UTAH SCIENTIFIC SC-4 Set Up And Operation Manual

Routing and control system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SC-4 Routing and Control System
System Setup and Operations Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-4 and is the answer not in the manual?

Questions and answers

Related Manuals for UTAH SCIENTIFIC SC-4

Summary of Contents for UTAH SCIENTIFIC SC-4

  • Page 1 SC-4 Routing and Control System System Setup and Operations Guide...

  • Page 2: Copyrights And Trademarks

    Information contained in this guide is subject to change without notice or obligation. While every effort has been made to ensure that the information is accurate as of the publication date, Utah Scientific, Inc. assumes no liability for errors or omissions. In addition, Utah Scientific, Inc. assumes no responsibility for damages resulting from the use of this guide.

  • Page 3: Declaration Of Conformity

    Following the provisions of the Directive(s) of the Council of the European Union: EMC Directive 89/336/EED • Low Voltage Electrical Directive 72/23/EEC • Utah Scientific, Inc. hereby declares that the product specified above conforms to the above Directive(s) and Standard(s). Setup and Operations Guide...

  • Page 4: Important Safeguards And Notices

    Route power cords and other cables so they won’t be damaged. • The AC receptacle (socket) should be located near the equipment and be easily • accessible. Disconnect power before cleaning. Do not use any liquid or aerosol cleaner - • use only a damp cloth. SC-4...
  • Page 5 Dangerous voltages exist at several points in this product. To avoid personal • injury, do not touch exposed conductors and components while power is on. Do not insert anything into either of the systems two-power supply cavities with power connected. Do not wear hand jewelry or watches when troubleshooting high current cir- •...

  • Page 6: Company Information

    Company Information Utah Scientific, Incorporated 4750 Wiley Post Way, Suite 150 Salt Lake City, Utah 84116-2878 U.S.A. Telephone: +1 (801) 575-8801 • FAX: +1 (801) 537-3098 • Technical Services (voice): +1 (800) 447-7204 • Technical Services (FAX): +1 (801) 537-3069 •...

  • Page 7: Warranty Policies

    Warranty Policies Hardware Warranty Utah Scientific, Inc. warrants to the original purchaser that the Utah Scientific hardware is free from defects in materials and workmanship and will perform substantially in accordance with the accompanying written materials under normal use and service for a period of ten (10) years from the date of shipment.
  • Page 8 No liability for consequential damages. To the maximum extent permitted by applicable law, in no event shall Utah Scientific or its suppliers be liable for any damages whatsoever (including without limitation, damages for loss of business profits, business interruption, loss...

  • Page 9: Table Of Contents

    System Hardware Requirements ....... 1-4 Hardware Features ............ 1-5 Front Cover Features ............. 1-5 SC-4 Chassis Front View with Front Cover Removed ..1-6 SC- 4 Control System Backplane ........1-7 CHAPTER 2 Hardware Installation In this Chapter ..............2-1 Unpacking and Inspection ..........
  • Page 10 ....3-7 Power Supply LED’s ............3-7 System LED’s ............3-9 The SC-4 Monitor Display Operation ......3-11 Features and Functions of the SC-4 Monitor Display ..3-11 Monitor Display Formats ..........3-12 The SC-4 Power - Supply and Connections ....3-18 Voltage Alarms ..............3-19...
  • Page 11 SC-4 Routing and Control Customizing Guide The SMPTE and Remote Alarms ....... 3-21 Alarm Port Pin-Outs ............3-22 Serial Port Pinouts ............3-22 CHAPTER 4 Operations In this Chapter ..............4-1 SC4 Operations ............4-2 The Debug Port .............. 4-2 Physical Connection ............
  • Page 12 Table of Contents...
  • Page 13 SC-4 Control Board Components – Front View ..........3-3 SC-4 Control Board – Top View ..............3-6 SW3 Identification – Viewed from the Top Rear of the SC-4 ......3-10 Monitor Display Features ................3-11 Time Display Edit Parameters ................ 3-14 Date Display Edit Parameters ................
  • Page 14 Chapter 4 Chassis terminal display ................. 4-7 Appendix B PAL Sync ......................B-2 Line Switching ....................B-4 SC-4 Routing and Control System...

  • Page 15: Introduction

    Includes some “do’s” and “don’ts” regarding the installation. Chapter 3 “System Configuration” provides information the user needs • to know when setting up or changing the SC-4 Control Boards. Chapter 4 “Operations” offers a detailed description of connections, •...

