® TDTO 30 • Apache™ Cummins®...

  • Page 5: Table Of Contents

    Reverse 3-28 Chapter 1: General Information Foot Throttle/ Decelerator 3-29 2019 AS740 Specifications Exhaust Braking 3-29 Apache AS740 Fluids, Filters and Capacities Cruise Control 3-30 Chapter 2: Safety Towing 3-31 Safety Symbols, Signal Word and Statements Hood Tilt Latch 3-31...
  • Page 6 Boom Power Distribution Module Check Transmission Fluid Level 5-15 Chapter 9: Warranty Check Hydraulic Fluid Level 5-15 Equipment Technologies Warranty Policy Adjust Poly Tank Straps 5-16 For all 2019 Model Year Apaches Every 40 Hours 5-16 Chapter 10: Maintenance Log...

  • Page 7: Chapter 1: General Information

    The graphics and text in this manual generally describe the AS740 Apache Sprayer. Apache Sprayers differ by model and by optionally installed equipment. Your Apache Sprayer may not exactly match the graphics and/or text descriptions in this manual. Please contact your dealer or Equipment Technologies with any questions regarding this manual, or the instructions within it. 2019 AS740 Specifications...

  • Page 8: Apache As740 Fluids, Filters And Capacities

    GENERAL INFORMATION Apache AS740 Fluids, Filters and Capacities Capacity Component Lubrication Filter Part Number Quarts [Liters] Engine Oil Lucas 15W-40 Magnum Motor Oil 16 [15] 201450241 KostGuard Universal Engine Coolant 24 [22.7] ---- Antifreeze 50/50 Engine Primary Air Filter ----...
  • Page 9 CHAPTER 2 SAFET Y Apache is committed to the safe design and operation of messages and information contained in this manual and its products. This Apache Sprayer has been designed and on the Apache Sprayer to prevent personal injury and manufactured with your personal safety while operating ensure safe reliable Apache Sprayer operation.

  • Page 10: Chapter 2: Safety

    Safety Safety Precautions There is no substitute for common sense and following careful operation and service practices. Improper practices and carelessness can cause personal injury or even death. The following safety precautions and guidelines must be followed in addition to the specific safety precautions listed throughout this manual and on the Apache Sprayer to reduce the risk of personal injury.

  • Page 11: Burn Hazards

    Safety Burn Hazards Some of the engine surfaces become very hot during operation and shortly after shut-down. Keep hands and other body parts away from hot engine surfaces. Lifting Hazards • ALWAYS use lifting equipment with sufficient capacity to lift the Apache Sprayer or equipment. •...

  • Page 12: Exhaust Emissions Safety

    Safety Exhaust Emissions Safety Carefully read all safety information and observe any exhaust or pollution safety instructions. Be aware of and follow all regulations and policies as outlined by the engine OEM to maintain exhaust emission compliance with the Environmental Protection Agency (EPA), California Air Resources Board (CARB) and Environment Canada where applicable.

  • Page 13: Safety Decals

    Safety Safety Belt ( ctnd.) WARNING! Impact Hazard DO NOT operate the Apache Sprayer if any part of the seat belt system is damaged. The system must be repaired or replaced before operating the Apache Sprayer. NOTICE: DO NOT use harsh cleaners, bleach or any products which could cause the safety belt material to deteriorate. Safety Decals CAUTION! ALWAYS read and follow the safety decals on the Apache Sprayer.

  • Page 14: Exterior Decal Locations

    Safety Exterior Decal Locations AS740 Operator’s Manual...
  • Page 15 Safety Exterior Decal Locations (continued) AS740 Operator’s Manual...
  • Page 16 Safety Exterior Decal Locations (continued) (Not shown in the picture) AS740 Operator’s Manual...

  • Page 17: Pre-Operation Checks

    CHAPTER 3 OPERAT ION Before performing any operation procedures, read the following Pre-Operation Checks safety messages and read the Safety Section. Before operating the Apache Sprayer, perform the following safety and equipment checks. • Read and understand this manual before operating the Apache Sprayer.

  • Page 18: Cab Overview

    OPERATION Cab Overview 1. Air Vents (multiple points in the steering 6. Arm Rest column - not shown) 7. Brake Pedal 2. Steering Column 8. Air Seat 3. Steering Wheel 9. Fire Extinguisher 4. Joystick (left of seat) 5. ET Pilot System AS740 Operator’s Manual...

  • Page 19: Cab Access Ladder

    OPERATION Cab Access Ladder Access Ladder The cab access ladder is automatically actuated by the parking brake switch. • When the parking brake is applied, the ladder folds down. • When the parking brake is released, the ladder folds up. Steering Column NOTE: DO NOT drill the plastic of the steering column, or alter in any way.

  • Page 20: Et Pilot System

    OPERATION ET Pilot System 1. Engine RPM and MPH Readout 2. Temperature Gauge 3. Fuel Gauge 4. Direction and Gear Indicator (The gear indicator will remain solid when torque converter is locked in.) 5. Engine Hours 6. Scheduled Maintenance Icon (Appears only when there is Scheduled Maintenance required.) 7.
  • Page 21 OPERATION ET Pilot System (continued) 1. Cruise Control Buttons 2. Engine Start/Stop Button 3. Agitate and Product Pump Buttons 4. Boom Fold/Unfold Buttons 5. Park Brake Button 6. Climate Control Buttons AS740 Operator’s Manual...

