KATU FTS500 Series Operating Instructions Manual

Integrated flow and temperature sensor

Advertisement

Quick Links

Sensor and controller
Flow
pressure
temperature
level
position
Operating instruction
Integrated flow and temperature sensor
FTS500/FTS520 series

Advertisement

loading
Need help?

Need help?

Do you have a question about the FTS500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for KATU FTS500 Series

  • Page 1 Sensor and controller Flow pressure temperature level position Operating instruction Integrated flow and temperature sensor FTS500/FTS520 series...
  • Page 2: Safety Instruction

    Safety instruction Safety instructions are intended to protect users from dangerous situations and/ or prevent material damage.In the operating instructions, the severity of the potential risk can be indicated by the following signal words: danger An imminent danger to the user. Failure to comply may result in fatal injury. warning An identifiable hazard.
  • Page 3: Technical Parameter

    Technical parameter ◇ Cardiac flow range: liquid: 0.4-350 L/min, depending on the pipe size. For details about the standard traffic, see the traffic range table. Gas: Calculated according to specific application ◇ Temperature range: 0~100℃ ◇ Accuracy: < ±3.0%F.S (flow rate), < ±1.0℃ (temperature) ◇...
  • Page 4: Panel Diagram

    Panel diagram FTS500 Liquid crystal display Signal alarm lamp Signal alarm lamp Flow unit Flow: L/min Instantaneous flow value Real-time temperature value TEMP: 30.8 ℃ left/reduce key right/increment key Enter/Exit/confirm key FTS500/FTS520 No display Power indicator light Flow indicator www.katusensor.com...
  • Page 5 FTS500 Dimensional drawing 67.5 41.5 M12*1 Aviation plug 15.0 50.0 15.0 R Thread tolerance to Gauge datum 4-M4 Depth of teeth 10.0 32.0 Process Mounting Overall Body range Selection height connection hole height code E ( m m ) L ( m m ) L / m in H ( m m ) ( G )
  • Page 6 FTS520 Dimensional drawing shell joint flow process Type Install Hole position ontology height Lock bit height hexagon range connection selection code L/min (A) (B) (C) (H) (L) (E) (ES) (R/G) 004A 30*30m 25mm 15mm 24mm 80mm 17mm 27mm 0.5-4 004B 016A 30*30m 25mm...
  • Page 7 FTS500 Wiring diagram Liquid crystal display brown blue Power supply + Power supply - grey Flow analog green yellow Temperature analog Temperature switch pink white Flow switch PNP+(4-20mA) NPN+(4-20mA) 24VDC + 24VDC + brown brown F mA grey white T mA green yellow pink...
  • Page 8 FTS520 Wiring diagram Analog quantity 4-20mA 18-28VDC brown Power supply + brown T mA(temperature) black Temperature analog quantity black blue Power supply - blue white Flow analog white F mA(flow) install Safety instructions are intended to protect users from dangerous situations and/or prevent material damage.
  • Page 9 Piping method: When piping a product, use a wrench to pipe the metal parts (pipe fittings) that are integrated with the piping part. If you use a wrench in other parts, the flow switch may be damaged. In particular, no spanner can be used on the M12 connector. Otherwise, the connector may be damaged Attentional collision Fixed wrench...
  • Page 10 DN is the gauge gauge unit:mm Sensor upstream Length of front and rear straight pipe section pipeline type Concentric contraction Fully open valve 15DN A 90-degree bend 20DN Two on the same plane A 90-degree bend 25DN www.katusensor.com...
  • Page 11 Two different planes A 90-degree bend 40DN Concentric expansion 30DN Regulating valve Half open Valve (not recommended) 50DN www.katusensor.com...
  • Page 12 Debugging/operation The pressure switch can only be debugged and operated by authorized personnel. caution Do not put the switch into operation when the switch itself or the connecting cable is damaged. Do not use any sharp, hard objects to make entries. The key may be damaged by something sharp and hard.
  • Page 13 Display menu Flow: L/min In the parameter display state, press Key to enter the TEMP: 30.8 ℃ setting state Just press the Add button Modify channel 0001 unit set L/min Just press the increase or decrease key ,Modify the units, L/min,m³/h,m/s clear volume 0.000 Click the Add key...
  • Page 14 K1 control Flow channel BClick the Add key , or Decrease ,Change K1 control channel, Flow, and temperature Change K1 control channel, Flow, and temperature K1 SET Click the Add key , or Decrease key Set K1 alarm value Set K1 alarm value K1 RESET Click the Add key , or...
  • Page 15 K2 control temperature channel Click the Add key , or Decrease Change the K2 control channel, Flow, and temperature K2 SET Click the Add key , or Decrease key Set the K2 alarm value K2 RESET Click the Add key , or Decrease key ,Set the K2...
  • Page 16 low clearance L/min Click Add key , or decrease , Clear the low traffic value Flow: L/min Switch set value, the setting TEMP: 30.8 ℃ www.katusensor.com...
  • Page 17: Maintenance & Cleaning

    Maintenance/cleaning The pressure switch does not require maintenance. warning Periodically check whether the switch is working properly. If the switch does not work properly, stop the operation immediately. caution Use of improper cleaning agent may damage the switch. The following cleaning agents can be used to clean polycarbonate: mild soap or detergent Isopropyl alcohol Immediately after cleaning, rinse with water.
  • Page 18 Katu Electronic (Kunshan)Co.,Ltd. The phone number is 400-150-8815 Website: www.katusensor.com Factory: No.1120 Jinyang East Road, Kunshan City, Suzhou City...
