MAGNITUDE LIGHTING LINDRIVE Series Installation Manual

120-130vac / 12vdc

Advertisement

FOR MODELS
SLT20L12, SLT40L12

General

This driver is to be installed in accordance with Article 450 of the
National Electric Code. The driver must be installed in a well-ventilated
area free from explosive gases and vapors. Proper operation requires
for free flow of air. This driver should only be installed by a qualified
electrician.

Precautions Before Installing

Check the label and ensure the driver has the proper input voltage and
wattage for the job. Check the wire markings to ensure they match the
wiring diagram on this installation guide.

Mounting

Select a suitable location capable of supporting the weight of the
driver. Use the two key holes in the wire housing and third hold on the
flange when mounting. It is recommended that the driver be mounted
vertically with the wiring compartment pointing down. Recommended
spacing between drivers is 5".
5" Min.
Spacing
Half hole
mounting flanges
Magnitude, Inc.
14711 Bentley Circle. Tustin, CA 92780
LINDRIVE SERIES

Quick Specs

Input Voltage
Output Voltage
Max. Ambient Temp.
Enclosure
Min. Installation Space
Between Drivers
www.MagnitudeInc.com
INSTALLATION GUIDE
120-130VAC / 12VDC
100-130V AC
12V DC
-250 C to 450 C (-13°F - 113°F)
IP21 Dry and Damp
5" Inch