  • Page 22: Et Pilot System Touch Screen

    OPERATION ET Pilot System Touch Screen To use the screen there are a few things to know. To change the items inside the gauges, touch the RPM or MPH icons (1) to display different options such as: Average GPH, Torque, MPH and RPM. To move to the App Screen, swipe left, anywhere in the middle of the screen (2) except for inside the gauges (1).
  • Page 23 OPERATION ET Pilot System Touch Screen (continued) After moving to the App Screen (by swiping left, anywhere in the middle of the home screen, except for inside the gauges) select an App, by touching the desired icon (1) on the screen to move to the selected screen. Once in an App screen, there are a few options to choose from.

  • Page 24: Diagnostics

    OPERATION Diagnostics Page 1: Vehicle Warnings When a new vehicle warning happens, the touchscreen will display a warning screen. It will indicate the fault code (1) and general description of that code (2). Touch the OK icon (3) to close the screen. To access the Active Faults screen, either touch the fault indicator (1) at the top of the screen or touch the Diagnostics App icon (2).

  • Page 25: Fault History

    OPERATION Fault History This page will display the option to choose active faults or fault history. Choose fault history (1). Then touch the fault in- formation bar to expand for further detail (2). The last hours are shown when the fault was last active (3). Once the information has expanded, the page will display more detail.
  • Page 26 OPERATION Diagnostics Page 2: Parameters To filter for Machine Parameters only, select Machine button (1). To filter for Engine Parameters only, select Engine button (2) . To filter Aftertreatment Parameters, select Aftertreat- ment button (3). To view All Parameters select All (4). To view all the information on that page, swipe the screen up.
  • Page 27 OPERATION Diagnostics Page 4 Page 4 of the diagnostic app shows a system map diagram. This diagram indicates which ET machine processors are online or offline. A green circle with a indicates the processor is online. A red circle with an x indicates a pro- cessor is off line.

  • Page 28: Diagnostics

    OPERATION Diagnostics Page 4 (continued) CHASSIS CONTROL DETAIL VIEW The left side of the screen will show the connection status for each processor that is visible on the firewall box along with the current software version. If a processor is not available (i.e.
  • Page 29 OPERATION Diagnostics Page 4 (continued) CAB BOARD CONTROLLER DETAIL VIEW On the bottom left of the screen, fuse/circuit detection faults are seen with the corresponding fuse and relay (if applicable) highlighted on the dynamic display on the right side of the screen.
  • Page 30 OPERATION Diagnostics Page 4 (continued) ARMREST KEYPAD DETAIL VIEW The top left side of the screen shows the connection sta- tus for the processor. Touching the function buttons on the armrest keypad will highlight the corresponding button on the dynamic display located on the right side of the screen. This will indicate whether or not the button touch is being seen by the CAN circuit.

  • Page 31: Scheduled Maintenance App

    OPERATION Scheduled Maintenance App The scheduled maintenance app is used to provide mainte- nance information and reminders. The app icon is located on the second page of the app menu. (1) This app can also be opened via a maintenance reminder icon on the bottom row (2).
  • Page 32 OPERATION Scheduled Maintenance App (continued) Maintenance Entry Alongside each item on the interval maintenance page is a button that allows the user to enter a maintenance event for that item. (1) Selecting the entry button opens a dialog that asks the user if they would like to add a maintenance entry for that item description.

  • Page 33: Vehicle Settings

    OPERATION Vehicle Settings Page 1: To activate these settings, touch the white circle (1). This will allow you to make adjustments to those settings by using the slider (2). Touch the red icon in the slider and swipe left or right to increase or decrease the value. To access the remaining options on this page, swipe the screen up (3).
  • Page 34 OPERATION Vehicle Settings Page 3: Foot Throttle Calibration **To be able to continue to the next page, a passcode is needed. This is a warning that the changes that are going to be made, will effect the machine’s function. Enter the code “2201” by touching the number icons (1). To cancel and return to the previous screen, touch the cancel icon (2).

  • Page 35: Light Buttons

    OPERATION The selection for Transmission Model, must be the JCB PS764 (1). Swipe the screen up to see all of the Vehicle Options. (2) The selection for the Engine Model, must be Tier 4F (3). Only select the options equipped on the machine (4). Light Buttons 1.

  • Page 36: Apache Sprayer Lighting

    For further detailed instructions visit the manufacturer’s website: http://asaelectronics.com/manuals-guides 2. Equipment Technologies is pleased to provide you with 3-months of free Sirius Satellite Radio! See Activation Information on the next page or find the instructions at the bottom of page 2 of the quick reference guide of your Apache’s Polk audio system.

  • Page 37: Siriusxm Satellite Radio Activation Information

    OPERATION ® SiriusXM Satellite Radio Activation Information Activation is easy and does not start until you are ready. This way, you are able to enjoy 120+ channels of crystal clear satel- lite radio throughout the majority of your application season. Activating your SiriusXM®...

  • Page 38: Seat Adjustment

    OPERATION Seat Adjustment Leather Seat Slide Release Lever: • Pull, hold and slide forward or rearward. • Release to stop slide. Fore-Aft Position of the Seat Cushion Only • Pull up and hold to adjust, release to stop. Seat Cushion Tilt: •...

  • Page 39: Joystick And Viper

    OPERATION Joystick and Viper® 4+ Console 1. Viper® 4+ Console (option) 2. Joystick See “Apache Sprayer Direction and Speed” on page 3-24 for complete operations 3. Auto Steer Engage Button (If equipped) 4. Master Spray Button 5. Boom Rack Press to move the boom rack up or down. 6.

  • Page 40: Starting And Stopping Engine

    OPERATION Starting and Stopping the Engine WARNING! Impact Hazard. ALWAYS fasten your seat belt when operating the Apache Sprayer. The safety belt must be worn properly by the driver anytime the Apache Sprayer is in motion. Refer to Safety Belt on page 2-4.

