Summary of Contents for Heliospectra SIERA
- Page 1 SIERA User Manual Heliospectra Horticulture Fixtures...
- Page 2 Heliospectra AB shall have no liability for any error or damage resulting from the use of this document. At Heliospectra AB we aim to continuously improve our product documentation. If you have com- ments or ideas regarding this document, please contact us at support@heliospectra.com.
- Page 3 Cet appareil ne peut être entretenu que par un technicien the case of a suspected malfunction contact your expérimenté. Si vous avez un soupçon sur le mauvais distributor or Heliospectra directly. fonctionnement de celui-ci, contactez votre distributeur ou Heliospectra directement.
-
Page 4: Table Of Contents
Table of Contents Product Overview 1.1. SIERA Light Bar 1.2. SIERA Power Supply Unit Installation 2.1. Mounting 2.2. Connecting light bars to the power supply unit 2.3. Electrical installation 2.3.1 Dimming Operations 2.4. Surge protection Operation Maintenance Cleaning Technical Specification... -
Page 5: Product Overview
5. Connection ports and separate cables for serial connection NOTE! When unpacking and installing your SIERA light bars make sure to have a sturdy surface to work on. Damage can occur to the light bar if dropped. SIERA User Manual... -
Page 6: Siera Power Supply Unit
7. 0-10V dimming cable with in-line connector (not pictured) 8. SIERA light bar connection ports with protective caps NOTE! When unpacking and installing the SIERA power supply make sure to have a sturdy surface to work on. Damage can occur to the unit if dropped. www.heliospectra.com... -
Page 7: Installation
The support structure needs to be sturdy enough to support the weight of the light bars and any ad- ditional equipment. The power cord cannot be used to support the weight of the unit. Air must be able to flow freely around the SIERA light bar and power supply unit, they are cooled using passive, convection cooling. -
Page 8: Connecting Light Bars To The Power Supply Unit
SIERA power supply unit. The status LED indicator on the front of the SIERA power supply unit will change from green to red if there is an issue e.g. if you attach too many bars to the power supply, or to any of the connection ports. -
Page 9: Electrical Installation
The SIERA power supply unit is delivered with a power cable (three wires; one blue neutral, one brown live and one yellow and green ground) with an in-line connector on the end. Your electrician can use this connector to attach the power supply unit to a mains power cable in the most suitable and safest way. -
Page 10: Dimming Operations
2.3.1 Dimming Operations www.heliospectra.com... -
Page 11: Surge Protection
2.4 Surge protection Heliospectra AB requires that the fixtures are installed with adequate surge protection according to the local recommended practice. In North America IEEE 1100-2005 contains the recommended prac- tice for powering and grounding electronic equipment. In Europe the applicable standard is IEC 62305 –... -
Page 12: Operation
3. Operation The SIERA light bars are static spectrum fixtures. You can use a dimmer, attached to the signal cable on the power supply unit, to control the intensity of light emitted. The fixture can be connected to a timer, to set the photo-period which the fixtures are to be active within. - Page 13 Cooling Passive - Convection cooled Durable ABS plastic and Anodized Aluminum Housing Material Diffuser : Highly transmissive acrylic glass Luminaire Class I Equipment Hanging None - Built in T-slot Attachments Compliance CE and ROHS, cETLus SIERA User Manual V. 3,0...
-
Page 14: Technical Specification
Heat Value (BTU/h) Up to 2047 BTUs/hr Cooling Passive - Convection cooled Cable Length 2 m (6 ft 5 in) Fixed Cable Cord Attachment Type Y Attachment Plug options Open ended Housing Material Anodized Aluminum Compliance CE and ROHS, cETLus www.heliospectra.com... -
Page 15: Warranty Information
Products to the original Buyer. If the Product fails to comply with the terms of this warranty, Heliospectra, at its option, will repair and return the original unit or provide a reconditioned unit as a replacement. The warranty excludes labor and equipment required to remove and/or reinstall original or replacement parts. -
Page 16: Terms And Conditions
Buyer or anyone other than an authorized Heliospectra technician. Heliospectra shall have no liability for any claim, suit or proceeding of infringement based on (a) the use of other than the then latest release of software provided by Heliospectra, if such infringement... -
Page 17: Warranty Limitations
The Product has not been installed by a licensed electrician with adequate surge protection. For MITRA LED components: 85% or more of the light emitting diodes illuminate. Heliospectra reserves the right to make the final decision on the validity of any warranty claim. SIERA User Manual V. 3,0... -
Page 18: Warranty Claim Process
Heliospectra will arrange for retrieval of the fixture(s) from the customer location b. A failure analysis will be conducted at the Heliospectra Repair Center. If the agent at the repair center finds that the cause of the issue is attributed to one or more of the warranty... -
Page 19: Implied Or Other Warranties
6.4 Disclaimers To the full extent permitted by law, Heliospectra will not be liable to the Buyer for any loss or damage arising from the use of the Product, or any defect in the Product, however it may arise. Apart from the warranties as stated above, Heliospectra has no obligation to provide support, maintenance, upgrades, modifications or new releases. - Page 20 Contact Details Got questions? Or need info related to how to set your new SIERA? Visit our Support Portal for User Manauals, articels and videos. https://support.heliospectra.com/portal/en/home Or sent our dedicated support team an email at support@heliospectra.com OUR OFFICES Sweden Canada...
