Summary of Contents for Heliospectra helioCORE
- Page 1 Setup Manual Heliospectra Horticulture Fixtures...
-
Page 2: Table Of Contents
Heliospectra AB shall have no liability for any error or damage of any kind resulting from the use of this document. At Heliospectra AB we aim to continuously improve our product documentation. If you have comments or ideas regarding this document, please contact us at support@heliospectra.com. -
Page 3: Product Overview
4kg (8.8 lbs) Dimensions 300x200x160mm Temperature -25 ... +70 °C (operation) -40 ... +85 °C (storage) Humidty 5 … 90% no condensation Certifications UL, CE, ROHS helioCORE computer Thermostat Power supply Air outlet Power inlet 2x Ethernet ports helioCORE Setup Manual... -
Page 4: Box Installation
1m from the ground. Mounting the cabinet, please use galvanized or stainless M6-M8 screw that withstand humid environments over time. 200mm 160mm The box has prefabricated mounting holes designed for M6 screw installation. Note the dimensions in the figure above. www.heliospectra.com... -
Page 5: Power Connection
US and Europe. There is also a pigtail version for other type of plugs or connections. No connection needs to be made inside the Heliocore box, all connections are made through the quick connect connector on the outside of the box. -
Page 6: Wide Area Network (Wan) - Internet Connection
Connect helioCORE to the facility network by plugging in the ethernet cable from the facility’s network to the “WAN” port as shown below. If the helioCORE is placed in a damp location, the included sealed connector should be used to ensure a water sealed connection of the ethernet cable. -
Page 7: Local Area Network (Lan) - Light Network
(LAN) and ™ can control all lights connected to the network, independet if they are connected through cable or wifi. The light network should be connected to the helioCORE by the LAN connector shown below. helioCORE Setup Manual V. -
Page 8: Software Startup
4. Maintenance The only maintence that is needed for the helioCORE™ is to secure that the airflow throught the fan unit is sufficient. The air through the unit is filtered by a filtermat located in the upper fan unit. Secure the airflow by monitor the degree of soiling of the filter mat. If required, replace, blow out or beat the filter mat clean. -
Page 9: Support & Faq
QR code to go straight there. 6. Warrenty helioCORE carry a warranty that the hardware components will be free from defects in material and workmanship for a period of three (3) years from the date of delivery. The warranty extends only to the original Buyer of the Product and may not be transferred or assigned by the original Buyer. - Page 10 Contact Details Got questions? Or need info related to how to set up helioCORE’s user interface? Visit our Support Portal for User Manauals, articels and videos. https://support.heliospectra.com/portal/en/home Or sent our dedicated support team an email at support@heliospectra.com OUR OFFICES Sweden...
