- Page 1 JAV-1283 D-TEK ® LEAK DETECTOR Safety Instructions & Operation Manual...
-
Page 2: Table Of Contents
13 Replacing Filters ............................ 15 14 Extra-long Probe ............................ 16 15 Needle Probe Extension .......................... 16 16 Optional Sensors............................ 17 17 Cleaning and Storage .......................... 18 18 Replacement Parts and Accessories ...................... 18 19 Troubleshooting Guide.......................... 19 20 Warranty and Liability-Limitation ....................... 20 074-710-P21-B JAVAC D-TEK 3 Operating Manual... -
Page 3: Eu Declaration Of Conformity
East Syracuse, NY USA 13057 ANY QUESTIONS RELATIVE TO THIS DECLARATION OR TO THE SAFETY OF INFICON'S PRODUCTS SHOULD BE DIRECTED, IN WRITING, TO THE AUTHORIZED REPRESENTATIVE AT THE ABOVE ADDRESS. 3 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... -
Page 4: Ukca Declaration Of Conformity
East Syracuse, NY USA 13057 ANY QUESTIONS RELATIVE TO THIS DECLARATION OR TO THE SAFETY OF INFICON'S PRODUCTS SHOULD BE DIRECTED, IN WRITING, TO THE AUTHORIZED REPRESENTATIVE AT THE ABOVE ADDRESS. 4 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... -
Page 5: Cautions And Warnings
Use in an environment with flammable refrigerant concentration approaching the LEL (lower explosive limit) could cause an explosion or fire resulting in serious injury, death, or damage to property. 5 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... -
Page 6: Specifications
• Charging 0–45°C (32–113°F) • Humidity 95% RH NC maximum Altitude 2000 m (6500 ft.) Pollution degree Overvoltage category Weight (with battery; not including carrying case 0.97 lb. (0.44 kg) or accessories) 6 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... - Page 7 JAVAC To achieve optimal performance and the specified sensitivities, it is recommended to allow D-TEK 3 to run for 15 minutes prior to use. Use in temperatures below 0°C (32°F) should be limited. Extended warm-up time is recommended before use in low temperature environments.
-
Page 8: Tek 3
JAVAC D-TEK 3 | 5 5 D-TEK 3 leak indicators sensitivity indicators power indicator MODE indicator MODE button SENS/ZERO button battery door eject button 8 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... - Page 9 5 | D-TEK 3 JAVAC micro USB power input power button eject button volume button headphone jack battery door 9 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual...
-
Page 10: Charging The Battery
Charging the Battery | 6 6 Charging the Battery D-TEK 3 uses a rechargeable lithium ion battery that comes partially charged. JAVAC recommends charging the battery before use. Using the supplied charger or charging cradle accessory, a dead battery can be charged to 80% in approximately 2 hours and 100% in approximately 3 hours. -
Page 11: Turning On The Instrument And Preparing For Use
7 Turning On the Instrument and Preparing for Use If the unit does not turn on, the battery is low and needs to be charged. D-TEK 3 can be used while charging. Long press the power button (located on the left side of the body of the instrument) to turn D-TEK 3 On or Off. -
Page 12: Manual Zero Mode
Manual Zero mode requires an extra warm-up time of up to 15 minutes for optimal performance. 10 Earbuds and Volume Control A headphone jack is located on the right side of D-TEK 3 for listening to the alarm sounds through headphones or earbuds. WARNING If attempting to use headphones not supplied by JAVAC, be sure to test them carefully to avoid hearing damage. -
Page 13: Removing And Installing The Lithium Ion Battery
JAVAC 11 Removing and Installing the Lithium Ion Battery Press the eject button on the back of D-TEK 3 and remove the battery door. battery release tab eject button Remove the battery by moving the battery release tab to the side until the battery begins to eject. -
Page 14: Removing And Installing The Sensor
Removing and Installing the Sensor | 12 12 Removing and Installing the Sensor D-TEK 3 uses a cartridge style sensor that is quick and easy to remove and replace in the field. In addition to the standard sensor, JAVAC offers a CO specific sensor for use in refrigeration and air conditioning applications. -
Page 15: Replacing Filters
JAVAC 13 Replacing Filters D-TEK 3 uses a hydrophobic filter cartridge that allows air and refrigerants to pass through while filtering out water, dirt, and oil. Examine the white cloth to determine if the filter needs to be changed. If the cloth appears discolored, install a new filter. -
Page 16: Extra-Long Probe
The optional extra-long replacement probe can be used for leak checking in hard-to- reach areas. To install the extra-long probe: Unscrew the standard probe from the D-TEK 3 body using a 10 mm wrench. Screw on the extra-long probe to approximately 35 in·lb (4 N·m). Do not overtighten. -
Page 17: Optional Sensors
Removing and Installing the Sensor [} 17]. D-TEK 3 automatically recognizes the sensor type and the MODE indicator illuminates the appropriate color to indicate the sensor type the entire time the sensor is installed. Green indicates CO red indicates flammable refrigerant, and orange indicates the standard refrigerant sensor is installed. -
Page 18: Cleaning And Storage
JAVAC 17 Cleaning and Storage D-TEK 3 can be cleaned with mild detergent or isopropyl alcohol. Care should be taken to prevent cleaner from entering the instrument. Do not clean with gasoline, acetone, or other aggressive solvents as they may damage the plastic or display. -
Page 19: Troubleshooting Guide
The incorrect sensor is installed. Verify that the refrigerant sensor is installed instead of the CO sensor. The pump is not making a The pump has failed. If the battery has a proper sound. charge, contact JAVAC. 19 / 21 074-710-P21-B JAVAC D-TEK 3 Operating Manual... -
Page 20: Warranty And Liability-Limitation
MERCHANTABILITY or of FITNESS FOR A PARTICULAR PURPOSE or otherwise. All such other warranties are expressly disclaimed. JAVAC shall have no liability in excess of the price paid to JAVAC for the instrument plus return transportation charges prepaid. JAVAC shall have no liability for any incidental or consequential damages. - Page 21 EU : +44 (0)1323 848842 javac@aspenpumps.com UK : +44 (0)1642 232880 sales@javac.co.uk Aspen Pumps Ltd Aspen Pumps France Apex Way 353 Allee des Vergers Hailsham 76360 East Sussex Barentin BN27 3WA, UK France...