  • Page 41: Warm-Up

    OPERATION Warm-up Check the engine oil pressure (1) as soon as the engine starts. To do this, access the App Screen and choose the Diagnos- tics App. Swipe left to page two. • If the oil pressure reading does not reach the minimum pressure of 15 psi [103.4 kPa], stop the engine and determine the cause.

  • Page 42: Apache Sprayer Direction And Speed

    OPERATION Apache Sprayer Direction and Speed WARNING! Sudden Movement Hazards • NEVER leave the operator’s seat or cab when the Apache Sprayer is in gear. ALWAYS stop the Apache Sprayer, shift the transmission into NEUTRAL and then apply the parking brake before exiting the cab.

  • Page 43: Forward

    OPERATION Forward To move the Apache Sprayer forward: Apply the foot brakes and release the parking brake. NOTE: The transmission will not shift if the parking brake is applied. To move forward: • Release the park brake. • Apply the Apache Sprayer brakes. •...

  • Page 44: Reverse

    OPERATION Upshifting and downshifting are achieved with a sideways rock and release movement or bump of the joystick. The joystick should return to the center (side-to-side) position between shifts and some time must be allowed for the transmission to respond. Upshifting: •...

  • Page 45: Foot Throttle/Decelerator

    OPERATION Foot Throttle/Decelerator The foot throttle/decelerator can be used to override the joystick throttle. Depending on which setting is chose for the foot pedal, it will override the joystick. Once the foot throttle/decelerator is released, the engine RPM will return to the joystick’s last RPM position. To enable the Decelerator, navigate to the first page of the Vehicle Settings screen and find the Decelerator Enable and Limit section.

  • Page 46: Cruise Control

    OPERATION Cruise Control The Apache offers the ability to set two cruise control points. To use the cruise control function, the machine must be in gear to operate. Press the master cruise button (1) to enable. Next, select cruise: one or two (2) on the control pad. To adjust the set speed, click the up and down arrow buttons (3).

  • Page 47: Towing

    OPERATION Towing ALWAYS use towing safety equipment and proper emergency warning lighting when towing the Apache Sprayer. If the Apache Sprayer’s transmission should become disabled, it may be towed for approximately 1 mile [1.6 km] at speeds less than 3 mph [4.8 km/h]. While towing the Apache Sprayer, the engine should be running at idle and the parking brake released.

  • Page 48: Battery

    OPERATION Battery The batteries are located under the hood, between the engine and the cab. The Apache Sprayer features a battery disconnect button, located in the cab on the post behind the arm rest (1). Only turn the battery disconnect button off when working on the machine.

  • Page 49: Axle Adjustment (Manual)

    OPERATION Axle Adjustment (optional) Manual The front and rear axles on the Apache Sprayer are adjustable from 120 to 160 in. [304.8 to 406.4 cm] (measured from center of left tire to center of right tire. Front Safely lift the front of the Apache Sprayer so the front tires are slightly off of the ground.

  • Page 50: Axle Adjustment (Optional) (Adjust-On-The-Go)

    OPERATION Axle Adjustment (Optional) (Adjust-On-The-Go) The front and rear axles on the Apache Sprayer are adjust- able from 120 to 160 in. [304.8 to 406.4cm] (measured from center of left tire to center of right tire). NOTE: The Adjust-On-The-Go system will not allow the axle to be adjusted beyond 160 in.
  • Page 51 OPERATION Adjust-On-The-Go Calibration (ctnd.) Once finished click done (1). Repeat the process to fully extend the axles. Click begin (2) while still moving at least 3 mph. Once fin- ished, click done for the process to be completed. Front Axle When activated, the Adjust-On-The-Go cylinder (1) adjusts the axle inward or outward as desired.

  • Page 52: Vehicle Dynamics

    OPERATION Rear Axle When activated, the Adjust-On-The-Go cylinder (1) adjusts the axle inward or outward as desired. The rear wheels/axles are actuated by two cylinders per wheel. The left rear Adjust On The Go axle is shown. NOTICE: The bolts (2) should be torqued to 22 lb-ft [30 N•m] at all times.

  • Page 53: Climate Controls

    OPERATION Climate Controls 1. Temperature Buttons. • Sets the desired temperature. 2. Vent Selection Buttons. • Selects which vents are on. 3. Auto Climate Control. • Automatically controls the fan. 4. A/C Activation Button. • Turns A/C on. 5. Manual Fan Controls. •...

  • Page 54: Precision Equipment

    Refer to the respective operators manual included with the machine before use. NOTE: Raven-based precision equipment is designed in a joint effort with Equipment Technologies and Raven and contains items that are specific to Apache Sprayers. Please note this with your service provider when seeking service.

  • Page 55: Rear Camera

    OPERATION Rear Camera If the rear camera is enabled, the full screen image will display when the sprayer is in reverse. To manually access the camera, press the Rear Camera App icon (1). The rear camera will display as well as the left information panel, regardless which direction the sprayer is moving.

  • Page 56: Jumpstarting The Engine

    OPERATION Jumpstarting The Engine Before performing any operation procedures, read the following safety messages and read the Safety Section. WARNING! Fire Hazard. NEVER start the engine by SHORTING ACROSS the starter terminals. WARNING! Safety Hazard. NEVER exceed 125 amps if boosting / charging a machine through the Fill Station battery terminal posts.
  • Page 57 OPERATION • Connect the second jumper cable to the negative ( - ) terminal on the booster battery. Connect the other end to the starter’s negative terminal ( - ). • Connect the battery via the battery disconnect switch. • Set the parking brake. •...

