Diesella DT2236E User Manual

High-precision photo/contact dual-use tachometer
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
EN
INSPECTION
HIGH-PRECISION PHOTO/CONTACT
DUAL-USE TACHOMETER
SAVE THIS MANUAL
Keep this manual and the receipt of your purchase in
a safe and dry place for future reference in terms of
functions, descriptions, specifications, operation and
precautions. Write down the product serial number
on the back of the manual (or month and year of
purchase, if the product has no number).
Copyright© 2022 Diesella A/S. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Diesella A/S. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.
USER MANUAL
15117465
UNPACKING
When unpacking, make sure that the product
is intact and undamaged.
If any parts are missing or broken, please call
+45 7633 8888 as soon as possible.
