ESP12-C4243ADN
ESP016-C4237ADN
ESP16-C4237ADN
ESP12-C4243ADNP
ESP016-C4237ADNP
ESP16-C4237ADNP
ESP12-C4243ADN / ESP12-C4243ADNP
FEATURES
ESP12-C4243ADN
ESP12-C4243ADNP
1/4" Sony CCD
420 TV Lines
4.3mm Supercone Pinhole Lens
0.5 Lux (Day) / 0.05 Lux (Night)
12V DC
DIMENSIONS
ESP12-C4243ADN / ESP12-C4243ADNP
WARRANTY
Sentry Camera products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased. We have no other way
to verify the purchase record without the serial number on the camera sticker; therefore, it should not be removed.
2. Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided immediately. It is the customer's
responsibility to keep the camera in good condition.
LIST OF COMPONENTS
One (1) ESP12-C4243ADN/ESP12-C4243ADNP or ESP016-C4237ADN/ESP16-C4237ADNP or ESP16-C4237ADN/ESP16-C4237ADNP Camera
One (1) Operational Manual
* For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any
component is missing/damaged or if any cable is cut or tampered with.
Operational Manual
Supercone Pinhole Camera
with Built-in Microphone
ESP016-C4237ADN / ESP016-C4237ADNP
ESP016-C4237ADN
ESP016-C4237ADNP
1/4" Sony CCD
420 TV Lines
3.7mm Supercone Pinhole Lens
0.5 Lux (Day) / 0.05 Lux (Night)
12V DC
ESP016-C4237ADN / ESP016-C4237ADNP
Please read the Operational Manual
before attempting to use this product.
Main Cable w/ Connectors
ESP16-C4237ADN / ESP16-C4237ADNP
ESP16-C4237ADN
ESP16-C4237ADNP
1/3" Sony CCD
420 TV Lines
3.7mm Supercone Pinhole Lens
0.5 Lux (Day) / 0.05 Lux (Night)
12V DC
ESP16-C4237ADN / ESP16-C4237ADNP
ESM40-C480DN_ESM40-C420-OSD_ESM34-C420DN_rev011909
Microphone
Video Out
Audio Out
Power In 12V DC
