- Page 1 ASSEMBLY INSTRUCTIONS W-FRAME STARTER // 292-WF-STR Use to build a stand-alone Burnside wall system.
- Page 2 ASSEMBLY INSTRUCTIONS W-FRAME STARTER PARTS LIST: 1. End Frame - Left - (1) 2. End Frame - Right - (1) 3. Top & Bottom Rail - (2) 4. Upright Center - (1) 5. Upright Sides - (2) 6. Joint Connector Single - (6) 7.
- Page 3 ASSEMBLY INSTRUCTIONS W-FRAME STARTER COUNTERSINK HEAD SCREW STEP ONE: 1/4” - 20 X 0.625” Attach Upright Sides to Top & Bot- tom Rails using the Countersink Head Screws with Allen Wrench. STEP TWO: TOP RAIL Attach Levelers. UPRIGHT SIDE COMPLETED BOTTOM RAIL GRAND + BENEDICTS | 800.547.7005 | www.grand-benedicts.com...
- Page 4 ASSEMBLY INSTRUCTIONS W-FRAME STARTER STEP THREE: ALIGN CONNECTORS OVER THE SCORED LINES ON TOP & BOTTOM Attach the Upright Sides & Upright HEX NUT 1/4” - 20 TPI Center with the Joint Connectors using JOINT CONNECTOR BOLT 1/4” - 20 X 0.625” the Joint Connector Bolts &...