  • Page 16: Chapter Contents

    Introduction Chapter Contents How to use this Guide ............1-3 Hardware Features ............. 1-5 Front Cover Features ............1-5 SC-4 Chassis Front View with Front Cover Removed ..1-6 SC- 4 Control System Backplane ........1-7 Introduction...

  • Page 17: How To Use This Guide

    The chapter on “System Configuration” relates directly to the SC-4 Control Card(s) and • what can be configured on them. “Operations” describes operational commands that can be sent to the SC-4 via Telnet or • the system debug port. This section also describes various status messages available at the debug port.

  • Page 18: System Hardware Requirements

    Introduction System Hardware Requirements Item Minimum Recommended Processor Intel Pentium II Intel Pentium IV Operating System Windows 2000 Windoes XP Memory 128 MB Ram 512 MB Ram Hard Disk 384 MB Free Space Including Swap File Monitor 17” 1024x768 Color Monitor Video Card 1024x768 capable, 8 MB of...

  • Page 19: Hardware Features

    Power Supply Light Pipe Clear Display Lens Power Supply Light Pipe SC-4 Front Panel Components FIGURE 1-1. Figure 1-1 shows the components of the SC-4 Front Panel. The function of each component is explained in the Table below. SC-4 Control System...

  • Page 20: Chassis Front View With Front Cover Removed

    SC-4 Chassis Front View with Front Cover Removed With the front cover removed the following components are visible from the front: • The SC-4 Control Boards (Normally shipped with two control boards). • Two Power Supplies. • One Chassis Monitoring (Display) Module.

  • Page 21: Control System Backplane

    Control Boards Provides Control and Configuration SC- 4 Control System Backplane The SC-4 Backplane provides all of the connections necessary to control Utah Scientific equipment. • The SC-4 backplane is arranged into the following groups of connectors: • Eight RJ-45 UNET Connectors •...
  • Page 22 Introduction Backplane Connections and Functions TABLE 1-3. Port Function AC Plug Connection for the AC Line Power Cord(s). Party Line Use with CSP Panels or Party Line controlled devices. UNET For use with UNET based control panels. Ethernet Standard Ethernet Ports. GPIO General Purpose Relay / Optos.

  • Page 23: Hardware Installation

    Setting the Correct Time and Date ..........2-20 Proper Hot Swappable Removal of SC4 Cards ......2-21 Changing Serial Port Settings ............ 2-22 Ethernet LEDs ................2-22 System LEDs ................2-23 Sync LEDs ................. 2-23 Power Supply LEDs ..............2-23 SC-4 - Installation and Operations...

  • Page 24: Unpacking And Inspection

    When the SC-4 Control System is shipped with control panels or other systems in the same carton it will be in a 25” x 25” x 29” carton and layered with the SC-4 on the bot- tom, other systems or control panels in the second layer and accessories on top. See Figure 1-2: SC-4 Expanded Packaging and Contents.

  • Page 25: Expanded Packaging And Contents

    25" x 25" x 13" Cardboard Box Styrofoam Lid Accessories SC-4 Control System Chassis Inner Styrofoam Packing SC-4 Basic Packaging and Contents FIGURE 2-1. 25" x 25" x 29" Cardboard Box Styrofoam Lid Accessories Other System Chassis, Control Panels; Etc.

  • Page 26: Warnings And Cautions

    The power socket should be located near the equipment and easily accessible in case of an emergency. Potentially lethal AC voltages are present when the SC-4 AC System is powered up. This equipment should be operated and maintained by technically qualified personnel.

  • Page 27: Claims Against The Carrier

    In some cases it may be useful to take pictures of the damage to present to the carrier if a claim must be made. As the SC-4 is unpacked for installation, carefully check for any internal damage. Exam- ine the frame and contents carefully as rough handling may dislodge cards and/or power supplies and cause internal damages not readily noticeable until the equipment is pow- ered up.

  • Page 28: Installing Hardware

    The U-NET is a panel control bus that interfaces UCP or SCP series control panels to the • SC-4. Each U-NET port can support up to 32 panels at 1000 feet of cable. Panels can be placed on any one of the U-NET ports without regard to station number, although every panel must have a unique station number.

  • Page 29: Connecting The Serial Port

    • mination it will cause erratic responses to control signals. Unused UNET Ports on the back of the SC-4 must be terminated. Those ports, which are • daisy chained to SCP or UCP panels, must be terminated at the end of the daisy chain.

