Sunset Furniture Sunset Trading Brook DLU-BR-B20-RTA Assembly Instruction

Pls Check to make sure you have all
* *
parts otherwise contact local retailer
or Sunset Trading customer service
at 877-364-8464''
d
e
a
f
f
Step 2 01
02
06
04
Thank You for purchasing this Quality product. It has
been engineered for easy assembly yet constructed
for durability.Please take the time to read and follow
the instruction while assembling.
Step 1
d
e
c
02
f
06
05
03
ASSEMBLY INSTRUCTION
Model : DLU-BR-B20-RTA (CS-1806-RTA)
01
02
d
e
b
1 OF 2
BROOK COUNTER STOOL
SIZE : 18 1/4" x 21 1/2" x 41" H

List of Part For 1 Set

Figure
Code Part
01 Chair Back
02
Seat Frame
Front Leg (R)
03
04
Front Leg (L)
Front Stretcher
05
06
Side Stretcher

List of hardware For 1 Set

Code Figure Hardware
Hex. Bolt
a
M6 x 80mm
Hex. Bolt
b
M6 x 60mm
Hex. Bolt
c
M6 x 40mm
Flat Washer
d
1/4 " x 18mm
Spring Washer
e
1/4 "
Spanner
f
10mm
PHRS Screw
g
#8 x 1 1/4"

Important Notes

* Keep all hardware parts out of reach
of children.
* Must tighten screws periodically.With
use screws will become loose.Check
tightness of all screws every 6-8
weeks.
* Don't attempt to repair or modify
parts that are broken or defective.
Please contact the store
immediatedly.
Do not tighten all screw / bolt until all
*
completely assembled.
Notes
Place all wooden parts on a clean and
*
smooth surface such as a rug or carpet
to avoid the parts from being
scratched.
Check to be sure that you have all
*
parts and hardware.
Remove all wrapping materials
*
including staples & packing straps
before you start to assemble.
Do not tighten all screws / bolts until all
*
completely assembled.
Care And Maintenance
The Touch of a soft cloth is all the
*
maintenance your wood pieces will ever
need.
Never use harsh chemicals or abrasive
*
cleaner as they could mark or destroy
finish.
MADE IN MALAYSIA
Qty.
1
1
1
1
1
2
Qty.
4
4
2
10
10
1
6
