- Page 1 Snow Blower Operation and Maintenance Manual Model 1500 from Serial Number 06337 to Current Model 1500 High-Flow from Serial Number 11136 to Current Model 1501 from Serial Number 06496 to Current Revision Date: January 2021...
-
Page 2: Table Of Contents
Introduction ................................. 14 Snow Blower Assembly - 01-1500 ........................15 Snow Blower Decal list ............................15 Snow Blower Parts list - 01-1500 ........................16 Snow Blower Assembly - 01-1501 ........................17 Snow Blower Decals - 01-1501 .......................... 17 Snow Blower Parts - 01-1501 ..........................18 Snow Blower Manifold Block –... - Page 3 TORQUE SPECIFICATION TABLE ..................27 General Specification Table ..........................27 SKID PRO ATTACHMENT Warranty ..................28 Rev. 2: 1-2021 Skid Pro Snow Blower Page 2...
-
Page 4: Introduction
It is also advisable to supply them to your insurance company. It will be helpful in the event that an equipment or skid steer is lost or stolen. SKID STEER IMPLEMENT MODEL: SERIAL NUMBER: DATE OF PURCHASE: DEALER NAME: Rev. 2: 1-2021 Skid Pro Snow Blower Page 3... -
Page 5: Safety Precautions
6. Never allow children to operate the machine even under adult supervision. 7. Use extra care when approaching blind corners, shrubs, trees, or other obstructions that might hide children from sight. Rev. 2: 1-2021 Skid Pro Snow Blower Page 4... -
Page 6: Notice
13. Use of counterweights is recommended. Weights provide the necessary balance to improve stability, traction and steering. Use only those recommended by your dealer. Rev. 2: 1-2021 Skid Pro Snow Blower Page 5... -
Page 7: Snow Blower Operation
21. Prolonged exposure to loud noise can cause impairment or loss of hearing. Wear a suitable hearing device such as earmuffs or earplugs to protect against objectionable or uncomfortable noises. 22. Never allow anyone near the work area. Rev. 2: 1-2021 Skid Pro Snow Blower Page 6... -
Page 8: The Skid Steer
21. DO NOT bypass the safety system by shorting across the terminals of the starter motor to start the engine. This may cause the skid steer to move suddenly. 22. If the safety start system does not work, consult your dealer immediately Rev. 2: 1-2021 Skid Pro Snow Blower Page 7... -
Page 9: During Operation
7. Securely lock equipment drive shaft. Check that all skid steer and equipment drivelines are in good working order. 8. Additional safety equipment: A fire extinguisher and first aid kit should be kept readily accessible. These are available through your dealer. Rev. 2: 1-2021 Skid Pro Snow Blower Page 8... -
Page 10: Maintenance
Do not use your hands to check for leaks. Use a piece of cardboard or paper to search for leaks. 16. Stop engine and relieve pressure before connecting lines. Tighten all connections before starting engine or pressurizing lines. Rev. 2: 1-2021 Skid Pro Snow Blower Page 9... -
Page 11: Transporting
5. Lubricate the snow blower as instructed under the "Lubrication" section. 6. When the snow blower is dry, oil all moving parts. Apply oil liberally to all surfaces to protect against rust. 7. Store in a dry place. Rev. 2: 1-2021 Skid Pro Snow Blower Page 10... -
Page 12: Operation
Refer to the skid steer's operating manual for instructions. WARNING: To avoid serious personal injury: Make sure skid steer engine and snow blower come to a complete stop and skid steer drive mechanism is disengaged BEFORE making any adjustments. Rev. 2: 1-2021 Skid Pro Snow Blower Page 11... -
Page 13: Deflector Adjustment If Manual
Remove skid shoe bolts (item 2) and adjust according to instructions below, and securely tighten bolts: Clearance between cutting edge and surface: Level paved surface: Adjust to 1/16" to 1/8" Uneven or gravel surface: Adjust 1/2" to 5/8" Rev. 2: 1-2021 Skid Pro Snow Blower Page 12... -
Page 14: Snow Removal Methods
180 degrees for the return pass. At the end of changing the direction of the discharge guide. each succeeding pass, rotate the discharge guide 180 degrees to maintain direction of throw in the same area. Rev. 2: 1-2021 Skid Pro Snow Blower Page 13... -
Page 15: Lubrication
The manufacturer reserves the right to change, modify, or eliminate from time to time, for technical or other reasons, certain or all data, specifications, or the product or products themselves, without any liability or obligation. Rev. 2: 1-2021 Skid Pro Snow Blower Page 14... -
Page 16: Snow Blower Assembly - 01-1500
Snow Blower Assembly - 01-1500 Snow Blower Decal list Label Letter Description QTY. Warning Do Not Put Hands In Large Logo Auger Warning Model/Serial Number Grease Daily Small Logo Caution Do Not Operate with Guard Removed Rev. 2: 1-2021 Skid Pro Snow Blower... -
Page 17: Snow Blower Parts List - 01-1500
Snow Blower Parts list - 01-1500 Item No. Part Number Description QTY. AU-02-1505 Rev 3 Auger Motor Mount AU-02-1504-Width Rev 2 Auger 104-4236-006 Auger Drive Motor AU-02-1501 Rev 4 AU-02-1502 rev 3 Chute Assembly AU-01-1600 Chute Tip Cylinder AU-02-1602 Back Foot AU-02-1671 Skid Shoe, L.H. -
Page 18: Snow Blower Assembly - 01-1501
Snow Blower Decals - 01-1501 Label Letter Description QTY. Warning Do Not Put Hands In Large Logo Auger Warning Model/Serial Number Grease Daily Small Logo Caution Do Not Operate with Guard Removed Rev. 2: 1-2021 Skid Pro Snow Blower Page 17... -
Page 19: Snow Blower Parts - 01-1501
Hydraulic Guard AU-03-5121 Manual Canister PH250-FT12 -10 Male ORB to 1/4" NPT Female Rigid PH250-FT05 1/4" NPT ST 90 PH500-FT11 -10 Male ORB to 1/2" NPT Female Swivel AU-03-1775 Wire Harness Rev. 2: 1-2021 Skid Pro Snow Blower Page 18... -
Page 20: Snow Blower Manifold Block - Standard Flow - Parts & Assembly
Snow Blower Manifold Block – Standard Flow - Parts & Assembly PART NUMBER DESCRIPTION QTY. ITEM AU-02-3200 Manifold Block PH250-FT1108 8MOR-4FPX STR PH500-FT1212 12MOR-8FP PH500-FT05 90° Fitting PH500-FT1216 16MOR-8FP STR Rev. 2: 1-2021 Skid Pro Snow Blower Page 19...
