Product Overview
The Catalyst 3850 family of switches are Ethernet switches to which you can connect devices such as Cisco
IP Phones, Cisco Wireless Access Points, workstations, and other network devices such as servers, routers,
and other switches.
The Catalyst 3850 switches support stacking through Cisco StackWise-480 technology and power management
through StackPower. The StackWise technology for the Catalyst 3850 switches is called StackWise-480.
Unless otherwise noted, the term switch refers to a standalone switch and to a switch stack.
This chapter contains these topics:
•
•
•
•
Switch Models
Table 1: Catalyst 3850 Switch Models and Descriptions
Switch Model
WS-C3850-24T-L
WS-C3850-48T-L
WS-C3850-24P-L
WS-C3850-48P-L
Switch Models, on page 1
Front Panel, on page 6
Rear Panel, on page 22
Management Options, on page 31
Supported Software Image
LAN Base
LAN Base
LAN Base
LAN Base
Description
Stackable 24 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
Stackable 48 10/100/1000 Ethernet
ports, 1 network module slot, 350
W power supply
Stackable 24 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
Stackable 48 10/100/1000 PoE+
ports, 1 network module slot, 715
W power supply
Product Overview
2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Catalyst 3850 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CIS Catalyst 3850 Series

  • Page 1 Product Overview The Catalyst 3850 family of switches are Ethernet switches to which you can connect devices such as Cisco IP Phones, Cisco Wireless Access Points, workstations, and other network devices such as servers, routers, and other switches. The Catalyst 3850 switches support stacking through Cisco StackWise-480 technology and power management through StackPower.
  • Page 2 Product Overview Switch Models Switch Model Supported Software Image Description WS-C3850-48F-L LAN Base Stackable 48 10/100/1000 PoE+ ports, 1 network module slot, 1100 W power supply WS-C3850-24U-L LAN Base Stackable 24 10/100/1000 Cisco UPOE ports, 1 network module slot, 1100 W power supply WS-C3850-48U-L LAN Base Stackable 48 10/100/1000 Cisco...
  • Page 3 Product Overview Switch Models Switch Model Supported Software Image Description WS-C3850-48PW-S IP Base Catalyst 3850 48-port PoE IP Base with 5 access points license WS-C3850-12S-S IP Base Stackable 12 SFP module slots, 1 network module slot, 350 W power supply WS-C3850-24S-S IP Base Stackable 24 SFP module slots, 1...
  • Page 4 Product Overview Switch Models Switch Model Supported Software Image Description WS-C3850-48XS-F-S IP Base Catalyst 3850 switch with SFP+ transceivers, 48 ports that support up to 10 G, and 4 QSFP ports that support up to 40 G. 750 W power supply.
  • Page 5 Product Overview Switch Models Switch Model Supported Software Image Description WS-C3850-24U-E IP Services Stackable 24 10/100/1000 Cisco UPOE ports, 1 network module slot, 1100 W power supply WS-C3850-48U-E IP Services Stackable 48 10/100/1000 Cisco UPOE ports, 1 network module slot, 1100 W power supply WS-C3850-12S-E IP Services Stackable 12 SFP module slots, 1...

  • Page 6: Front Panel

    Product Overview Front Panel Switch Model Supported Software Image Description WS-C3850-48XS-E IP Services Catalyst 3850 switch with SFP+ transceivers, 48 ports that support up to 10 G, and 4 QSFP ports that support up to 40 G. 750 W power supply.
  • Page 7 Product Overview Front Panel • LEDs • Mode button All of the switches have similar components. See the following illustrations for examples. Note The Catalyst 3850 switches might have slight cosmetic differences on the bezels. Figure 1: WS-C3850-48P-L Switch Front Panel Mode button USB mini-Type B (console) port...

  • Page 8: Poe, Poe+, And Cisco Upoe Ports

    Product Overview 10/100/1000 Ports USB mini-Type B (console) port Figure 3: WS-C3850-24XS-E Switch Front Panel Note The WS-C3850-24XS-E switches have the following components. Mode button USB mini-Type B (console) port Status LEDs 10 G SFP+ ports USB Type A storage port Network module 10/100/1000 Ports The 10/100/1000 ports use RJ-45 connectors with Ethernet pinouts.