  • Page 58: Exhaust Cleaning

    OPERATION Exhaust Cleaning Warning! During exhaust system cleaning operations, the engine may run at elevated idle and hot temperatures for an extended period of time. Exhaust gases and exhaust system compo- nents reach temperatures hot enough to burn people, or ignite or melt common materials. Keep machine away from people, animals, or structures which may be susceptible to harm or damage from hot exhaust gases or components.

  • Page 59: Disabled Mode

    OPERATION Disabled Mode To access Disabled Mode, slide the main screen to the left until the Exhaust Cleaning app (1) is visible. Touch the Exhaust Cleaning icon to continue to the next screen. To change from Automatic mode to Disabled mode, touch the Disabled radial button (2).

  • Page 60: Manual Cleaning

    OPERATION Manual Cleaning When the machine Exhaust Cleaning is disabled, the machine will determine when it is time to perform a cleaning. It will be indicated at the top of the screen with the Cleaning Required lamp (1). The manual cleaning option will then be available.

  • Page 61: Low Def Fluid

    OPERATION Manual Cleaning (continued) If the Park Brake is released or the Engine Idle is manually changed, the Exhaust Cleaning process will be aborted (1). Once the process has been aborted, the Inhibit Switch will revert back to Disabled (2). The process can be started again, once the criteria has been met.
  • Page 62 OPERATION 5% DEF fluid level- A vehicle warning will pop up on the screen with the engine fault code and a brief explanation of the fault. Click on the OK button (1) to return to the main screen. The Yellow warning lamp (2) and the flashing Amber DEF lamp (3) will be on.
  • Page 63 OPERATION 2.5% DEF fluid level- A vehicle warning will pop up on the screen with the engine fault code and a brief explanation of the fault. Click on the OK button (1) to return to the main screen. The Amber Engine Warning lamp (1) and the Flashing Amber DEF lamp (2) will be on.
  • Page 64 OPERATION NOTES 3-48 AS740 Operator’s Manual...

  • Page 65: Chapter 4: Wet System Operation

    Chapter 4 WET SYSTEM OPERATION NOTICE: Before performing any wet system operation procedures, read the Safety Section on page 2-1. Wet System Overview 1. Fill Station 5. Flow Controls 2. Boom Cradle 6. Product Tank 3. Rinse Tank 7. Left Boom Tip 4.

  • Page 66: Product Pump And Valves

    WET SYSTEM OPERATION Fill Station 1. Hand Rinse Valve This valve allows water from the rinse tank on the right side to be used for hand rinsing. 2. Rinse Tank Quick Fill 3. Product Valve (shown in CLOSED position) This valve directs flow from the product tank to the pump or from the rinse tank to the pump.

  • Page 67: Sump Valve

    WET SYSTEM OPERATION Sump Valve 1. Product Tank Sump Valve Shown in the OPEN position. Flow Control 1. Raven Flowmeter 2. PWM Valve AS740 Operator’s Manual...

  • Page 68: Electronic Boom Valves

    50 mesh screens, that must be cleaned periodically. Viper® 4+ Monitor Viper® 4+ Monitor is the Raven field computer option. This monitor is built for Equipment Technologies by Raven. See the manufacturer’s instructions, provided with the Apache Sprayer, for complete operating, calibration, and service information.

  • Page 69: Side Console

    WET SYSTEM OPERATION Side Console ® 1. Viper 4+ Controller (option) 2. Master Spray Button 3. Boom Tilt/ Rack Buttons 4. Left/Right Wing Buttons 5. Fold/Unfold Buttons 6. Left/Right Tip Buttons 7. Agitate Up Button 8. Product Pump Button 9. Agitate Down Button AS740 Operator’s Manual...

  • Page 70: Joystick

    WET SYSTEM OPERATION Joystick 1. Left Boom Tilt Press to tilt the left boom up or down. Press the top of the button to raise and press the bottom of the button to lower. 2. Right Boom Tilt Press to tilt the right boom up or down. Press the top of the button to raise and press the bottom of the button to lower.

  • Page 71: Tank Fill Monitor

    WET SYSTEM OPERATION Tank Fill Monitor (optional) Screen 1: The first screen shows the Tank Volume and Fill Volume in larger text. The Edit button allows you to adjust tank volume (see screen 2) The purpose of this is to add chemical to the tank that is not added through the secondary flow meter.
  • Page 72 WET SYSTEM OPERATION Tank Fill Monitor (optional) (continued): Screen 3: The third screen is for information. It has Tank Capacity, Fill Volume, Tank Volume, Sparge Pressure and the Flow Rate. Screen 4: The fourth screen is just a node information screen. It has the Product Controller node information and fill meter display information.

  • Page 73: Product Tank Sight Gauge

    WET SYSTEM OPERATION Product Tank Sight Gauge The product tank sight gauge is located on the side of the fill station leading up to the hand rail above the tool box. The gauge (1) indicates the amount of product in the tank, begin- ning at 50 gallons and up to 250 gallons on the side.

