BERJAYA CB3BGG1B-17 Service Manual

Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
CB3BGG1B-17
CB3BGG1BFS-17
Made in Malaysia
(Buatan Malaysia)
Thank you for purchasing BERJAYA product. Please read this
service manual carefully before operating the product.
Please keep this manual in a safe place for future reference.
(Terima kasih kerana membeli produk BERJAYA. Sila baca
manual penyelenggaraan dengan teliti sebelum menggunakan
produk ini. Simpankan panduan operasi ini dengan selamat
untuk rujukan masa depan.)
(SM - Open Burner, Char Broiler Griddle Combination-17 / REV 00 / 2018 / 07)
Service Manual
(Manual Penyelenggaraan)
OB4GG1B-17
OB4GG1BFS-17
Contents (Kandungan) : -
- Installation (Pemasangan) ............................
dengan Gas Asli NG .....................................
- Leak Testing (Ujian Kebocoran) .....................
- Operation (Operasi) .....................................
- Warning (Amaran) ........................................
- Cleaning (Pembersihan) ...............................
- Improvement (Peningkatan) ..........................
- Service (Perkhidmatan) ................................
- Memo (Memo) .............................................
2
2
2
3
3
4-5
4-5
6
6
7
7
7
7
8
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB3BGG1B-17 and is the answer not in the manual?

Questions and answers

Summary of Contents for BERJAYA CB3BGG1B-17

  • Page 1: Table Of Contents

    Pertukaran Diantara Gas Petroliam Cecair LPG dengan Gas Asli NG ………………………………. - Leak Testing (Ujian Kebocoran) ………………… Thank you for purchasing BERJAYA product. Please read this - Explosive Drawing (Rajah Terperinci) ………….. service manual carefully before operating the product. - Component List (Senarai Komponen) ………….

  • Page 2: Installation (Pemasangan)

    INSTALLATION (PEMASANGAN) - Installation and maintenance are to be performed by qualified person. (Pemasangan dan penyelanggaraan alat ini hendaklah dilakukan oleh wakil yang bertauliah.) - Must confirm with local codes. (Penggunaan alat ini hendaklah mematuhi peraturan-peraturan tempatan.) SITE PREPARATION (PERSEDIAAN TEMPAT) - Only install the appliance in a well ventilated place.

  • Page 3: Interconversion Of Lpg And Ng

    - The appliance must be disconnected from the gas supply piping system during any pressure testing. (Semasa ujian tekanan, alat ini mesti diasingkan dengan bekalan gas.) - A separate gas supply shut off valve must be installed up-stream of the regulator in an accessible location. (Satu lagi injap gas hendaklah dipasangkan pada tempat yang mudah dicapai.) - The gas service supply line must never be smaller than the appliance inlet line.

  • Page 4: Explosive Drawing (Rajah Terperinci)

    Step 3 (Langkah 3) - Fix the bullet feet (inserts). (Pasangkan kaki (masukkan sahaja). EXPLOSIVE DRAWING (RAJAH TERPERINCI) - OPEN BURNER GRIDDLE COMBINATION Note : This hole must in line with pilot burner. (Nota : Lubang ini mesti segaris dengan penunu pilot.) (SM - Open Burner, Char Broiler Griddle Combination-17 / REV 00 / 2018 / 07)

  • Page 5: Component List (Senarai Komponen)

    COMPONENT LIST (SENARAI KOMPONEN) - OPEN BURNER GRIDDLE COMBINATION Description (Butir-Butir) Gas Valve (Injap Gas) VA-MT10A-1 VA-MT10A-1 Burner Nozzle (Mucung Penunu) C-M10-BN C-M10-BN Pilot Control Valve Injap Kawalan Pilot) VA-MT10B-1 VA-MT10B-1 Pilot Burner Connector (Penyambung Penunu Pilot) C-BJS55 C-BJS55 Short Venturi (Leher Pendek) BR-VEN-S BR-VEN-S Long Venturi (Leher Panjang)

  • Page 6: Technical Informations (Maklumat Teknikal)

    (Model) (Penggunaan Gas) (Bth / Jam) OB4GG1B-17 106000 OB4GG1BFS-17 106000 CB3BGG1B-17 71000 CB3BGG1BFS-17 71000 OPERATION (OPERASI) Pilot Lamp (Lampu Pilot) - Our equipment are equipped with manual controlled, continuous burning pilots. The pilots are kept burning to provide the flame for burner ignition when the individual burner knobs are turned on.

  • Page 7: Warning (Amaran)

    Open Burner Pilots (Penunu Pilot Untuk Pembakar Terbuka) - Remove the burner grate. The pilot is located on each burners. One pilot valve controls two burners. (Tanggalkan penyokong atas pembakar terbuka gas. Penunu pilot terletak dekat dengan kedua-dua penunu. Pembakar terbuka injap pilot mengawal kedua-dua penunu tersebut.) - Light pilot by piezo ignitor, and test fire for both burners.

  • Page 8: Improvement (Peningkatan)

    IMPROVEMENT (PENINGKATAN) - The company reserves the right to alter the design of any appliance without prior notification. (Syarikat pembuatan berhak mengubahkan rekabentuk alat ini tanpa terlebih dahulu memberitahu pengguna.) BEFORE CALLING FOR SERVICE (SEBELUM MEMANGGIL PERKHIDMATAN PEMBAIKAN) Service calls can often be avoided. If you feel our product is not operating properly, please check these possible causes first : - (Panggilan untuk perkhidmatan pembaikan biasanya dapat dielakkan.

  • Page 9: Memo (Memo)

    MEMO (MEMO) Please fill in the following at the purchasing time for future service reference. (Sila isikan jadual yang berikut untuk rujukan perkhidmatan lepas jualan.) Model Number (Nombor Model) : Purchasing Date (Tarikh Pembelian) : Dealer's Name (Nama Pengedar) : Address (Alamat) : Home (Rumah) : Contact Number (Nombor Telefon) :...

This manual is also suitable for:

Ob4gg1b-17Cb3bgg1bfs-17Ob4gg1bfs-17