  • Page 30: Connecting Power - Ac Systems

    (Furnished by Utah Scientific). Connecting Power - AC Systems There are two six foot IEC / 18 Gauge power cords furnished with the SC-4 Control System. The power cords connect into the two IEC plugs located on each side of the chassis’...

  • Page 31: Control System Ac Power Connections

    Installing Hardware Repeat steps 1 and 2 for any additional control systems. DB-9S (FEMALE) CONTROL PARTY LINE DB-9S (FEMALE) DB-9S (FEMALE) SYNC 1 DB-9S (FEMALE) Source Source SC-4 Control System AC Power Connections FIGURE 2-3. SC-4 Guide...

  • Page 32: Dc Power Connectivity

    • Strip 1/4” of the insulation from the new wires. • Insert wire, then turn screw clockwise to tighten Use 12 AWG wire (maximum) The maximum branch circuit protection rating for the circuit feeding the SC-4 is 2 Amps 2-10 Hardware Installation...

  • Page 33: Cable Considerations

    This section provides some guidelines regarding those cables. Cables that may be ordered from Utah Scientific The SC-4 Control System is not normally shipped with any control cables; these are usually shipped with the Utah Scientific routing systems.

  • Page 34: Setup And Operations

    Hardware Installation SC-4 Setup and Operations Overview This section will assist you with configuration and setup for any SC-4 within your facility. Inventory instructions and visual sequences are provided throughout the following steps where necessary. Please contact Utah Scientific Customer Service if you have additional questions.

  • Page 35: Connecting All Pieces To Sc4 Chassis

    (8) UNET terminators (RJ45) f. (2) MX-Bus Terminators g. (1) System CD (containing SC-4 manual and rMan software) h. (1) RJ45 to 9 pin adapter labeled SC4/2020 3. Find the best location to install the chassis that will accommodate the various connections which include –...
  • Page 36 Hardware Installation the dual ports on the MX-bus equipment. Then from that chassis 2nd port, another cable will run from there to the next piece of MX-Bus equipment. Continue this looping topology until the final frame is attached. You must then attach one of the two MX-Bus terminators to the open port on the SC4 chassis and the other terminator to the open port on the final frame closing the MX-Bus loop.
  • Page 37 SC-4 Setup and Operations Option 1 View Option 2 is a star topology and requires the use of an optional UNET hub (DA). Attach one of the UNET ports on the SC4 to the 1st port on the hub and run the remaining ports of the hub to each control panel in that loop.
  • Page 38 There are three Sync ports on the rear of the SC4 chassis. As a default, the SC-4 uses sync 1 for vertical interval switching. The sync ports should be fed with analog black burst signals, either NTSC, PAL, or Tri- Level.
  • Page 39 SC-4 Setup and Operations 5. Party Line Port connections a. There are 4 individual Party Line ports. There can be up to 128 panels installed overall across the 4 ports. b. Attach coax cable to any of the 4 ports and connect to desired panel using either of the two ports on the control panel.

  • Page 40: Applying Power To Sc4 Chassis

    Hardware Installation Applying Power to SC4 Chassis 1. Plug both AC cords in and verify that the power supplies and SC4 cards power up correctly. 2. The power supplies should come on with only green LED’s on. 3. One of the SC4 cards will come up as the active card and should have the power, SYNC and Ethernet 1 green LED’s on.

  • Page 41: Changing The Chassis Id

    5. To check the current chassis ID, type chassis (space)-r and hit the return key. (This chassis ID is the name that is found in U-CON for the SC-4 icon). To change the chassis ID, type chassis (space)-chid(space)new name. (This name can contain underscores and hyphens, as long as there are no spaces.)

  • Page 42: Setting The Correct Time And Date

    Hardware Installation Setting the Correct Time and Date Note: Any date and time set must be completed for both cards in a two card system. Follow this procedure - including ‘Proper Reset’ and ‘Proper Changeover’ whenever the time and date are set. Note also that this setting is independent of your house clock.

  • Page 43: Proper Hot Swappable Removal Of Sc4 Cards

    SC-4 Setup and Operations Proper Changeover To change over from the active card to the back up card, simply push the change over button on the active card (the inside button). The change over button does not function when pushed on the back-up card.

