Operator’s Manual THREE SPINDLE FINISH MOWER ACYCMO72 The operator’s manual is a technical service guide and must always accompany the machine. Manual 980-173B June 2015...
Page 2
SAFETY Take note! This safety alert symbol found throughout this manual is used to call your attention to instructions involving your personal safety and the safety of others. Failure to follow these instructions can result in injury or death. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Page 3
INDEX 1 - GENERAL INFORMATION 1.01 - General 1.02 - Warranty Information 1.03 - Model and Serial Number ID 2 - SAFETY PRECAUTIONS 2.01 - Preparation 2.02 - Starting and Stopping 2.03 - Messages and Signs 3 - OPERATION 3.01 - Operational Safety 3.02 - Assembly Instructions 3.03 - Cutting Height Adjustment 3.04 - Pre-Operational Check...
Page 4
’ INISH OWER PERATOR ANUAL 1 - GENERAL INFORMATION Thank you and congratulations for having chosen our implement. Your new finish mower is a technologically advanced machine constructed of high quality, sturdy components that will fulfill your working expectations. Read this manual carefully. It will instruct you on how to operate and service your mower safely and correctly.
Page 5
’ INISH OWER PERATOR ANUAL This limited warranty covers defective material and workmanship. The cost of normal maintenance or repairs for accidents or improper use and related labor will be borne by the owner. 1.03 - Model and Serial Number ID Attached to the frame is an ID plate showing the model and the serial number.
Page 6
’ INISH OWER PERATOR ANUAL 2 - SAFETY PRECAUTIONS Safety is the primary concern in the design and manufacture of our products. Unfortunately our efforts to provide safe equipment can be wiped out by a single careless act of an operator. In addition to the design and configuration of equipment, hazard control and accident prevention are dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation, transport, maintenance and storage of...
Page 7
’ INISH OWER PERATOR ANUAL 2.02 - Starting and Stopping 1. Be sure that no one is near the machine prior to engaging or while the machine is working. 2. Be sure the tractor is in “Neutral” before starting engine. 3.
Page 8
’ INISH OWER PERATOR ANUAL Fig. 2 - Safety decals; replace immediately if damaged. placed under belt shield right side red reflective decal left side ABI A AFETY RECAUTIONS TTACHMENTS...
Page 9
’ INISH OWER PERATOR ANUAL Safety decals - driveline; replace immediately if damaged. placed on outer shield placed on outer tube ABI A AFETY RECAUTIONS TTACHMENTS...
Page 10
’ INISH OWER PERATOR ANUAL 3 - OPERATION You have purchased a three spindle mower designed especially for the mowing of grassy areas where a highly professional cut is required without wasting time. This mower is perfect for the maintenance of parks, private lawns, industrial parks, airports, hospital grounds, schools, highways, golf courses, sport complexes, etc.
Page 11
’ INISH OWER PERATOR ANUAL stop before dismounting tractor. Never leave equipment unattended with the tractor running. 6. Never place hands or feet under mower with tractor engine running or before you are sure all motion has stopped. Stay clear of all moving parts. 7.
Page 12
’ INISH OWER PERATOR ANUAL 25. Always cut down slopes; never across the face. Avoid operation on steep slopes. Slow down on sharp turns and slopes to prevent tipping and/or loss of control. 3.02 - Assembly Instructions CAUTION: Stand clear of bands when cutting as they could be under sufficient tension to cause them to fly loose.
Page 13
’ INISH OWER PERATOR ANUAL 8. Bolt up the top hitch supports (see #3, fig. 3 & 4) to the inside of the linking plates (see #6, fig. 3) that are already bolted to the outside of the front support plates (see #7, fig.
Page 14
’ INISH OWER PERATOR ANUAL The cutting height is the distance from the blades to the ground. The cutting height is adjusted by moving the spacers on the wheel yokes. Placing spacers between the wheel arm and the wheel yoke raises the cutting height by the size of the spacer. Removing the spacers, lowers it by the same height (see fig.
Page 15
’ INISH OWER PERATOR ANUAL 7. All hardware is tight. 8. The tractor, to ensure correct direction of PTO and rpm speed. 9. All safety shields and guards are in place and tightly attached. 10. No people or animals are in the work area. 11.
