Models:
LS-SLIM
LS-6-D
LS-9-D
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE.
Installation
and Operating
Instructions
727626102013
Advertisement
Summary of Contents for Parmco LS-SLIM
- Page 1 Operating Instructions Models: LS-SLIM LS-6-D LS-9-D As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE. 727626102013...
- Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to find out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...
- Page 3 CONTENTS Contents Page Important Safety Information Installation of Unit Use and Care Pre-Use Checklist Warranty Included in the packaging: Laundry cabinet and bowl All pressure single lever tap Tap connectors and water shut off valve Sink waste and overflow ...
-
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION For best performance and to extend the life of your laundry tub, we recommend that you read the instructions in this owners manual thoroughly before using your new laundry tub. It will provide you with all the information you need to ensure its safe installation, proper use and maintanence. Retain this owners manual for future reference. -
Page 5: Installation
INSTALLATION The laundry tub can be placed on either the left or right side of the washing machine. The washing machine water connections and the waste water from the washing machine can come in through three conveniently located holes on either side of the unit (fig 1). To change sides, simply unscrew the plastic fittings and replace accordingly. - Page 6 Lay the laundry tub on its back and fit the four adjustable feet (fig 3 & 4). It is important that the feet are assembled correctly as they carry the weight of the unit. Location nut Locking nut (fig 3) (fig 4) ...
- Page 7 CONNECTING TO THE WATER SUPPLY You will notice that the entire pipe assembly is unassembled. For your convenience, the pipe work has been specifically not assembled to allow you to easily change the pipe assembly to best match your particular installation situation. The directions below show one example of how to connect the cold water connection to the tub mixer tap and the washing machine cold water inlet.
- Page 8 CONNECTING THE TAP TO THE LAUNDRY TUB Lay the entire tap assembly on the floor and become familiar with its components. Main tap body Braided hoses 1 x cold Threaded securing 1 x hot Rubber washer and brass securing bracket Securing nut Hot water Cold water...
- Page 9 When installing the goose neck tap on the 90cm model please make sure the tap is orientated as per below picture with the tap handle facing the front of the unit. From the top of the laundry station carefully push through one water inlet hose first and then the other.
- Page 10 With one hand hold, the grey under-sink trap and rubber flange in place on the underside of the sink. Place the rubber gasket on the top side of the sink. Place the stainless steel drainer on top of the rubber gasket and screw it in place with the securing screw. Ensure the securing screw is done up tightly with a wide blade screwdriver in the slots provided.
- Page 11 INSTALLING THE PVC SHELF (selected models only) The shelf is made of rigid, non-rot PVC plastic. First, fix the shelf hanger brackets to the underside of the PVC shelf using the bolts and washers supplied, ensuring that the domed head of the bolt is on the top side of the PVC shelf.
-
Page 12: Pre-Use Checklist
This can cause serious damage to the ceramic discs in the tap and is not covered by warranty. Congratulations. Your Parmco laundry tub is now ready to use. - Page 13 09 573 5678 f: 09 573 5699 e: sales@parmco.co.nz w: www.parmco.co.nz Parmco Appliances 2 year warranty The Warranty: The Warranty is not valid: • If the product is not installed and operated in accordance with the operating • Subject to the terms and conditions contained within this instructions. warranty, if the product is not of Acceptable Quality (as • If the product is not installed to comply with the electrical, gas, plumbing defined in the Consumer Guarantees Act) within 2 years of and other Regulations and Codes of Practice in New Zealand. the date of original purchase, then Parmco Sales undertakes • If the product is operated on voltages or frequencies outside the normal range for domestic appliances in New Zealand. to repair or, at it’s sole discretion, replace the product. • If the product is not used in normal domestic use, or if it is used in a • The warranty does not cover the costs of transport, mileage...
