CL-TYH Solar outdoor motion-sensor wall light
User manual
Technical specification
Model
Main features
Battery
Solar panel type
Power
Light source type
LED quantity (pcs)
CRI (Ra>):
Outdoor use
Light colour
Luminous flux
Light angle
Sensor type
Daylight sensor sensitivity
Detection range
Detection angle
Operation mode
Blocking time
Operation time
Charge time
Operating temperature
Material & colour of housing
Product size
Lifetime
Warranty
Package dimensions
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
CL-TYH-3W
Motion-sensor activated, wireless, solar outdoor light with daylight sensor
3.2 V - 1500 mA Lithium battery (solar-charged)
Monocrystalline, 5.5 V, 0.6 W
3 W
SMD 2835 white LED
24
>80
Yes, suitable for outdoor use
White 3000 K / 4000 K / 6000 K
280 lm +/- 10%
120°
PIR sensor
10 LUX
3 6 m
120°
3 operation modes
0.2 sec
≥2.6 hours
4 hours
-10°C - 40°C (25°C is the most optimal)
ABS + PC (White colour)
97 x 123 x 46 mm
50,000 hours
2 years
127 mm (L) x 50 mm (W) x 103 mm (H)
0.167 kg
1
Advertisement
Table of Contents
Summary of Contents for squarespace CL-TYH-3W
- Page 1 CL-TYH Solar outdoor motion-sensor wall light User manual Technical specification Model CL-TYH-3W Main features Motion-sensor activated, wireless, solar outdoor light with daylight sensor Battery 3.2 V - 1500 mA Lithium battery (solar-charged) Solar panel type Monocrystalline, 5.5 V, 0.6 W...
- Page 2 CL-TYH Solar outdoor motion-sensor wall light User manual Safety notices Electrical work safety advice and tips ● Keep away from inflammable and explosive materials when charging. The charging time should not exceed 12 hours. Try to avoid using while charging. ●...
- Page 3 CL-TYH Solar outdoor motion-sensor wall light User manual Product details Mounting hole Solar panel Mode button PIR sensor LED panel Sensing range Product dimensions www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 4 CL-TYH Solar outdoor motion-sensor wall light User manual Installation 1. Drill the hole for the raw plug and screw in the screw, leaving the screw head partially protruded Step 1: Drill the hole for the raw Step 2: Screw in the screw, leaving Step 3: Hang the light plug the screw head partially protruded...
- Page 5 CL-TYH Solar outdoor motion-sensor wall light User manual Application areas The CL-TYH Solar outdoor motion-sensor activated wires outdoor lights have a wide range of applications: street, courtyard, gate, balcony, garage, garden. All you need is a surface to secure the lights to. www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 6 CL-TYH Solar outdoor motion-sensor wall light User manual www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
- Page 7 CL-TYH Solar outdoor motion-sensor wall light User manual www.stellarlighting.co.uk email: info@stellarlighting.co.uk...