Page 16
’ INISH OWER PERATOR ANUAL Release the pin and pull back slowly until the pin clicks in place. Repeat this operation on the implement end. 5. Attach the driveline chains to the tractor and to the mower to keep the driveline protection from turning.
Page 17
’ INISH OWER PERATOR ANUAL 11. Checking that the PTO shield, belt shields and all other shielding are on the machine and securely in place. 12. Making sure the proper attire is worn. Avoiding loose fitting clothing which can become entangled. Wearing sturdy, tough-soled work shoes and protective equipment for eyes, hands, ears and head.
Page 18
’ INISH OWER PERATOR ANUAL Another benefit of the mulching kit is safety. In fact, the kit greatly reduces the possibility of thrown objects. This is particularly important when mowing around schools, public parks and golf courses. If you are using a mulching kit, you need to reduce your ground speed to under 2 mph (see fig.
Page 19
’ INISH OWER PERATOR ANUAL Pick up all rocks and other debris before mowing. Enter new areas carefully. Cut grass higher at first, allowing mower to clear hidden objects. CAUTION: For emergency reasons learn how to stop the tractor and mower quickly.
Page 20
’ INISH OWER PERATOR ANUAL driveline and store in appropriate place. Disconnect three point linkage and carefully drive tractor away from mower. 3.11 - Transport Before raising the mower for transport, the tractor top link must be adjusted so when lifted, the rear of the machine is higher than the front (the mower’s nose is tilted downward).
Page 21
’ INISH OWER PERATOR ANUAL Quick Hitch Adapter assembly (see fig. 7): 1. Remove hitch pins from finish mower’s linking plates. 2. Remove M16x140 bolt on top of the three point hitch of the finish mower. 3. Remove M20x45 bolts that hold the top hitch supports to the linking plates of the mower.
Page 22
’ INISH OWER PERATOR ANUAL Quick Hitch Adapter operation: After completing assembly of the adapter, the tractor lift arms should be raised and locked in a position so the floating yokes are horizontal. Ensure that the M16x60 bolt is approximately in the center of the slot on the floating yoke. Positioning the bolt in this location allows the mower to have maximum float both up and down.
Page 23
’ INISH OWER PERATOR ANUAL 4 - MAINTENANCE DANGER: Stop engine, lock parking brake and remove key before performing any service or maintenance. Never rely on the tractor lift system. Install blocks or stands under the mower deck to prevent it from falling. Always use personal protection devices, such as glasses or gloves when performing maintenance.
Page 24
’ INISH OWER PERATOR ANUAL 15. Where replacement parts are necessary for periodic maintenance and servicing, genuine replacement parts must be used to restore your equipment to original specifications. The company will not claim responsibility for use of unapproved parts and/or accessories and other damages as a result of their use.
Page 25
’ INISH OWER PERATOR ANUAL Every 8 hours: 1. Lubricate the driveline (see fig. 8) and the wheel yokes (see fig. 9): Apply two or three shots of grease to the driveline cross and bearings and to the inner and outer locking rings;...
Page 26
’ INISH OWER PERATOR ANUAL Every 50 hours: 1. Lubricate the three spindles with two or three shots of multipurpose grease (see fig. 10). The top grease fittings are easily accessible from the top of the deck by simply removing the plastic dust guards. 2.
Page 27
’ INISH OWER PERATOR ANUAL Installing or removing blades If the mower blades need to be installed, do the following: 1. The blade turns in a counter clockwise direction when viewed from the bottom of the deck. The cutting edge must be towards the direction of rotation. The lift wing of the blades is closest to the deck and the cutting edge away from it (see fig.
Page 28
’ INISH OWER PERATOR ANUAL CAUTION: Unbalanced or warped blades can cause damage to the mower and/or personal injury. Replace damaged blades before operating the mower. Sharpen both ends of the mower blades equally or until the blade is balanced. 4.04 - Belt Tension Belt tension control Check the belt tension by applying a force of 12-15 lb.
Page 29
’ INISH OWER PERATOR ANUAL 2. Release spring tensioner to loosen belt. 3. Loosen rear nuts holding central plate (do not remove them). 4. Remove front nuts holding central plate (see fig. 13). 5. Lift the front of the central plate and remove old belt. 6.