  • Page 44: Changing Serial Port Settings

    Step 5 - Scroll to the bottom of the file and make the desired changes to the serial ports. Note: When editing this file it is imperative that all spaces and commas remain as they are seen. FAilure to do so will cause the SC-4 to not function properly. Step 6 - Save changes and exit the file.
  • Page 45 SC-4 Setup and Operations Burn Encode - screen 2 FIGURE 2-5. Burn Encode - screen 3 FIGURE 2-6. 2-23 SC-4 Guide...
  • Page 46 SC-4 cards have been reset. Step 8 - Press and hold the reset button on both SC-4 cards at the same time and release the reset button on the active card first, followed by the backup card. (The ‘active’ LED will be illuminated on the card that is in use.)

  • Page 47: Ethernet Leds

    SC-4 Setup and Operations Ethernet LEDs ENET #1 (Network Interface #1) Link = should be green when attached to a network. Activity = should flicker amber with activity on the network. ENET #2 (Network Interface #2) Link = should be green when attached to a network. Activity = should flicker amber with activity on the network.
  • Page 48 Hardware Installation 1.8v FAIL = If the 1.8 volt supply drops below 1.8 volts, this LED will turn red. 12v FAIL = If the 12 volt supply drops below 12 volts, this LED will turn red. 3.3v FAIL = If the 3.3 volt supply drops below 3.3 volts, this LED will turn red. POWER OK = If all of the voltages are good, this LED will remain green.

  • Page 49: System Configuration

    Power Supply LED’s ..............3-7 System LED’s ..............3-9 The SC-4 Monitor Display Operation ......3-11 Features and Functions of the SC-4 Monitor Display ....3-11 Monitor Display Formats ............3-12 The SC-4 Power - Supply and Connections ....3-18 Voltage Alarms ................

  • Page 50: Control Board System Operation

    System Configuration SC-4 Control Board System Operation The SC-4 Control System is designed so it may operate with one control board or in the redun- dant mode, with two control boards. Utah Scientific always recommends having the system configured as a redundant system in case of board failure during system operation.

  • Page 51: The Sc-4 Control Board

    Chgovr Switch Reset Switch Left Board Extracter Right Board Extracter SC-4 Control Board Components – Front View FIGURE 3-1. SC-4 Front View Components and Functions The following table describes the components of the front view: SC-4 Control Board Front View Component Functions TABLE 3-1.

  • Page 52: The Sc-4 Control Board Hardware Settings

    2. Quickly remove the SC-4 Control Board from the chassis. The SC-4 Control Board Hardware Settings The following hardware changes must be made with the SC-4 Control Board removed from the chassis. If your system does not have redundant controllers these changes should be made during equipment maintenance downtime.

  • Page 53: Hardware Changes On The Sc-4 Control Board

    Note: When making hardware changes on one SC-4 Control Board, be sure that the same changes are made on the other (redundant) SC-4 Control Board. The changes that can be made on the SC-4 Control Board include the following: Serial Ports – Each Serial Port gang-jumper must be physically moved from the RS-232 (factory default) position to the RS-422 position.

  • Page 54: Control Board - Top View

    - All Switches "OFF" SDRAM Board RJ - 45 Debug Port ENET #1 ENET #2 System Sync Power Supply Error and Status LED's 3 Volt Lithium Battery Chgover Switch Reset Switch SC-4 Control Board – Top View FIGURE 3-2. System Configuration...

  • Page 55: Control Board Error And Status Led's

    SC-4 Control Board Error and Status LED’s SC-4 Control Board Error and Status LED’s The error and status LED’s are located on the very front of the SC-4 Control Board, directly below the SD-Ram board. These LED’s are not viewable with the front cover installed.
  • Page 56 On - +5 Volt DC Failure * If the system indicates a battery failure, observe the precautions on Page 3-4 before removing the board and checking or replacing the battery. Replacement batteries can be ordered through Utah Scientific Technical Services at 1.800.447.7204. System Configuration...

  • Page 57: System Led's

    TABLE 3-3. Color Status Indication Ready Green Off = SC-4 not in sync with partner card On = Active and redundant boards are in sync and configuration data is being updated PS-2 Fail Off = No Fault On = Left hand power supply failure...
  • Page 58 SC-4 Control Board. Currently there are no user-defined functions for SW3. All of the switches will be in the “OFF” position on all controllers in the SC-4 Control Systems currently being shipped from the factory.

  • Page 59: The Sc-4 Monitor Display Operation

    “Changing IP address for SC4 chassis” on page 2-18 for the preferred process. The SC-4 Monitor Display is located on the front - bottom center of the SC-4 Chassis. The clear plastic lens on the front cover allows the user to view the selected status with the cover Currently the only displays available are Time, Date, the Name assigned the SC-4 Chassis and the Network Setup Menu.