  • Page 9: Management Ports

    Product Overview SFP and QSFP Module Slots Depending on the installed power supply modules, each port can deliver up to 60 W of Cisco UPOE. See the Power Supply Modules, on page 25 for the power supply matrix that defines the available PoE, PoE+, and Cisco UPOE power per port.

  • Page 10: Usb Type A Port

    Product Overview USB Type A Port If you use the USB mini-Type B console port, the Cisco Windows USB device driver must be installed on any PC connected to the console port (for operation with Microsoft Windows). Mac OS X or Linux do not require special drivers.

  • Page 11: Network Modules

    Product Overview Network Modules Figure 5: Cisco USB Bluetooth Network Modules The switch supports one hot-swappable network module that provides uplink ports to connect to other devices. The switch should only be operated with either a network module or a blank module installed. The switch generates logs when you insert or remove a network module with SFP ports.
  • Page 12 Product Overview Network Modules Network Module Description C3850-NM-2-10G This module has four slots: Two slots (left side) support only 1 G SFP modules and two slots (right side) support either 1 G SFP or 10 G SFP modules. Note This is supported on the following switch models: •...

  • Page 13: Sfp And Sfp+ Modules

    Product Overview SFP and SFP+ Modules All network modules are hot-swappable. For information about the network modules, see the Installing Network Modules. For cable specifications, Cables and Adapters. SFP and SFP+ Modules The SFP and SFP+ modules provide copper or fiber-optic connections to other devices. These transceiver modules are field-replaceable, and they provide the uplink interfaces (expect in the fixed SFP slots in the WS-C3850-12S and WS-C3850-24S switches) when installed in an SFP module slot.
  • Page 14 Product Overview LEDs Figure 6: Switch Front Panel LEDs This figure shows the switch LEDs and the Mode button that you use to select a port mode. STAT (status) USB mini-Type B console port LED DUPLX (duplex) SYST (system) SPEED ACTV (active) STACK S-PWR (StackPower)
  • Page 15 Product Overview LEDs Figure 7: Switch Front Panel LEDs for the WS-C3850-12S, WS-C3850-24S, WS-C3850-12XS, and WS-C3850-24XS Switches UID (blue beacon) USB mini-Type B console port LED STAT (status) SYST (system) DUPLX (duplex) ACTV (active) SPEED STACK S-PWR (StackPower) XPS = expandable power system. Figure 8: Switch Front Panel LEDs for the WS-C3850-48XS Switches Product Overview...
  • Page 16 Product Overview SYST LED UID (blue beacon) STACK STAT (status) USB mini-Type B console port LED DUPLX (duplex) SYST (system) SPEED ACTV (active) SYST LED Table 3: SYST LED Color System Status System is not powered on. Green System is operating normally. Blinking green POST in progress.

  • Page 17: Port Leds And Modes

    Product Overview Port LEDs and Modes http://www.cisco.com/go/xps2200_hw Port LEDs and Modes Each Ethernet port, 1-Gigabit Ethernet module slot, and 10-Gigabit Ethernet module slot has a port LED. These port LEDs, as a group or individually, display information about the switch and about the individual ports.
  • Page 18 Product Overview Port LEDs and Modes Port Mode Port LED Color Meaning SPEED 10/100/1000/SFP ports Port is operating at 10 Mb/s. Green Port is operating at 100 Mb/s. Single green flash (on for Port is operating at 1000 Mb/s. 100 ms, off for 1900 ms) Blinking twice Port is operating at 2500, 5000 or 10000 Mb/s Network module slots...

  • Page 19: Usb Console Led

    Product Overview USB Console LED Port Mode Port LED Color Meaning PoE+ PoE+ is off. If the powered device is receiving power from an AC power source, the port LED is off even if the device is connected to the switch port. Green PoE+ is on.

  • Page 20: Stack Led

    Product Overview ACTV LED Color Description Blinking green This appears on the switch in a StackPower ring configuration that detects an open ring or has only one StackPower cable connected. Amber There is a fault: load shedding is occurring, a StackPower cable is defective, or an administrative action is required.
  • Page 21 Product Overview PoE LED Stack member 1 LED blinks green to show that this is switch 1 in the stack. Stack member 2 LED blinks green to show that this is switch 2 in the stack. Stack member 3 LED blinks green to show that this is switch 3 in the stack.

