- Page 1 Last updated: 2020-9-2 C2000-B2-UJE0401-CB6 User Manual ⇋ Ethernet 4 * RS485/422/232 6 TCP/IP connections Serial-to-Ethernet Device — Serial Device Server SinoCon Co., Ltd.
-
Page 2: Copyright Notice
Copyright Notice ©2000 - 2020 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means. - Page 3 C2000-B2-UJE0401-CB6 User Manual SinoCon Co., Ltd. www.sinoconsys.com 4 / 11...
-
Page 4: Hardware Description
C2000-B2-UJE0401-CB6 User Manual 1. Hardware Description 1.1. Specifications Classification Parameter Specification Ethernet No. of Ports Bandwidth 10/100M Communication Distance 100m Protocol Mode Support TCP Server/TCP Client/UDP Mode Max. No. of TCP Connections Downstream Serial Serial Standard RS485/422/232 Port No. of Ports... - Page 5 C2000-B2-UJE0401-CB6 User Manual 1.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 6 / 11...
- Page 6 C2000-B2-UJE0401-CB6 User Manual 1.3. Indicators Classification Indicator Description Meaning Ethernet LINK Network status Steady on：Network connection enabled indicator Flashing：Transmit or receive data Off：The network port is not plugged into the network cable 10/100Mbps Steady on：100M network connected indicator Off：Not connected to the 100M network...
-
Page 7: Port Description
C2000-B2-UJE0401-CB6 User Manual 1.4. Port Description Recommended Classification Port Description wiring Ethernet Ethernet RJ45 Ethernet port CAT-5e Downstream Serial RS485/422x RS485/422 communication port CAT-5e Port (downward) RS232x RS232 communication port (downward) CAT-5e Power Input Button Power switch button Socket 220VAC power input SinoCon Co., Ltd. -
Page 8: Product Dimensions
C2000-B2-UJE0401-CB6 User Manual 1.5. Product Dimensions unit: mm（inch） 1.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 9 / 11... -
Page 9: Package Contents
C2000-B2-UJE0401-CB6 User Manual 2. Package Contents Contents Device * 1 Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 10 / 11... -
Page 10: Warranty Policy
C2000-B2-UJE0401-CB6 User Manual 3. Warranty Policy In the normal use of the products you purchased, free warranty service will be provided from the date of purchase whenever the quality problems caused by raw materials or production process are concerned. However, due to the user's failure to install, disassemble or improperly use the product according to the requirements of this product manual, the company provides maintenance services, but charges appropriate maintenance fees.
