Kidco G4200 User Manual

Extension kit for angle mount safeway g2100; g2101

Table of Contents

Download this manual

U S E R G U I D E

G2100

Angle Mount Safeway

H A R D W A R E M O U N T I N S TA L L AT I O N

Fits openings 28" – 42.5"

G2101

Extension Placement Guide

G4200 Extension Kit for Angle Mount Safeway Model G2100

G4201 Extension Kit for Angle Mount Safeway Model G2101

Note: Each kit contains one extension

Width Opening

Extensions

What You Need

28"-42 ½"

Basic Gate

No extensions

42"-52 ½"

1-G4200/4201

Gate + 1 extension

52"-63"

2-G4200/4201

Gate + 2 extensions

Placement

-1 on one end

-1 on each end