  • Page 74: Operating Booms

    WET SYSTEM OPERATION Operating Booms Before performing any boom operations, read all the following safety messages and take all necessary precautions to avoid personal injury and equipment damage. WARNING! Electrocution Hazard. DO NOT fold or unfold the booms near power lines. WARNING! Control Hazard.
  • Page 75 WET SYSTEM OPERATION Height Adjustment On the joystick, press the bottom of the boom rack raise/low- er button (1) to lower the boom rack (2) to the desired height. Press the top of the button to raise the boom rack. Tilt to Level Boom On the joystick, use the Left (1) and/or Right (2) boom tilt raise/lower buttons to adjust the booms to level.
  • Page 76 WET SYSTEM OPERATION Fold Boom Wings NOTICE: ALWAYS raise the rack and the left and right boom tips completely before folding the booms. On the console keypad, make sure the Fold button (1) is acti- vated. Then, press and hold the Left and Right Wing buttons (2) until the boom wings are fully folded.
  • Page 77 WET SYSTEM OPERATION Spraying (continued) Set the product valve (1) to PRODUCT TO PUMP. Set rotoflush/agitation knob (2) to AGITATION. The product strainer (1) features 50 mesh screens, which should be checked and cleaned after every 50 hours of opera- tion or as needed.
  • Page 78 WET SYSTEM OPERATION Set the product pump button (1) to the ON position. Using the Viper 4, set the desired boom section to the ON position. IMPORTANT: DO NOT run the product pump dry. Damage to the pump seals will result. DO NOT intentionally dead-head the pump with high pressures.
  • Page 79 WET SYSTEM OPERATION Optional Fence Row Nozzle The Apache sprayer can be equipped with optional left, and/ or right fence row nozzles. If equipped, the fence row nozzles (1) and actuator solenoids (2) are plumbed into the first boom section on the left and the last boom section on the right (left side shown).
  • Page 80 WET SYSTEM OPERATION Flushing Booms NOTICE: Read and follow chemical labels for proper usage, flushing, disposal and protective clothing requirement instruc- tions. ALWAYS dispose of chemicals and contaminated rinse water in a safe location in accordance with chemical label recommendations and local laws. NOTICE: Some chemicals may require multiple tank flushings.
  • Page 81 WET SYSTEM OPERATION Cleanload Chemical Eductor The eductor assembly is automatically lowered and raised with the use of the park brake button. When the park brake is activated, the eductor is lowered. When the park brake is deactivated, the eductor is raised. Startup 1.
  • Page 82 WET SYSTEM OPERATION NOTES 4-18 AS740 Operator’s Manual...
  • Page 83 CHAPTER 5 LUBRICATION AND MAINTENANCE The Scheduled Maintenance Icon will illuminate when maintenance is required. Before performing any maintenance procedures, read the Safety Section on page 2-1. Maintenance Precautions • Parts found defective during inspection or any part whose specifications are not adequate must be replaced. •...
  • Page 84 LUBRICATION AND MAINTENANCE WARNING! Flying Object Hazard • ALWAYS wear eye protection when servicing the engine or when using compressed air or high-pressure water. Dust, flying debris, compressed air, pressurized water or steam may injure your eyes. WARNING! Crush Hazards •...
  • Page 85 LUBRICATION AND MAINTENANCE WARNING! Shop Equipment Hazards • ALWAYS check before starting the engine that any tools or shop rags used during mainte- nance have been removed from the area. • ALWAYS use tools appropriate for the task at hand and use the correct size tool for loosening or tightening machine parts.
  • Page 86 LUBRICATION AND MAINTENANCE Cleaning Guidelines The following guidelines are recommended when cleaning mechanical and electrical parts of the cab. WARNING! Fire Hazard • Cleaning solvents can cause death or serious injury. • Cleaning solvents are extremely flammable and toxic if inhaled. •...
  • Page 87 LUBRICATION AND MAINTENANCE Apache Sprayer Service Interval Chart Perform and repeat the prescribed maintenance at each interval. = Required Service = Conditional Service = Regular Service NOTE: DO NOT overlook the “After First 100 Hours” interval. Check (and adjust as needed) Poly Tank Straps Torque Lug Nuts Grease Steering Components Grease Axle Components...
  • Page 88 LUBRICATION AND MAINTENANCE Before Initial Use The following services must be performed before initial use of the Apache Sprayer and repeated at the interval prescribed in the Apache Sprayer Service Interval Chart. See “Apache Sprayer Service Interval Chart” on page 5-5. •...
  • Page 89 LUBRICATION AND MAINTENANCE 2. Loosen the 3 bleed screws (1) for the boom fold and cushion circuits. 3. Loosen the jam nut (1) on the fold cylinder cushion rod. 4. Rotate the fold cylinder cushion rod (2) to adjust the boom lead.
  • Page 90 LUBRICATION AND MAINTENANCE Boom Breakaway Each left and right boom is equipped with one or two boom breakaways depending on boom configuration. A right, boom tip breakaway is shown. The breakaways should be adjusted so the boom sections on both sides of the breakaways are straight and aligned as they extend from the boom rack.
  • Page 91 LUBRICATION AND MAINTENANCE As Required The following services will be required at various intervals depending on both Apache Sprayer use and environmental con- ditions. Repeat these services as prescribed by the Apache Sprayer Service Interval Chart. See “Apache Sprayer Service Interval Chart”...
  • Page 92 LUBRICATION AND MAINTENANCE Grease Pommier Boom (Optional Equipment) The Pommier boom is equipped with five sets of grease fittings. Apply an ample amount of lithium grease through each of the grease fittings. 1. Boom Fold Cylinder (2 fittings) 4. Boom Tip Fold (7 fittings) 2.
