Summary of Contents for LIVICOM Livi Smart Hub
-
Page 2: Table Of Contents
Contents 1 Hub description ..........................3 1.1 Hub description ........................3 1.2 Differences between Livi Smart Hub 4G, Livi Smart Hub and Livi Smart Hub 2G ......3 1.3 Hub appearance ........................4 1.4 Specifications ......................... 5 1.5 Supply set ..........................6 1.6 Packaging.......................... -
Page 3: Hub Description
Livi Water Control water leakage protection unit. Endpoint Livi radio devices. One Livi Smart Hub can be bound up to 64 endpoint devices, such as Livi Relay, Livi Relay 12/24, Livi Socket, Livi Siren and Livi Roller Shutter unit. ... -
Page 4: Hub Appearance
Battery life: Battery will supply power to the hub in case of a power failure at the site. Livi Smart Hub 4G can operate on battery power for up to 11 hours, Livi Smart Hub can continue to operate on battery power for at least 12 hours and Livi Smart Hub 2G will operate for at least 15 hours. -
Page 5: Specifications
Livi Smart Hub 4G / Livi Smart Hub / Livi Smart Hub 2G Manual 1.4 SPECIFICATIONS Table 1.1 – Specifications LIVI SMART HUB 4G Ethernet 10/100 Mbps First communication channel Livi Smart Hub/Livi Smart Hub 2G Ethernet 10 Mbps LIVI SMART HUB 4G 2G –... -
Page 6: Supply Set
The hub requires connection to the mains (230 V AC network) through the supplied power adaptor and stable Internet access through a wired connection (Ethernet channel – see 4.1), wireless connection (Wi- Fi channel for Livi Smart Hub 4G – see 4.2) and / or through a mobile network (GSM/UMTS/LTE channel – see 4.3). -
Page 7: Setting Up Communication Channels
6. Sign up and then sign in to the Livicom system. 7. Follow on-screen instructions to register the hub and create your livicom site. You can bind sensors and endpoint devices to the hub once your Livicom site is created. Invite family members to control the Livicom smart home together. -
Page 8: Connecting Wi-Fi Channel
Attention The command will be accepted from any phone number if the hub has no registration on the Livicom cloud server (for example, if the hub is new). If the hub is registered on the Livicom cloud server, then the command will be accepted by the hub only if it's been sent from the phone of its site's owner. - Page 9 If you have selected a SIM card from another operator, then install it into the hub and check whether the hub succeeded to connect to the Livicom server via mobile Internet. To check, disconnect Ethernet-cable from the hub, wait several minutes and look at the connection indicator (3). Mobile Internet is automatically activated if the connection indicator lights yellow.
-
Page 10: User Notification Algorithm Via Voice Calls And Sms
The command will be accepted from any phone number if the hub has no registration on the Livicom cloud server (for example, if the hub is new). If the hub is registered on the Livicom cloud server, then the command will be accepted by the hub only if it's been sent from the phone of its site's owner. -
Page 11: Intended Usage Of The Hub
If the Ethernet channel is connected to the hub, the hub sends alarm alerts and other notifications through it to the Livicom cloud platform. The hub will also use Ethernet to send test events to the platform every 10 seconds in order to monitor the state of the Ethernet connection. -
Page 12: Operation Via Wi-Fi
Livicom mobile app. If a security service is connected to the Site in the Livicom app and the connection between the hub and the STEMAX server is lost, then in five minutes the hub will generate the "Loss of connection with the monitoring station"... -
Page 13: Led Indication
Livi Smart Hub 4G / Livi Smart Hub / Livi Smart Hub 2G Manual 5.7 LED INDICATION Table 5.1 — LED Indication Power indicator Main power supply 230 V is ok, battery is ok The indicator lights green (hub receives power from the 230 V mains) -
Page 14: Hub Control
If you have divided devices into groups in the Livicom app, you can enable both full guard and the guard of a specific group using the voice menu. In this case, press the buttons 1, 1, 1 and * to enable the full... -
Page 15: Sms-Commands
Manual If you have divided devices into groups in the Livicom app, you can disable both full guard and the guard of a specific group using the voice menu. In this case, press the buttons 1, 2, 1 and * to disable... -
Page 16: Maintenance And Repairs
Livi Smart Hub 4G / Livi Smart Hub / Livi Smart Hub 2G Manual Table 6.1 — SMS-command codes SMS-reply from the hub Code Command description (example) Turning on the Livi endpoint device. You can find the serial number of the device 26 device serial on its enclosure. -
Page 17: Updating The Hub Firmware
You can update the hub firmware in the Livicom mobile app on the hub settings screen. Updating the hub firmware is described on the website of the Livicom system. -
Page 18: Disposal
Livi Smart Hub 4G / Livi Smart Hub / Livi Smart Hub 2G Manual DISPOSAL Disposal of all parts of the hub must be carried out in accordance with the local legislation. Please note that the device belongs to the 4th waste hazard class when disposing (with the exception of the battery). -
Page 19: Appendix A - Event Generation Periods
Livicom cloud server* restored * If the connection is lost between the hub and the Livicom cloud server, all generated events are queued by the hub for sending. The hub will send all accumulated events after the connection is restored. -
Page 20: Appendix C - Document Change Log
Livi Smart Hub 4G / Livi Smart Hub / Livi Smart Hub 2G Manual APPENDIX C - DOCUMENT CHANGE LOG Table C.1 - Document change log Date Version Description Design, operation principle and technical characteristics of the Livi Smart Hub 24.09.2021...