  • Page 60: Monitor Display Formats

    System Configuration Pressing and holding the button in momentarily activates the “Save” prompt for the display being edited. a. Press the Scroll Up button to “Save”. b. Press the Scroll Down button to ignore or not save any changes. Monitor Display Formats The formats for each display are fixed so the user can only change specific characters / num- bers in each display.
  • Page 61 The SC-4 Monitor Display Operation Character Set After you select a format to edit, Table 4 shows the character set available to you. The charac- ter set may be scrolled up or down to select the character or number you need to fill the edit- able blocks.

  • Page 62: Time Display Edit Parameters

    System Configuration Time Format: The display of the time is shown in Figure 3-5, below, indicating which characters may be edited in the display. In Time Display ONLY These Parameters can be changed Time Display Edit Parameters FIGURE 3-5. Date Display Format: The portions of the Date Display that can be edited are shown in Figure 3-6 below.

  • Page 63: Network Setup Menu Display

    The SC-4 Monitor Display Operation Network Setup Menu To enter into the Network Setup Menu first scroll down to the Network Setup Menu Display. It will appear as shown in Figure 3-8. This display cannot be edited. Network Setup Menu Display FIGURE 3-8.

  • Page 64: Submenu-3; Broadcast 1 Address

    System Configuration The Brdcast 1 Submenu items that can be changed are shown in Figure 3-11: In Network Setup Submenu - 3: ONLY These Parameters can be changed Submenu-3; Broadcast 1 Address FIGURE 3-11. The ROUTEIP 1 Submenu items that can be changed are shown in Figure 3-12: In Network Setup Submenu - 4: ONLY These Parameters can be changed Submenu-4: Route IP Address 1 Address FIGURE 3-12.

  • Page 65: End Display Of Network Setup Menu

    Note: Each network address is applied to the chassis backplane, the Date and Time is loaded into the SC-4 Control Board. When Date and Time are changed it must be changed on both control boards. Back to Main Menu: Once all of the Network Setup Screens have been scrolled through and edited, the Back to Main Menu Screen appears.

  • Page 66: The Sc-4 Power - Supply And Connections

    Utah Scientific recommends redundant supplies as standard because redundant supplies share the load equally, which increases the total serviceable life of each supply. Figure 16, Figure 17 and Table 5 identify and explain the features of the SC-4 Power Supply as viewed from the Front.

  • Page 67: Voltage Alarms

    The SC-4 Power - Supply and Connections Voltage Alarms Any voltage failures on the SC-4 Power Supply are also detected on the SC-4 Control Boards. For example, a 5 Volt DC failure occurring on the right hand power supply would cause the PS-1 Fail and SMPTE Alarm LED’s to turn on the control board.

  • Page 68: Power Supply - Top View

    System Configuration SC – 4 Power Supply – Top View When the SC-4 Power Supply is removed from the chassis you will see the components indi- cated in Figure 3-18. Note: None of the components shown are user serviceable. Contact Utah Scientific for a replacement supply if it is failing.

  • Page 69: The Smpte And Remote Alarms

    The SMPTE and Remote Alarms The SMPTE and Remote Alarms The SC-4 Control System has two SMPTE Alarm circuits and four Remote Alarm circuits. The features and/or functions of each alarm is shown in Table 6, below; the DB-9S Alarm Back- plane Connector is shown in Figure 19.

  • Page 70: Alarm Port Pin-Outs

    System Configuration Alarm Port Pin-Outs Table 3-7 shows the Alarm Port Pin-Outs for the DB-9 Connector. TABLE 3-7. Connector Pin Signal ALM0 ALM1 ALM2 ALM3 SMPTE0 SMPTE1 6, 7, 8 Serial Port Pinouts DB-9S (FEMALE on Chassis) DB-9P (MALE on Cable) TABLE 3-8.
  • Page 71 The SMPTE and Remote Alarms 3-23 SC-4 Operations Guide...
  • Page 72 System Configuration 3-24 System Configuration...

  • Page 73: In This Chapter

    Physical Connection ............4-2 Terminal Emulation software setup ........4-2 General Status ..............4-2 Specific Operations ............4-3 Shutting down the SC4 application ........4-4 Resetting the SC4 .............. 4-4 Gathering data from the onboard log ......... 4-5 SC-4 Routing and Control System...

  • Page 74: Sc4 Operations

    Any terminal emulation program such as windows Hyper terminal is useful for debug port oper- ation. Utah Scientific recommends TeraTerm, a freeware terminal emulation software package available on the internet. Serial Port parameters necessary to communicate to the SC4 are as follows: TABLE 4-1.