  • Page 93 LUBRICATION AND MAINTENANCE Boom Fold Cylinder There are two grease fittings (1) on each boom fold cylinder. The left side is shown. Tilt Cylinder There are two grease fittings (1) on each tilt cylinder. The right side is shown. Boom Tip Fold There are seven grease fittings in the boom tip fold area of each boom.
  • Page 94 LUBRICATION AND MAINTENANCE Boom Breakaway There is one grease fitting (1) on each boom breakaway. The left side is shown. Flush Wet System Drain and flush the product tank and wet system after use and when changing chemicals. See “Flushing Product Tank” on page 4-15.
  • Page 95 LUBRICATION AND MAINTENANCE Check Engine Oil Level NOTICE: If the engine has been running, shut off and wait 10 minutes before checking oil level. The dipstick is located in the engine compartment, on the left side of the engine. While parked on level ground, remove the dipstick and check the oil level.
  • Page 96 LUBRICATION AND MAINTENANCE Check Cooling System WARNING! Fire Hazard. Coolant may be flammable under certain conditions. NEVER allow coolant to come into contact with hot surfaces. WARNING! Exposure Hazard. Wear eye protection and rubber gloves when handling engine coolant. Avoid skin contact with coolant. If contact with the eyes or skin should occur, flush eyes and wash immediately with clean water.
  • Page 97 LUBRICATION AND MAINTENANCE Check Transmission Fluid Level NOTICE: While parked on level ground, check the transmission fluid level with the oil at operating temperature and the engine off. The transmission fluid dipstick is located in the engine com- partment, on the left side of the engine, and toward the cab. NOTE: The transmission fluid should be at operating tempera- ture and the engine should be off.
  • Page 98 LUBRICATION AND MAINTENANCE Adjust Poly Tank Straps Check the poly tank straps while the tank is at least 50% full. If the straps feel or appear loose, tighten them evenly from side to side without deforming the tank, bolts, or the tank cradle.
  • Page 99 LUBRICATION AND MAINTENANCE Grease Front Axle Assembly Each steering cylinder has two king-pin grease fittings (1), one hub grease fitting (2), and one inter-flex bearing grease fitting (3). The right wheel is shown. Apply lithium grease through the two king-pin grease fittings (1). Apply lithium grease through the hub bearing grease fitting (2).
  • Page 100 LUBRICATION AND MAINTENANCE Grease Axle Components (adjustable only) The rear axle is equipped with 24 grease fittings, installed in two square-tube axle extension assemblies. Eight fittings point downward from the bottom faces of each square tube. Shown are the four rear-most fittings (1). The front axle is equipped with 12 grease fittings.
  • Page 101 LUBRICATION AND MAINTENANCE After First 100 Hours The following services must be performed after the first 100 hours of operation and repeated as prescribed by the Apache Sprayer Service Interval Chart. • Adjust Poly Tank Straps. See “Adjust Poly Tank Straps” on page 5-16. •...
  • Page 102 LUBRICATION AND MAINTENANCE Every 100 Hours The following services must be performed after every 100 hours of operation of the Apache Sprayer. Grease Driveline Components The Apache Sprayer has a total of ten driveline grease fittings. Three of these fittings are slip joint fittings, and seven are U-joint fittings.
  • Page 103 LUBRICATION AND MAINTENANCE Torque Axle Extension Brace Bolts NOTICE: There are different axle brace bolt torque values for manual and Adjust-On-The-Go axles. Follow the instructions for your application. Also, it is recommended to thread all bolts down until they make contact with the wedge blocks, verify the slider tube is centered, then tighten in a cross pattern similar to wheel lug nuts.
  • Page 104 LUBRICATION AND MAINTENANCE Change Fuel Filter The fuel filter (1) is located in the engine compartment on the left side of the engine. WARNING! Fire Hazard. Wipe up fuel spills immediately. Fuel will spill from the filter and fuel lines when loosened or removed. Use a suitable container to collect the fuel and dispose of properly.
  • Page 105 LUBRICATION AND MAINTENANCE Clean Fuel Tank Strainer The fuel tank strainer is located in the fuel tank, behind the fuel supply line fitting (1). The best time to clean the fuel tank strainer is when the fuel level is low. Drain the fuel tank and remove the 1/2”...
  • Page 106 LUBRICATION AND MAINTENANCE Every 500 Hours or Yearly NOTE: Some services at this interval were performed at the “After First 100 Hours” interval. If the service was performed as prescribed, measurement of 500 hours should begin at the 100 hour mark. The following services must be performed after every 500 hours of operation or yearly.
  • Page 107 LUBRICATION AND MAINTENANCE Change Differential Fluid The differential is located under the Apache Sprayer, on the rear axle. The fill/level plug (1) is directly above the drain plug on the rear of the differential. Remove the differential drain plug and drain the fluid into a suitable container.
  • Page 108 LUBRICATION AND MAINTENANCE Clean Hydraulic Fluid Strainer (continued) Remove the hydraulic fluid line (1). Remove the strainer (2). Clean the strainer with diesel fuel and allow to air dry. Dispose of the fuel properly. NOTICE: If the strainer cannot be cleaned or has holes in the screen, replace with new strainer.
  • Page 109 LUBRICATION AND MAINTENANCE Inspect Front Accumulator and Suspension Cylinder Inspect the front accumulators and suspension cylinders for hydraulic leaks and correct operation. Typically, the cylinder should have 4 to 6 in. [101.6 to 152.4 mm] of the cylinder ram showing while the Apache Sprayer is on level ground. NOTE: Additional cylinder ram may be exposed when the Apache Sprayer is new.