  • Page 22: Network Module Leds

    Product Overview Network Module LEDs Network Module LEDs Figure 10: Network Module LEDs G1 LED G3 LED G2 LED G4 LED Color Network Module Link Status Link is off. Green Link is on; no activity. Blinking green Activity on a link; no faults. Note The LED will blink green even when there is very little control traffic.
  • Page 23 Product Overview Rear Panel Figure 11: Catalyst 3850 Switch Rear Panel Ground connector StackWise port connector CONSOLE (RJ-45 StackPower connector console port) MGMT (RJ-45 AC OK (input) status 10/100/1000 management port) RESET button PS OK (output) status Fan module Power supply modules (AC power supply modules shown) Figure 12: WS-C3850-12S and WS-C3850-24S Switches Switch Rear Panel...

  • Page 24: Beacon Led

    Product Overview Rear Panel MGMT (RJ-45 AC OK (input) status 10/100/1000 management port) RESET button PS OK (output) status BEACON LED Power supply modules (AC power supply modules shown) Fan module Figure 13: WS-C3850-48XS Switches Switch Rear Panel Ground connector Fan module Product Overview...

  • Page 25: Console Port Led

    Product Overview RJ-45 Console Port LED CONSOLE (RJ-45 Power supply FAIL LED console port) BEACON LED Power supply OK LED MGMT (RJ-45 Power supply modules 10/100/1000 management 9 AC OK (input) status LED port) RJ-45 Console Port LED Table 12: RJ-45 Console Port LED Color RJ-45 Console Port Status RJ-45 console is disabled.
  • Page 26 Product Overview Power Supply Modules • PWR-C1-715WAC • PWR-C1-1100WAC • PWR-C1-440WDC The following power supply modules are applicable to only the WS-C3850-48XS switches: • PWR-C3-750WAC-R: This module has red handles to match fans with red handles. Airflow is from the front panel to the rear panel (warm air is ‘pulled out of’...
  • Page 27 Product Overview Power Supply Modules Models Default Power Supply Available PoE 24-port PoE+ switch PWR-C1-715WAC 435 W 48-port PoE+ switch 48-port full PoE+ switch PWR-C1-1100WAC 800 W 24-port Cisco UPOE switch 48-port Cisco UPOE switch Table 14: Available PoE with DC Power Supply Models Number of Power Supplies Available PoE...

  • Page 28: Fan Module

    Product Overview Fan Module PoE Option 24-Port Switch 48-Port Switch Cisco UPoE (up to 60 W per port) (2) 1100 W These are the combinations of power supplies: • (1) 1100 W + (1) 715 W • (2) 1100 W Note Up to 30 PoE ports can receive full Cisco UPoE.
  • Page 29 Product Overview Fan Module Note The WS-C3850 switches require three fans for proper cooling. The WS-C3850-48XS switches require five fans for proper cooling. Figure 14: 24- and 48-Port Switch Airflow Patterns The following illustrations show the airflow patterns for the 24- and 48-port switches. The blue arrow shows cool airflow, and the red arrow shows warm airflow.

  • Page 30: Stackpower Connector

    Product Overview StackPower Connector Figure 17: Airflow Patterns for the Catalyst 3850-48XS Switches (using Power Supplies and Fans with Red Handles) For information about installing a fan module and fan specifications, see the "Technical Specifications" chapter. StackPower Connector The C9300 switches have a StackPower connector for use with Cisco StackPower cables to configure a switch power stack that includes up to nine switches.

  • Page 31: Console Port

    Product Overview RJ-45 Console Port The following table shows the Ethernet management port LED colors and their meanings. Table 17: Ethernet Management Port LED Color Description Green Link up but no activity. Blinking green Link up and activity. Link down. RJ-45 Console Port The RJ-45 console port connection uses the supplied RJ-45-to-DB-9 female cable.
  • Page 32 Product Overview Management Options Product Overview...
