Congratulations on purchasing your Nextar Mobile DVD Player. Read this
manual to get started using your Nextar Mobile DVD Player quickly.
Important Safety Instructions.......... ...............................................................3
Precautions with Moisture .......... ...................................................................4
Function Features ...................... ...................................................................5
Parts Introduction ....................... ...................................................................6
Remote Control .......................... ...................................................................9
Connections ............................... ...................................................................11
Preparation................................. ...................................................................13
◆ Use of Remote Control.......... ...................................................................13
◆ Compatible disc formats........ ...................................................................14
Power Supply ............................. ...................................................................15
◆ Use of Adapter.......................................................................................15
◆ Use of Car Adapter ............. ...................................................................16
Basic Operations ........................ ...................................................................17
FM transmitter use......................................................................................19
System Setup ............................. ...................................................................20
Play Functions............................ ...................................................................23
Care of Discs.............................. ...................................................................26
Troubleshooting.......................... ...................................................................27
Specifications ............................. ...................................................................28
Advertisement
Table of Contents
Related Manuals for Nextar MP1607
Summary of Contents for Nextar MP1607
-
Page 1: Table Of Contents
Contents Congratulations on purchasing your Nextar Mobile DVD Player. Read this manual to get started using your Nextar Mobile DVD Player quickly. Important Safety Instructions... ………………………………………………………3 Precautions with Moisture ... ………………………………………………………….4 Function Features ... ………………………………………………………….5 Parts Introduction ... ………………………………………………………….6 Remote Control ... ………………………………………………………….9 Connections ... -
Page 2: Important Safety Instructions
Important Safety Instructions The lighting flash with arrowhead symbol within a triangle alerts the user to “dangerous voltage” which could cause electric shock. The exclamation point within a triangle alters user to read important operation and maintenance instructions in the manual. IMPORTANT FOR LASER PRODUCTS 1. -
Page 3: Precautions With Moisture
Precautions with Moisture ◆Under the following circumstances, moisture may appear on the lens of the product, which is the most sensitive part of the DVD player. - The DVD player is suddenly moved from a cold place to a warm place. - A room is heated while the DVD player starts operating, or the DVD is placed by an air-conditioner. -
Page 4: Function Features
Function Features 1. EXCELLENT SOUND Dolby Digital delivers great sound. 2. HIGH RESOLUTION MPEG2 decoding format achieves more than 500 lines of horizontal resolution. 3. SPECIAL FUNCTIONS Supports language caption parental-lock. 4. COMPATIBILITY Compatible with DVD, CD, CD-R/RW, and PICTURE CD discs. 5. -
Page 5: Parts Introduction
Parts Introduction DVD Player TFT Liquid Crystal Display buttons MODE button NEXT SKIP button PREV SKIP button ■STOP/ OFF button PLAY / ON button Speaker Remote sensor Indicator light 10. Headphone jack 11. VIDEO jack 12. Stand fixing hole 13. DC 9.5V input jack 14. - Page 6 Parts Introduction Front View 1. Latch hook Left View 1. Stand fixing hole - 6 -...
- Page 7 Parts Introduction Bottom View Battery contacting point VIDEO input/output jack AUDIO input/output jack AV IN/OUT switch FM CH1 (fixed frequency 87.9) FM CH2 (fixed frequency 88.1) FM OFF switch DC 9.5V IN Attention: Noise may occur in speakers when input external audio signal while playing a DVD disc.
-
Page 8: Remote Control
Remote Control - 8 -... - Page 9 Remote Control 1. PWR button -Press to turn the player on or off. 2. INFO button -Press for detailed information on the disc playing. -Keep pressing remove information from screen. 3. TITLE button -Press to display titles if present on the disc.
-
Page 10: Connections
Connections Connect to a TV Audio/video connections 1. Always ensure that the DVD player, TV and any other electrical equipment connected to DVD player is switched off and unplugged from the power supply. 2. Connect the DVD player to the TV’s audio/video inputs with audio/video cables. Connect to an Amplifier The DVD player can be connected to an AV amplifier. - Page 11 Connections Connect to Headphone Connect the headphone to the jack on the right side of the unit. When headphone is connected, the speaker will automatically turn off. - 11 -...