  • Page 110 LUBRICATION AND MAINTENANCE Change Engine Oil and Filter WARNING! Burn Hazard. If you must drain the engine oil while it is still hot, stay clear of the hot engine oil to avoid being burned. ALWAYS wear eye protection. Operate the engine for approximately five minutes to warm the engine oil.
  • Page 111 LUBRICATION AND MAINTENANCE Change Transmission Fluid and Filter and Clean Strainer The transmission drain plug is located under the machine on the front side of the transmission. Remove the drain plug (1) and drain the transmission fluid into a suitable container. Dispose of the fluid properly. Install the drain plug (1) Remove the strainer cover plate (2) and clean the strainer with diesel fuel.
  • Page 112 LUBRICATION AND MAINTENANCE Check the transmission fluid level with the transmission fluid at normal operating temperature, transmission in NEUTRAL position, and the engine off. The fluid level should be between the two dots on the dip- stick. Install the dipstick and turn the handle clockwise to tighten. Inspect and Repack Wheel and Inter-Flex Bearings Contact your dealer to inspect and repack the wheel (1) and inter-flex (2) bearings.
  • Page 113 LUBRICATION AND MAINTENANCE Change Final Drive Fluid Depending on the machine’s crop clearance, the Apache Sprayer is equipped with either a drop box or planetary final drive. Drop Box The drop box drain, level and fill plugs are located on the drop box at each rear wheel.
  • Page 114 LUBRICATION AND MAINTENANCE Change Cab Charcoal Filter NOTICE: DO NOT attempt to clean the old cab air filter. ALWAYS replace with a new filter. The charcoal air filter is located under the cab, connected to the A/C box. Remove the knob screw (1) by turning to the left to loosen. Remove and discard the filter (1) by sliding it out.
  • Page 115 LUBRICATION AND MAINTENANCE Every Year The following services must be performed every year. Adjust Toe-In (Standard 120” Axles) Measure Toe-In Safely lift the front of the Apache Sprayer so the front tires are slightly off of the ground. Turn the steering wheel so the front wheels are pointing straight. Measure and note the distance between the left and right tires at the front (1) of the tires and at the rear (2) of the tires.
  • Page 116 LUBRICATION AND MAINTENANCE Adjust Toe-In (120” to 160” Adjustable Axles) NOTICE: On adjustable axle machines, the steering must be re-phased before measuring or adjusting the toe-in. Rephase the Steering NOTE: This process will be easier with warm oil. Lift the front wheels off the ground. Turn the wheel to the right extreme and continue to turn 100 complete revolutions.
  • Page 117 LUBRICATION AND MAINTENANCE Adjust Toe-In Toe-in adjustments should be made at the ram end of the steering cylinder. Loosen the nut and bolt on the tie rod clamp (1). Use a wrench on the end of the ram (2) to increase (counter- clockwise) or decrease (clockwise) toe-in.
  • Page 118 LUBRICATION AND MAINTENANCE Winterize Wet System The product tank and wet system must be flushed before winterizing. See “Flushing Product Tank” on page 4-17. Open the product tank fill valve, rinse tank valve, and ro- to-flush valve to drain any remaining water in the tanks and roto-flush line.
  • Page 119 LUBRICATION AND MAINTENANCE Winterize Wet System (continued) Repeatedly open and close the sump valve (1) and rinse tank/ product valve (2), to allow the antifreeze to surround the ball valves. Close the rinse tank valve (3) and open the sump valve (4). Except for one nozzle at the end of each boom section, turn off all the nozzle bodies.
  • Page 120 LUBRICATION AND MAINTENANCE Every 1000 Hours or Yearly The following services must be performed after every 1000 hours of operation or yearly. Change Hydraulic Fluid The hydraulic fluid drain plug (2) is located on the hydraulic fluid reservoir, between the cab and the product tank. Remove the hydraulic fluid drain plug (2) from the bottom of the reservoir and drain the fluid into a suitable container with a capacity of more than 40 gallons [151.42 liters].
  • Page 121 LUBRICATION AND MAINTENANCE Lift the unit out of the tank and remove the suction screen retaining screw (1) from the foot of the suction tube. Remove the screen and replace it with a new one. • DEF Suction Strainer Part Number: 241000008 Place the DEF level/temperature unit back into the tank and orient the hose barbs as they were originally.
  • Page 122 LUBRICATION AND MAINTENANCE NOTES 5-40 AS740 Operator’s Manual...
  • Page 123 Chapter 6 TORQUE VALUE CHARTS Fittings ALWAYS tighten fittings to the values below unless a different torque value is specified. Make sure fitting threads are clean and threads are engaged properly. All torque values are adopted from SAE J514 and SAE J1453. Size Chart SAE Dash Size...
  • Page 124 TORQUE VALUE CHARTS Torque Value Chart TORQUE SAE Dash SAE 37° Flare O-ring Straight Thread Face Seal Size lb-ft N•m lb-ft N•m lb-ft N•m ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- ---- Bolts ALWAYS tighten fittings to the values below unless a different torque value is specified. Fasteners must ALWAYS be replaced with the same grade.
  • Page 125 TORQUE VALUE CHARTS Metric Series Torque Value Chart Metric Metric Metric Metric Grade 8.8 Grade 10.9 Grade 8.8 Grade 10.9 Course Thread Fine Thread Diameter and Diameter and Wrench Metric 8.8 Metric 10.9 Metric 8.8 Metric 10.9 Thread Pitch Thread Pitch size N•m lb-ft...
  • Page 126 TORQUE VALUE CHARTS NOTES AS740 Operator’s Manual...
  • Page 127 Chapter 7 TROUBLESHOOTING Apache Sprayer Troubleshooting Symptoms and Solutions If your issue was not resolved by using the troubleshooting guide, contact your dealer for more help. SYMPTOM SOLUTION Parking brake will not engage. Check electrical coil on hydraulic junction block, under cab, for power.
