- Page 1 INSTRUCTION MANUAL 20V Cordless Blower Model # PS76101AH Have product questions or need technical support? Please feel free to contact us! Website: www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Assembly instruction……………………………………………………… 11 Operating instruction…………………………………………………..Maintenance.……………………………………………………………… 13 Environmentally safe battery disposal……………………………………. 14 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty statement……………………………………………………… TECHNICAL DATA 20V Cordless Blower Model # PS76101AH Power input: Blower speed: 130MPH No-load speed: 13500 RPM Battery type: 20V Lithium-ion,2.0Ah... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your blower works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 6 Do not operate this unit when you are tired, ill, or under the influence of alcohol, drugs, or medication. Keep all parts of your body away from any moving parts and all hot surfaces of the unit. Do not put any object into openings. Do not use with any opening blocked; keep openings free of dust, lint, hair, and anything that may reduce air flow.
- Page 7 vinegar. If liquid gets into your eyes, flush them with clean water for at least 10 minutes, then seek immediate medical attention. Following this rule will reduce the risk of serious personal injury. If the power supply cord is damaged, it must be replaced only by the manufacturer or by an authorized service center to avoid risk.
- Page 8 ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. The battery contains material which is hazardous to you and the environment. It must be removed and disposed of separately at a facility that accepts lithium-ion batteries.
-
Page 9: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 10: Knowing Your Blower
KNOWING YOUR BLOWER Blower small tube Lock off button On/Off trigger switch Battery pack Blower big tube Unpacking Unpack the blower and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. Please call 1-800-791-9458 or E-mail us at support@amerisuninc.com if any parts are damaged or missing. -
Page 11: Assembly Instruction
ASSEMBLY INSTRUCTIONS INSTALLING THE BLOWER TUBE CAUTION: Always ensure that the tool is switched off and the battery is removed before making any adjustments or maintenance procedures. Slide the small tube (C) over the big tube (B) until the latch on the big tube is inserted into the end of the opening on the small tube and locks into position (see fig.1) ... - Page 12 To install the battery pack To install the battery pack into the tool, align the rails of the battery pack with the rails in the tool and push the battery into the handle. To connect the battery, slide the battery pack fully forward. Until the latch locks into place.
-
Page 13: Maintenance
MAINTENANCE WARNING: In order to avoid personal injury and the risk of fire and electric shock, remove the battery pack before adjusting, inspecting, or cleaning the blower. CLEANING Remove the battery pack. Brush or blow dust and debris out of the air vents using compressed air or a vacuum. Keep the air vents free of obstructions, sawdust, and wood chips. -
Page 14: Environmentally Safe Battery Disposal
ENVIRONMENTALLY SAFE BATTERY DISPOSAL The batteries used in this blower's battery pack contain the following toxic and corrosive material: LITHIUM-ION. WARNING: Toxic materials must be disposed of in a specified manner in order to prevent contamination of the environment. Before disposing of damaged or worn out Lithium-Ion battery packs, contact your local waste disposal agency for information and specific instructions. -
Page 15: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 16 Item Stock# Description PS76101AH-001 Left front cover PS76101AH-002 Left housing PS76101AH-003 Motor PS76101AH-004 Motor retaining plate PS76101AH-005 Shock pad PS76101AH-006 Screw ST4x10 PS76101AH-007 PS76101AH-009 Button spring PS76101AH-010 Switch button PS76101AH-011 Un-locked button spring PS76101AH-012 Un-locked button PS76101AH-013 Lead wire PS76101AH-014...
- Page 17 TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
- Page 18 INSTRUCTION MANUAL 20V Cordless String Trimmer Model # PS76112A Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 20: Warranty Statement
CONTENTS Technical data…...………………………………………………………... 3 Introduction…...………………………………………………………..4 Safety information…...…………………………………………………..4 General safety rules…….………………………………………………... Specific safety rules for string trimmer………………………………… Symbols………………………………………………………………….. Knowing your string trimmer…… ..…………………………………… Assembly instruction……………………………………………………… 13 Operating instruction…………………………………………………..Maintenance.……………………………………………………………… 17 Environmentally safe battery disposal…………………………………….. 18 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty statement…………………………………………………………... -
Page 21: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 22: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your string trimmer works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 23 CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are not sure if it is, have a licensed electrician check the outlet. WARNING: Do not expose to rain or use in damp locations. Guidelines for using extension cords Make sure your extension cord is in good condition.