  • Page 75: Specific Operations

    -d – activates debug mode which displays low level interactions with the device hardware. • -r – read and display data contained in the local chassis config ROM. • -init – write a set of default values into the chassis config ROM • SC-4 User’s Guide...

  • Page 76: Shutting Down The Sc4 Application

    <ps> command followed by a kill –INT <pid> command which is the method for stopping the current SC-4 software from running. A message will tell the user whether the shutdown has been successful or not.

  • Page 77: Gathering Data From The Onboard Log

    – Displays level mapping sc4config srcs – Displays source table sc4config dsts – Displays destination table sc4config serial – Displays serial port parameters sc4config misc – Displays miscellanous parameters sc4config dstattrs – Displays router attribute status SC-4 User’s Guide...
  • Page 78 Simply double-click the rtrsave.bat file after running the NFS server, then enter the PC IP address and the SC-4 IP address as prompted. You will also be prompted to enter a filename where the current router status will be stored. You may then enter a list of destinations whose status you want to Sav.
  • Page 79 SC4 Operations chassis This utility provides various chassis commands for modifying the IP address, gateway, mask addresses, chassis ID, and viewing all settings. Chassis terminal display FIGURE 4-1. SC-4 User’s Guide...
  • Page 80 Operations Operations...

  • Page 81: Audio Attributes Notice

    4 code, which will clear all status, including attributes and tielines. Use 'sc4config dstattrs' to view the current attribute status. If you are using an earlier version of the SC-4 code (or if you only want to clear out the attribute status), complete a ‘getencode' operation, delete the attribute status, then complete a 'burnencode' operation.
  • Page 82 Audio Attributes Notice ########################################################################## # Destination Device Attribute Table # Audio attrs: 0 Normal, 1 Swap, 2 Mix, 3 MonoLeft, 4 MonoRight, 5 InvLeft, 6 InvRight, 7 MuteLeft, 8 MuteRight, 9 Mute # Dig. video attrs: 10 Rate143, 11 Rate177, 12 Rate270, 13 Rate360 # Data attrs: 0 Tributary devices, 1 Controller devices, 2 Auto devices # Note: A value of -1 means router default.
  • Page 83 The status will be cleared when you do a 'burnencode'. Caution: As you may be already aware, a reset done immediately after a burn encode (on a redundant system) will cause the slave board to take over and rewrite the status to both cards. SC-4 User’s Guide...
  • Page 84 Audio Attributes Notice Audio Attributes...

  • Page 85: System Timing Consideration

    System Timing APPENDIX B Consideration Overview This appendix addresses a timing issue that can affect certain system configurations, causing switches to occur out of sync. The following illustration contains an explanation of HD and SD line switch- ing, and in particular, where the switching should occur. Introduction...

  • Page 86: Switching Example

    System Timing Consideration Switching Example This is an example of PAL switching. It should be noted that NTSC switching follows suit. PAL Sync FIGURE B-1. Introduction...

  • Page 87: The Critical Issue

    Overview The Critical Issue The SC-4 uses an analog signal (black burst or tri-level) as reference for vertical interval switching. If single sync is used (i.e., black burst), the following should be noted: Within NTSC configurations, the system is attempting to switch on line 10 of reference, yet within HD/SD environments, the switching of HD signals should occur at line 7.
  • Page 88 System Timing Consideration Proper line switching is illustrated below: Line Switching FIGURE B-2. 1. SMPTE Form RP 168-2002 Introduction...
  • Page 89 Again the solution is to offset the timing as described so that the switch properly occurs on sync, and on the correct line. Also refer to ‘multiple sync domain’. SC-4 Control System...
  • Page 90 System Timing Consideration Introduction...
  • Page 91 Control Boards 1-7 Name Display Format 3-14 Data Bits 4-2 Network Setup Menu 3-15 Date Display Format 3-14 Network Setup Submenus 3-15 Debug Port 3-2, 4-2 Display Board 1-7 Ordering cables 2-11 Equipment installation 2-6 SC-4 Setup and Operations Guide...
  • Page 92 SC-4 Voltage Alarms 3-19 monitor display operation 3-11 power supply 3-18 SC-4 Backplane 1-7 Warning LED’s 3-9 SC-4 Control Board 3-2, 3-3 Warnings and Cautions 2-4 error and status LED’s 3-7 Watchdog 3-5 hardware changes 3-5 hardware settings 3-4 top view 3-6...
