Summary of Contents for Phantom Cure Station
- Page 1 Update: July 2022 Apply once, glide forever. INSTRUCTIONS High performance base treatment to improve gliding surfaces.
- Page 2 します。 PHANTOM을 이용하여 올바르게 관리하려면 특정 UV 조명 및 온도 조건이 필요합니다. 당사는 가능하면 전문적인 적용을 추천합니다. PHANTOM trenger et bestemt UV-lys og riktige temperaturforhold for korrekt herding. Vi anbefaler at dette gjøres av en profesjonell der det er mulig. PHANTOM kräver specifika UV-ljus- och temperaturförhållanden för att härda ordentligt.
-
Page 3: Definitions Of Symbols
UV cure for skis and snowboards. The formula has been specifically designed and tested with the temperature and UV concentration and combinations of wavelengths created by this equipment. No processes other than using the cure station as described, or following the instructions for natural outdoor strong sunlight cure, should be attempted. -
Page 4: Cleaning Information
IMPORTANT Power Cable Information Please, ensure that your PHANTOM Cure Station™ is electrically rated to operate with the AC power available in your location. North America voltage: 110 VAC. Europe and Japan voltage: 220 VAC. -
Page 5: Operation
OPERATION Power Cord Inlet/Main Power Switch Preheat Start Cancel Saw Horse Door Limit Switch... - Page 6 INITIAL CURE STATION SET UP STEP 1 Install the 4 custom UV light bulbs into the light clips. Insert with pins vertical and rotate 90° until “click”. A. Best if done by two people to securely insert each end to the light clips.
- Page 7 Turn on the main power switch on the back left (A). STEP 2 Triple display button (Cure Station version 2 and up): a. With the door closed, press Preheat once. Both the heater and fan and the 4 UV lights should be on during Preheat.
- Page 8 PHANTOM 2.0 from 2018 is a two-part process requiring a Part A cure and a Part B cure. PHANTOM CSF from 2019 is offered in bulk bottles for shops and demo needs and is a one-part process with a single cure.
- Page 9 Put Equipment into Cure Station Once the surfaces have been prepared as described in Step 2, the equipment is ready to go directly into the cure station. Ensure the bases have an even, thin polished sheen, with no excess PHANTOM Glide™ anywhere along the running surface.
- Page 10 STEP Continued Maintenance A PHANTOM Glide™ treated base will continue to have consistent and fast glide as long as the base is kept in good condition. In practice, this means that some maintenance is required at regular intervals. When the bases begin to look dry/white, this is a sign that abrasion has formed micro-hairs on the base. Regular dry polishing using the PHANTOM GlideTM polishing pad and intermittent polishing with water will help keep bases clean and maintain glide performance.
- Page 11 Avoid direct UV light, except for curing inside the box. • Use protective gloves to avoid contact with skin. • PHANTOM Glide™ is harmful if ingested. Clean up spills and keep away from children and pets. • Wear protective eyewear and mask while rotobrushing. •...
- Page 12 • Take the skis/board out, and using a fresh paper towel wipe down any wet areas. Place the skis/board back in the Cure Station for another 5 - 10 minutes, or until the base(s) are 100 % dry. • For future applications more diligently work the excess PHANTOM Glide™ into the base until the base is left with a thin, even shine, leaving no excess PHANTOM Glide™...
- Page 13 HOW TO UPDATE PHANTOM CURE STATION FIRMWARE - MAC If you have any questions or concerns regarding Cure Station Firmware, please email phantomsupport@dpsskis.com. Mac Firmware Update Instructions Follow the instructions provided at the links below. Cure Station Firmware Update Instructions - MAC: https://drive.google.com/file/d/1MctXts2U2z-F1pKhnqRO7Mt5OumB7l0L/view?usp=sharing...
- Page 14 Fuse Ratings and Characteristics Miniature Fuse, 5 x 20 mm, Time-Lag T, L, 250 VAC Description IEC Standard Fuse L = Low Breaking Capacity (Glass Tube) Applications Primary Protection in Equipment Technical Data Rated Voltage: 250VAC Rated current: 0.05 - 20A Breaking Capacity: 35A - 200A Characteristic:...