- Page 24 Don’t wear loose clothing or jewelry. Wear protective hair covering to contain long hair. They can be caught in moving parts. Use of rubber gloves and substantial footwear is recommended when working outdoors. Wear safety glasses with side shields or goggles that are marked to comply with ANSI Z87.1 ...
- Page 25 If you lend this tool to someone else, also lend them these instructions. BATTERY TOOL USE AND CARE WARNING: USE ONLY POWERSMART APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE MOWER. Use with POWERSMART 20V battery.
- Page 26 Always remove battery pack before storing the device. When battery becomes fully charged, unplug the charger from the power supply and remove the battery pack from the charger. Always wear eye protection with side shields marked to comply with ANSI Z87.1, along with ...
-
Page 27: Specific Safety Rules For String Trimmer
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemical: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles. SERVICE Tool service must be performed only by qualified repair personnel. -
Page 28: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 29: Knowing Your String Trimmer
KNOWING YOUR STRING TRIMMER ig.1 Trigger switch Lock off button Edger function switch Front handle Shaft adjustment lock Guide wire Edger wheel Safety guard Battery Angle adjustment button Telescopic shaft Upper shaft Front handle adjustment button Unpacking Unpack the string trimmer and all its parts, and compare against the list below. Do not discard the carton or any packaging materials. -
Page 30: Assembly Instruction
ASSEMBLY INSTRUCTIONS WARNING: Do not use this product if any parts on the packing list are already assembled to your product when you unpack it. Parts on this list are not assembled to the product by the manufacturer and require customer installation. Use of a product that may have been improperly assembled could result in serious personal injury. - Page 31 Locate the guard onto the motor housing and turn it a bit to make sure it engages into the slots on the motor housing. Note to follow the arrow direction on the guard. Then fix the guard onto the motor housing with the screw out of the package (See fig.6 and fig.7).
-
Page 32: Operating Instruction
OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this string trimmer. Failure to do so may cause serious injury or death. Do not allow anyone to operate this string trimmer who has not read this manual. A string trimmer can be dangerous if assembled or used improperly. - Page 33 Adjusting the angle of motor housing Press the angle adjustment button on motor housing, push back and forth the shaft to adjust the motor housing(7 positions) . Fig.12 Convert to edging mode The wheeled edge guide should only be used when in the edging mode.The trimmer can be used in trimming mode or edging mode to trim overhanging grass along lawn edges and flower beds.
-
Page 34: Maintenance
FITTING AND REPLACING LINE SPOOL ASSEMBLY WARNING: Remove the battery pack from string trimmer before performing adjustments. Only fit line spool recommended by the manufacturer. The line spool is already fit with the string trimmer when out of package. You need to replace it with new line when it’s used up. -
Page 35: Environmentally Safe Battery Disposal
BATTERY PACK Store the battery pack fully charged. Once the charging light turns green, remove the battery from the charger and disconnect the charger from the outlet. Do not store the battery pack on the tool. After charging, the battery pack may be stored in the charger, as long as the charger is not plugged in. ... -
Page 36: Troubleshooting
TROUBLE SHOOTING WARNING: Read instruction manual first! Remove the battery before making adjustments or assembling accessories. The following form lists the common operating system with problem and solutions. Please read the form carefully and follow it. PROBLEMS POSSIBLE CAUSES SOLUTION Motor fails to start when Check battery charger Recharge... -
Page 37: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 38 Item Stock# Description Qty. Item Stock# Description Qty. PS76112A-001 Screw ST4*16 PS76112A-030 DC motor PS76112A-002 Left rear handle PS76112A-031 Motor fixed plate PS76112A-003 Lead wire PS76112A-032 Screw M4*10 PS76112A-004 Insert base PS76112A-033 Motor bushing PS76112A-005 Right rear handle PS76112A-034 Left rotating cover Anti self locking PS76112A-006 PS76112A-035...
- Page 39 TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
