Aerovent SCBD Series Instruction Manual

General Installation, Operation and Maintenance Instructions For Aerovent Products
Throughout this manual, there are a number of HAZARD WARNINGS that must be read and adhered to in order to prevent possible
personal injury and/or damage to equipment. Two signal words "WARNING" and "CAUTION" are used to indicate the severity of a hazard
and are preceded by the safety alert symbol.
WARNING
Used when serious injury or death MAY result from misuse or failure to follow specific instructions.
CAUTION
Used when minor or moderate injury or product / equipment damage MAY result from misuse or failure to follow specific instructions.
NOTICE
Indicates information considered important, but not hazard-related.
It is the responsibility of all personnel involved in installation, operation and maintenance to fully understand the
Warning and Caution procedures by which hazards are to be avoided.
Aerovent Catalog 340 provides additional information on this equipment. This catalog can be found at www.aerovent.com or by contacting
your local Aerovent sales representative.
Model SCBD
– 080A through 402A
Nomenclature
SCBD = Belt Driven Centrifugal Inline
SCDD = Direct Drive Centrifugal Inline
Square Inline
Centrifugal Fans
Model SCDD
– 080A through 165A
SCBD - 120 A HP
©2009 – 2022 Twin City Fan Companies, Ltd.
High Pressure
Design Vintage
Size
IM-167
May 2020
Model SCDD
Size 140X