-
Page 12: Preparation
Preparation Use of Remote Control According to the drawings above, pull the empty battery tray out. Prior to shipping, a separating film was covering the battery. Remove this film. Place the battery into the tray and then insert the tray into the remote control. For best usage, aim the remote directly at the player’s receiving window from a range no greater than 15 feet, and at angles no greater than 60 degrees. -
Page 13: Compatible Disc Formats
Preparation Compatible Disc Formats The unit can play discs bearing any of the following logos: DISC LOGO Operation method of some DVD discs is specified by the software manufacturer. Please follow the instruction manual of the disc. The DVD Player will play most recordable (CD-R) or erasable (CD-RW) CDs, but playback of CD-R or CD-RW discs created on a computer requires proper formatting and finalization of the disc for audio playback. -
Page 14: Power Supply
Preparation Use of AC Adapter The player is supplied with a power adapter. Connect AC adaptor to the side of the DVD player in the slot marked “DC 9.5V IN”. Plug the two-prong end of the power cord to a grounded electrical socket. Note: Please turn player’s power off before unplugging. -
Page 15: Use Of Car Adapter
◆Please detach battery pack when using car adapter as power source. ◆We advise you power off the player at the instant of car start-up. A lithium-ion rechargeable battery pack is available as an optional accessory for greater ease and portability. Details available in-store or online at www.nextar.com. - 15 -... -
Page 16: Basic Operations
Basic Operation Please read the following instructions carefully before using your DVD player for the first time. Turn on the player’s power by pressing the on the front panel. Press OPEN button to open the disc cover. Load disc with the label side up. Close the disc cover. -
Page 17: Basic Operation
Basic Operation Stop 1. During playback, hold down ■ button on the control panel for more than 2 seconds to power off the player. 2. During play, press ■ button on the remote control to stop playing. Press button to continue playing from the point where it last stopped. During play, press ■... -
Page 18: Fm Transmitter Use
FM Transmitter Use This unit is equipped with an audio frequency transmitting function; you can use any FM equipment to receive a signal from it. The FM regulator is located on the bottom of the player. Please follow the steps below: Switch to CH1 or CH2 to open FM transmitter during play. -
Page 19: System Setup
System Setup SETUP You can change the default settings to customize performance to your own preference. Remove the disc from the DVD drive and press the SETUP button on the remote control. The settings menu will appear. It includes General Setup, Speaker Setup, Dolby Digital Setup, Video Setup and Preference Setup. - Page 20 System Setup 3. Captions You can turn captions on or off during play. 4. Screen Saver Press setup button on the remote control to enter general setup, move the highlight to “screen saver” by ▼ buttons, enter “screen saver” item by ▲...
- Page 21 System Setup Video Setup 1. Sharpness Use this item to adjust sharpness setting. 2. Brightness Use this item to adjust brightness level. 3. Contrast Use this item to adjust contrast level. Preference Page 1. Audio, Subtitle, Disc Menu This setting allows you to hear or read subtitles in English, French, Spanish, Chinese, Japanese, Korean, Russian or Thai.
-
Page 22: Play Functions
Play Functions Audio DVD discs contain up to 8 audio bit streams. For Example: English, French etc. To select the audio bit stream you prefer press the AUDIO button on the remote control during play. The DVD player will play the next audio bit stream every time you press the AUDIO button in succession. - Page 23 Play Functions Search by time You can use the GOTO button to search by time, i.e., to play from a given time. During DVD playback, press GOTO button to display a menu, then use the button to select the title or chapter, then press ENTER button to enter setup, press number buttons to input the time, press the ENTER button again to start playback.
- Page 24 Play Functions Playing a JPEG disc JPEG is a common picture format that has small file size and low quality loss rate of picture. Hundreds of pictures can be stored in a disc in this format. In order to utilize real digital album, use film to make a ”PICTURE CD” in JPEG format. OPERATION 1.
-
Page 25: Care Of Discs
Care of Discs How to hold discs When loading or removing discs, try not to touch their playing surfaces. Cleaning Fingerprints or stain on the disc may affect the quality of sound and picture. To clean your discs, use a soft clean cloth to wipe them. -
Page 26: Troubleshooting
Troubleshooting SYMPTOM - Please make sure the disc cover is closed. - Please make sure a disc is loaded. - Please make sure the disc isn’t loaded upside down. - Disc should be clean, not dirty or warped. The player cannot play. - Player’s region code should be the same as region code of DVD disc. -
Page 27: Specifications
Specifications TFT screen size Laser Wavelength Video System Frequency Response Audio Signal-to-noise Rate Audio distortion + noise Channel Separation Dynamic Range Audio Out Analog Audio Out Video Out Video Out Power AC 100-240V～50/60Hz Power Consumption ＜25W Dimensions 200mm x 156mm x 30mm (L*W*D) Weight 0.9kg DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE...
