  • Page 1 Aemulus AM450e User Manual Version 1.2, 12-2013...

  • Page 2: Table Of Contents

    3.2.2 Floated Output ......................20 SECTION 4: MAINTENANCE ..................21 4.1 C ......................21 LEANING 4.2 C ......................21 ALIBRATION 4.3 S ......................21 ERVICING SECTION 5: WARRANTY ..................... 22 SECTION 6: REVISION HISTORY ................. 23 SECTION 7: CONTACT US ................... 24 AEMULUS...

  • Page 3: Safety Precautions

     If the product is used in a manner not specified, the protection provided by the instrument warranty may be impaired.  Return the instrument to Aemulus for service and repair to ensure that safety features are maintained. The WARNING heading explains hazards that might...

  • Page 4: Identification And Discouragement Of Hazardous Applications

    AM450e User Manual B. Identification and Discouragement of Hazardous Applications  Ensure that the mains power is turned off before plugging CAUTION or removing the PXI module into or from the chassis. Main Power  Make sure the power cord is plugged properly to the chassis before applying power.
  • Page 5 AM450e User Manual  The fan speed of the chassis that carries the instrument WARNING has to be in HIGH speed to allow proper heat ventilation.  Make sure the product temperature is under 46˚C before Operating operating the product.

  • Page 6: Identification Of Authorized Personnel

    AM450e User Manual C. Identification of Authorized Personnel End user Individual or group who is responsible for the use and maintenance of the product, as well as being responsible for ensuring that the product is operated within its specifications. Knowledge on electrical safety procedures and proper use of the product are prerequisite before operating the product.

  • Page 7: Section 1: Quick Start

    AM450e User Manual Section 1: Quick Start 1.1 Product Start-up Configuration Each product is carefully inspected before it leaves the factory. Upon receipt and before unpacking the product, please inspect the unit for any obvious damage that may occur during shipment.

  • Page 8: Product Software & Hardware Installation

    AM450e User Manual 1.2 Product Software & Hardware Installation Refer to AM400e installation guide. AEMULUS...

  • Page 9: Section 2: Operation

    (BNC socket) Error LED Active LED Power LED ANALOG OUTPUT (25 position D-Sub Female) Figure 1 : AM450e Front Panel Description Light up when module encounters any one of the following hardware issues: 1. Temperature sensed by the temperature sensor on the module is more than 75°C...
  • Page 10 Channel 0, Force-High Table 2: Analog Output Pin-out (Without External High Current Module) If AM450e is used without the external high current module, pins 1-7 and WARNING pins 14-18 must be left open. Do not connect these pins to device-under- test (DUT).
  • Page 11 AM450e User Manual Signal Name No Connect No Connect No Connect No Connect No Connect No Connect No Connect Channel 1, Sense-Low Channel 1, Sense-High Channel 1, Guard Channel 0, Sense-Low Channel 0, Sense-High Channel 0, Guard No Connect No Connect...

  • Page 12: Soft Front Panel

    AM450e User Manual 2.2 Soft Front Panel The soft front panel provides a graphical interface for operating the module. It is intended for testing and diagnosing, for demonstration and training, and for basic operation of the module. It represents most of the functions available in the instrument driver. It is not however a comprehensive application suitable for measurements;...
  • Page 13 AM450e User Manual Configuration panel: Output Function DC DVCI: Drive-Voltage Clamp-Current operation. Continuous mode. DC DICV: Drive-Current Clamp-Voltage operation. Continuous mode. Output Switch Enable Turn on the selected channel if the box is checked Voltage Level Voltage level V Range...

  • Page 14: Remote Operation

    AM450e User Manual 2.3 Remote Operation Refer to programming manual. AEMULUS...

  • Page 15: Section 3: Brief Technical Description

    AM450e is a source-measure unit (SMU). 3.1 Basic Operation AM450e is more than the just a power supply. It is fast-response, read-back voltage and current sources with high accuracy measurement capabilities. It is designed for circuit and device evaluation where a DC signal must be applied to a device under test (DUT) and the response to that signal measured.
  • Page 16 If a source channel reaches compliance during measurement, this indicates an error in the operation. Example: 1. AM450e is set to voltage source/current monitor mode; compliance of 1mA; output load is a 1kohm resistor 2. If source voltage is 5V, the current that should flow through the resistor is 5V/1k=5mA 3.

  • Page 17: Smu Connection

    AM450e User Manual 3.2 SMU Connection There are 5 leads per channel: 1. Guard 2. Force-High 3. Force-Low 4. Sense-High 5. Sense-Low Force-High and Force-Low outputs are where voltage and current are generated during source or sink operation. Sense-High and Sense-Low outputs are high impedance paths. Connect these lines as close to the DUT terminal as possible for more accurate voltage source or measure operations.
  • Page 18 AM450e User Manual Figure 4: Typical 5-Wire Connection AEMULUS...

  • Page 19: Guard Terminal

    AM450e User Manual 3.2.1 Guard Terminal The purpose of Guard is to reduce current leakage into sensitive node, from SMU output connector all the way to the DUT terminal, via cables, PCB, and/or test fixture. This current leakage can affect the measurement results if not being taken carefully. Measurement test time can become very long in order to fully charge up the leakage current caused by the parasitic paths, before actual test results of the DUT can be taken.
  • Page 20 AM450e User Manual Never short the guard and force line together because it will defeat the WARNING effect of the driven guard. AEMULUS...

  • Page 21: Floated Output

    AM450e User Manual 3.2.2 Floated Output AM450e is a floated SMU. This means it can be cascaded in series to produce higher voltage source, or connected in parallel to produce higher current source. 3.3 External High Current Module By adding an external module, AM450e can be used for pulse generation at 30V and 1A (pulse) range.

  • Page 22: Section 4: Maintenance

    AM450e User Manual Section 4: Maintenance 4.1 Cleaning Before doing any cleaning to the product, switch off the chassis and disconnect it from main power supply. You can wipe the front panel of the module using a soft cloth moistened in water, taking care not to wet the connectors.

  • Page 23: Section 5: Warranty

    If the product is found to be defective otherwise, Aemulus, at its option, will replace or repair the product at no charge. If you ship the product, you must assume the risk of damage or loss in transit. Aemulus may replace or repair the product with either a new or reconditioned unit, and the product returned becomes Aemulus property.

  • Page 24: Section 6: Revision History

    AM450e User Manual Section 6: Revision History JULY 2013 INITIAL RELEASE OCT 2013 ADDED OPERATING TEMPERATURE WARNING MESSAGE DEC 2013 CORRECTED PIN OUT (PIN19 IN TABLE 2 IS LEFT OPEN) AEMULUS...

  • Page 25: Section 7: Contact Us

    AM450e User Manual Section 7: Contact Us To obtain service, warranty or technical assistance, please contact Aemulus. Aemulus Aemulus Corporation Sdn. Bhd. Krystal Point, B-2-04, B-2-05, B-2-06 & B-2-07 303, Jalan Sultan Azlan Shah, 11900 Penang, Malaysia Tel: +604 6446399...
