TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
4 5 6 7
1 2 3
for CC-Link, POWER
■ CONNECTION DIAGRAM
4
DA
1
DB
5
DG
2
SLD
3
FG
6
24V DC
7
0V
In order to improve EMC performance, bond the FG
terminal to ground.
Caution: FG terminal is NOT a protective conductor terminal.
Output Connection Examples
+
VHn
WIDE SPAN
VLn
VOLTAGE
COMn –
SEN TRONIC
115 (4.53)
6 7 8 9
1 2 3 4 5
6 (.24)
7–M3 SCREW
TERMINALS
OUTPUT 0
7
VH0
8
VL0
2
COM0
3
COM0
OUTPUT 1
9
VH1
10
VL1
4
COM1
5
COM1
VHn
VLn +
NARROW SPAN
VOLTAGE
COMn –
056 222 38 18
AG
17 (.66)
10
6 (.24)
10–M3 SCREW
TERMINALS
for OUTPUT
mailbox@sentronic.com www.sentronic.com
R7C-YV2
54 (2.13)
DIN RAIL
35mm wide
30 (1.18) [5 (.20)]
