Nodis Nowire - Cuffia Bluetooth Stereo Manual

Table of Contents

Contents

1 Safety instructions
2 Technical features
3 The Packing list
4 Understand your multifunctional headset
5 Headset Charging
6 Paired with a Bluetooth Phone
7 Switching the modes of MP3, FM, Bluetooth
8 Playing FM Radio Stations
9 Operation description
10 Multifunctional headset troubleshooting
11 The maintenance and care of the Multifunctional headset
12 Documents / Resources
- 12.1 Download manual

Safety instructions

To avoid hearing damages, please reduce listening time at high volume and set a safe volume level. An higher volume implies a lower listening time that is included in safety parameters.
Do not expose headphone in places with too high temperatures.
Do not let fall headphone.
Do not expose headphone to drops or splashes.
Avoid putting the headphone in water.
Do not use any cleaning products with alcol, ammonia, benzene or abrasive substances.
For the product cleaning, please use a damp soft cloth with little water or diluted soap.
The built in battery must not be exposed to high temperatures as sunlight, fire and so on.
If the battery does not be replaced correctly, it will cause explosions. Please, battery must be replaced with equal or equivalent one.

When you use the headphone, please observe following directions:

Listening must be at a reasonable volume and for time period not excessively long.
Please do not turn up the volume after your ear adapts.
Please do not turn up the volume to a level that it will not hear nearby sounds.
During dangerous situations please pay attention or temporarily stop listening.
An excessive sound pressure levels from headphone or earphones can cause hearing loss.
During the driving, please do not use headphone covering both ears; such use can be considered illegal in some countries.
For your safety, avoid to be distracted by listening music or making calls during the driving or in any other dangerous situations.

PLEASE, READ THIS USER MANUAL AND STORE IT FOR FUTURE USES.

Technical features

Bluetooth V3.0
Hands-free to send and receive calls
TF card to play music
FM radio
3.5mm aux to connect to mp3 players
High fidelity audio playback
40mm optiflex speaker drivers
Frequency response 20Hz - 20KHz
High sensitivity 110Db
Powerful deep bass with sharp vocals&crystal clear treble
Comfortable heat dissipating ear cushions
Handsfree talking
Make and receive calls
Convenient head mounted answer button
Wireless music streaming
A2DP support
Work up to 10M
High-end Bluetooth JL chipset
Built-in battery 300mAh
Standby time up to 300 hours
Talk time 8-10 hours
Charging time <3 hours

The Packing list

Multifunctional headset
USB charging cable
User manual

Understand your multifunctional headset

SD card slot
Multi-function keys Last song/last channel Volume up/down Automatic search channels
USB Charger port
Microphone socket
LED status indication
Play/Pause/Answer/Hang up the phone
Power switch

Headset Charging

The headset has a built-in rechargeable battery. Before first use, ensure the battery is fully charged.
Connect the charger into the charging port by USB charging cable, the charging time is approximately 2 hours.

Paired with a Bluetooth Phone

When the headset is powered on, the headset will go into the pairing mode.
Open the Bluetooth function for your phone to search (please refer to your phone user manual if it is related to mobile phone Bluetooth function) for the headset nearby and select it in the list.
Enter the password "0000", press "OK" to pair your phone and headset.
After completing the above steps, you can answer the phone or listen to music from your phone in the headset.

Switching the modes of MP3, FM, Bluetooth

Working mode: press the mode button to switch among MP3, FM and Bluetooth. If the headset is successfully paired with your phone, when a call comes in, or the phone is playing music, the headset will automatically switch to the Bluetooth mode, so as to conveniently answer the phone.

Playing FM Radio Stations

Auto search
When in FM mode you are able to listen to your local FM radio stations. To enter the FM auto search press and hold the multifunctional button. Once a station is found press the multifunctional button again to stop the auto search.

Manual search
Press and hold the previous or next buttons on the multifunctional button to manually change the FM station.

MP3 Playback
This device can play an MP3 file directly from an SD card. Insert the SD card into the slot on top of the earphone. The headset will switch to MP3 playback automatically. The headset is only capable of playing MP3 files.

Operation description

Function	Description
Play / Pause	Press the multifunctional button once
Next music	Press the forward button once
Last music	Press the back button once
Answer / Hang up	Press the multifunctional button

Multifunctional headset troubleshooting

If you can not connect the Bluetooth headset to phone, please try the following steps:
Make sure the headset is switched on.
Make sure the Bluetooth function is turned on.

Check if the distance between the headset and the phone is more than 30 feet, or if there is a wall or electronic equipments between them.
The pairing information list of Bluetooth headset may be full. The Bluetooth headset can store up to eight devices. If the pairing list is full, please re-pair the Bluetooth headset.
If the headset can't automatically reconnect to the preferred device, please re-insert the headset to the charger or reboot the headset.
If no sound check the volume level.
Check if battery is charged. Connect headset to a computer or the optional charger. If the battery is full, the red indicator on the headset will turn off.
Please check if there are music files in the SD card. Connect SD card to see if there are music files.
Please check if the SD card MP3 music files are in the correct format. MP3 player can only play MP3 format file, it currently does not support other music formats file.

The maintenance and care of the Multifunctional headset

Your MP3 Bluetooth headset is a product which has superior design, use it carefully. The following suggestions will help you protect your warranty coverage.

Keep all accessories out of the reach of small children.
Keep the Bluetooth headset dry. If Bluetooth headset is wet, ensure the headset is completely dry before use.
Store the Bluetooth headset in clean environment. Dust will damage its moving parts and electronic components.
Do not store Bluetooth headset in extreme temperatures which can shorten the life of electronic devices, damage batteries and warp or melt certain plates.
Do not drop, knock or shake the Bluetooth headset.
Do not use cleaning solvents, or strong detergents to clean the Bluetooth headset. All of the above suggestions are suitable equally for your USB cable, battery charger and other accessories. If any device is not working properly, take it to your nearest authorized service for repair.