  • Page 128 TROUBLESHOOTING SYMPTOM SOLUTION Engine will not start. Confirm battery disconnect switch is “ON”. Check diesel fuel level. Check neutral safety relay. Confirm Start/Stop Engine button is “Green”. Apache Sprayer steering does not work. Check hydraulic fluid level. Check for hydraulic fluid leaks. Check steering column coupling on steering motor.
  • Page 129 TROUBLESHOOTING SYMPTOM SOLUTION Apache Sprayer will not spray. Confirm engine is running. Confirm product in product tank. Confirm ball valves from tank to product pump are open. Confirm product pump is turned on. Check ground speed on console controller display. Confirm boom valves are opening.
  • Page 130 TROUBLESHOOTING NOTES AS740 Operator’s Manual...
  • Page 131 Chapter 8 ELECTRICAL SYSTEM Chassis Power Distribution Module RELAY # DESCRIPTION FUSE # FUSE TYPE 500A MEGA Alternator Power 80A MIDI Auxiliary Battery Post Power 250A MEGA Cab / Boom Battery Power 250A MEGA Cold Start Power 15A ATO DEF Supply Heater Power 40A ATO Starter Solenoid Power 15A ATO...
  • Page 132 ELECTRICAL Cabin Power Distribution Module RELAY # DESCRIPTION FUSE # FUSE TYPE 5A MINI Antenna Battery Power 5A MINI Relay 1 Node Logic Power 5A MINI Relay 1 ISOBUS CAN Power 5A MINI HDU Battery Power 20A MINI Relay 2 CAN Switched Power 5A MINI Relay 3...
  • Page 133 ELECTRICAL Boom Power Distribution Module RELAY # DESCRIPTION FUSE # FUSE TYPE 15A MINI Relay 1 Hawkeye Nozzle Power 15A MINI Relay 2 Hawkeye Nozzle Power 15A MINI Relay 3 Hawkeye Nozzle Power 15A MINI Relay 4 Hawkeye Nozzle Power 15A MINI Relay 5 Hawkeye Nozzle Power...
  • Page 134 ELECTRICAL NOTES AS740 Operator’s Manual...
  • Page 135 APACHE SPRAYER LIMITED WARRANTY POLICY Equipment Technologies (hereinafter called ET) warrants each new Apache Sprayer to be free from defects in materials and workmanship for a period of five (5) years or two thousand (2000) hours, whichever occurs first, from the warranty start date, with the exclusions listed herein. Under no...
  • Page 136 WARRANT Y There is no warranty on glass, parking brake pads or discs, brake linings, filters, oils, product pump seals, product pump bearings, rubber product hoses, pressure gauges or ground engaging accesso- ries such as auto boom wheels and related bearings, shocks, or springs. Components, systems, or accessories that are installed by the dealer and were not installed by ET when the machine was originally manufactured are not covered by this warranty.
  • Page 137 WARRANT Y (30) calendar days of the issue of an automatically or manually generated RMA. Parts must be re- turned through the authorized selling dealer, transportation charges prepaid. All returned parts must be clean from all chemicals and/or oils. ET’s obligation under this limited warranty is in lieu of all other warranties or representations, expressed or implied, and specifically excludes any obligations or liability for loss of crops, losses caused by harvest delays or any expense or loss of labor, supplies, rental equipment, and all inci- dental or consequential damages.
  • Page 138 WARRANT Y NOTES AS740 Operator’s Manual...
  • Page 139 Chapter 10 MAINTENANCE LOG ____________________ Season Check and inspect each of the following items on your Apache Sprayer. Put the date on the line next to each item as it is completed. Check front suspension cylinders for leaks around the seal and oil level in cylinder. Grease the front axle assembly including all king-pins and center pivot pin.
  • Page 140 MAINTENANCE LOG Inspect booms for cracks, breaks, and worn hinge points. Inspect boom plumbing for worn hoses and bad nozzles. Inspect all hydraulic hoses for rubs, worn spots, and leaks. Inspect all hydraulic cylinders for leaks and proper operation. Inspect wiring harnesses for rub points. Inspect foam marker components for leaks and operation (if equipped).
  • Page 141 MAINTENANCE LOG ____________________ Season Check and inspect each of the following items on your Apache Sprayer. Put the date on the line next to each item as it is completed. Check front suspension cylinders for leaks around the seal and oil level in cylinder. Grease the front axle assembly including all king-pins, ball joints, and center pivot pin.
  • Page 142 MAINTENANCE LOG Inspect wiring harnesses for rub points. Inspect foam marker components for leaks and operation (if equipped). Verify Raven controller calibrations: Flow Meter Boom Sections Control Valve Speed Cal Check A/C operation. Inspect frame for cracks and loose bolts. Inspect Tee Jet valves for operation and wear.
  • Page 143 MAINTENANCE LOG ____________________ Season Check and inspect each of the following items on your Apache Sprayer. Put the date on the line next to each item as it is completed. Check front suspension cylinders for leaks around the seal and oil level in cylinder. Grease the front axle assembly including all king-pins and center pivot pin.
  • Page 144 MAINTENANCE LOG Inspect wiring harnesses for rub points. Inspect foam marker components for leaks and operation (if equipped). Verify Raven controller calibrations: Flow Meter Boom Sections Control Valve Speed Cal Check A/C operation. Inspect frame for cracks and loose bolts. Inspect Tee Jet valves for operation and wear.
  • Page 145 MAINTENANCE LOG ____________________ Season Check and inspect each of the following items on your Apache Sprayer. Put the date on the line next to each item as it is completed. Check front suspension cylinders for leaks around the seal and oil level in cylinder. Grease the front axle assembly including all king-pins and center pivot pin.
  • Page 146 MAINTENANCE LOG Inspect wiring harnesses for rub points. Inspect foam marker components for leaks and operation (if equipped). Verify Raven controller calibrations: Flow Meter Boom Sections Control Valve Speed Cal Check A/C operation. Inspect frame for cracks and loose bolts. Inspect Tee Jet valves for operation and wear.
  • Page 148 WWW.ETSPRAYERS.COM...

Table of Contents
