WAAS Changes
GPS 3000 / 3050 / 3100 / 4050 / 4100 / 5100
Setting up the receiver with Ag Remote
Version 3.00 firmware is required to enable WAAS satellites 135 and 138
Connect your receiver to a PC and access it with Ag Remote. Refer to
not have a current version of Ag Remote.
1.View the receiver firmware version. (Press Status / Receiver Status / Version.) If you do not have version
3.00 installed, use the FlashLoader 100 utility to update the firmware. You can download the firmware
and the FlashLoader utility from www.agleader.com
2.From the receiver Home screen, press ⇒ two or three times, depending the receiver model, to access the
Configuration menu. Press ⇓ to enter Configuration and then press ⇒ to access the DGPS Config
menu.
3. From the DGPS Config menu, press ⇓ four or five times to access the SBAS Sats screen. The satellite
name and status appear on the lower line.
4. Press ⇒. The cursor blinks on the satellite name.
2202 South Riverside Drive, P.O. Box 2348, Ames, IA 50010
Phone: 515-232-5363 Fax: 232-3595 Internet:
7/12/2007
http://www.agleader.com
www.agleader.com
if you do
Advertisement
Table of Contents
Summary of Contents for Ag Leader Technology GPS 3000
- Page 1 Phone: 515-232-5363 Fax: 232-3595 Internet: http://www.agleader.com WAAS Changes GPS 3000 / 3050 / 3100 / 4050 / 4100 / 5100 Setting up the receiver with Ag Remote Version 3.00 firmware is required to enable WAAS satellites 135 and 138 www.agleader.com Connect your receiver to a PC and access it with Ag Remote.
- Page 2 2202 South Riverside Drive, P.O. Box 2348, Ames, IA 50010 Phone: 515-232-5363 Fax: 232-3595 Internet: http://www.agleader.com 5. Press ⇓ to scroll through the list of satellites until you reach 135. The status value is Disabled. 6. To edit the satellite status, press ⇒ and then press ⇓ to change the value to Heed Health. *Note –...
