Summary of Contents for Bartscher K3600L
- Page 1 K3600L 109847...
- Page 2 Bartscher GmbH Phone: +49 5258 971-0 Franz-Kleine-Str. 28 Fax: +49 5258 971-120 Service hotline: +49 5258 971-197 D-33154 Salzkotten Germany www.bartscher.com Version: 1.0 Date of preparation: 2022-08-12 Original instruction manual...
- Page 3 Technical Data Water filter system K3600L Name: 109847 Art. No.: Material: plastic Performance level: litres / at °KH 3600 / 10 (carbonate hardness) Water connection: 3/8" Water supply temperature in °C 2 - 30 Water pressure, in bar: Dimensions (W x D x H), in mm:...
- Page 4 Intended Use The water filtration system is designed to reduce the carbonate hardness (KH) and the water dissolved solids (TDS) content of the tap water. Equipment included 1. Wall Holder (1x) 2. Filter head (1x) 3. 3/8’’ adapter for plastic hose Ø10 mm (2x) 4.
- Page 5 Colour: White Colour: steel grey • • Designed for: Designed for: – K3600L water filtration – K3600L water filtration system system • Water supply temperature: 2 °C to 30 °C • Performance level: 3600 litres / • Water connection: ¼’’...
- Page 6 Installation 1. Install a water filter system near the water connection and the machine. 2. Attach the wall holder to the desired location. 3. Hang the water filter system (water filter cartridge with the filter head screwed on) on the wall holder. 4.
- Page 7 Performance level The performance level depends on the hardness of the water (KH carbonate value). Check the water hardness in the place where the water filtration system is installed and on this basis, use the table below to determine the capacity: Water hardness (dH –...
- Page 8 Replacement of the water filter cartridge When the performance of the water filter cartridge is reached, replace it with a new one. Perform the following steps (fig. 3): 1. Close the drinking water tap. 2. Unscrew the used water filter element from the filter head. 3.