Page 30
’ INISH OWER PERATOR ANUAL If determined that the driveline is too long, follow these procedures to adjust the length: 1. Separate the two driveline halves. Connect one half to the tractor PTO and the other half to the mower. 2.
Page 32
’ INISH OWER PERATOR ANUAL 5 - REPAIR PROCEDURES CAUTION: It is not recommended that untrained individuals perform any repair work. The following operations are detailed for qualified personnel only. 5.01 - Gearbox To remove the gearbox: 1. Remove the belt 2.
Page 33
’ INISH OWER PERATOR ANUAL Description Quantity Blades Blade bolts and washers Belts 5.04 - Storage After seasonal use it is important to perform the following for prolonged storage: 1. Wash the mower carefully. 2. Inspect the mower and replace worn or damaged parts. 3.
Page 34
’ INISH OWER PERATOR ANUAL 6 - TROUBLESHOOTING WARNING: Be sure tractor engine is off, parking brake is locked, and key is removed before making any adjustments. PROBLEM POSSIBLE CAUSE SOLUTION Uneven cutting. Cup washer not between Check washer location at all 3 blade and bolt.
Page 36
1320 3rd. Street Osceola, IN 46561 877.788.7253 ABIattachments.com...
Page 37
Parts Manual THREE SPINDLE FINISH MOWER ACYCMO72 Manual 981-173B June 2015 Parts Manual 06/2015 C30-RD6 Ver. G...
Page 38
’ INISH OWER RAME PERATOR ANUAL ABI A ARTS ANUAL TTACHMENTS 06/2015...
Page 39
’ INISH OWER RAME PERATOR ANUAL Ref. Part # Description Qty. 035-1501P Frame 72” rear discharge 030-8817 Belt shield 72” 005-1585 Central plate 72” 000-6647 005-1859 Rear protection 72”, inner 005-1856 Rear protection 48”-72”, inner 000-8818 Bolt HH M10-1.50x110 C8.8 Z F 001-4106 Nut ES M10-1.50 Z TK 003-0157...
Page 40
& W ’ INISH OWER HREE OINT ITCH HEEL PERATOR ANUAL ABI A ARTS ANUAL TTACHMENTS 06/2015...
Page 41
& W ’ INISH OWER HREE OINT ITCH HEEL PERATOR ANUAL Ref. Part # Description Qty. 005-6511 Top hitch support 48”-72” 035-6521 Top hitch arm 72” 000-6829 Spacer Ø26.9x4x79 mm. 000-6828 Top hitch plate 000-6891 Bolt HH M16-2.00x140 C8.8 Z P 000-5581 Nut PT M16-2.00 C6 Z TK 003-2687...
Page 42
& S ’ INISH OWER RANSMISSION PINDLE PERATOR ANUAL ABI A ARTS ANUAL TTACHMENTS 06/2015...
Page 43
& S ’ INISH OWER RANSMISSION PINDLE PERATOR ANUAL Ref. Part # Description Qty. 000-8881 Pulley SPB 160x1 000-8561 Pulley, belt tensioner 000-8950 Belt BX 140 005-1740 Spring 000-8623 Pulley SPB 250x1 005-1745 Support, belt tensioner 005-1757 Hitch plate 005-1751 Bolt belt tensioner SP M10-1.50 005-1753 Washer flat Ø16 Z...
Page 44
’ INISH OWER EARBOX TANDARD PERATOR ANUAL ABI A ARTS ANUAL TTACHMENTS 04/2015...
Page 45
’ INISH OWER EARBOX TANDARD PERATOR ANUAL Ref. Part # Description Qty. 001-0192 Oil seal 40.68.10 001-2149A Bearing 6208 000-8892 Input shaft 000-8609 000-1806 Nut HH M08-1.25 C6 Z TK 001-0177 Breather cap 000-8601 Gasket, breather cap 001-0171 Bolt SC M08-1.25x50 C8.8 Z P 005-6681 Housing w/o fill hole, gearbox 000-3038...
Page 46
(AMA) ’ INISH OWER RIVELINE PERATOR ANUAL #286014 #320235 FROM ABI A ARTS ANUAL TTACHMENTS 06/2015...
