Camera Link Range Extender
over Fiber
International Distributors
User Manual
October
2022
Sky Blue Microsystems GmbH
Geisenhausenerstr. 18
81379 Munich, Germany
+49 89 780 2970, info@skyblue.de
www.skyblue.de
- Rev
3.0
In Great Britain:
Zerif Technologies Ltd.
Winnington House, 2 Woodberry Grove
Finchley, London N12 0DR
+44 115 855 7883, info@zerif.co.uk
www.zerif.co.uk
Advertisement
Table of Contents
Related Manuals for Kaya Instruments KY-CL2F-D/H
Summary of Contents for Kaya Instruments KY-CL2F-D/H
- Page 1 Camera Link Range Extender over Fiber User Manual October - Rev 2022 International Distributors In Great Britain: Sky Blue Microsystems GmbH Zerif Technologies Ltd. Winnington House, 2 Woodberry Grove Geisenhausenerstr. 18 81379 Munich, Germany Finchley, London N12 0DR +49 89 780 2970, info@skyblue.de +44 115 855 7883, info@zerif.co.uk www.skyblue.de www.zerif.co.uk...
-
Page 2: Table Of Contents
Table of Contents Figures and Tables ..........................3 List of figures ............................3 List of tables ............................3 Revision history ..........................4 Introduction ............................5 Safety precautions ..........................5 Disclaimer ............................6 Key Features ............................7 Overview ............................7 Features ............................. 7 Product Applications .......................... - Page 3 7.2.2 KY-CL2F-D Device Unit configuration ....................18 7.2.3 KY-CL2F-H Host Unit configuration....................19 Firmware update ..........................19 IO Connector ............................20 Electrical Specifications ........................22 Absolute maximum ratings ........................ 22 Operating conditions ......................... 22 Mechanical Specifications ......................... 24 Dimensions ............................24 Weight ..............................
-
Page 4: Figures And Tables
1 Figures and Tables 1.1 List of figures 1 : KY-EXT-CL ......................... 9 IGURE EXTERNAL VIEW 2 : KY-EXT-CL LED ........................10 IGURE S DESCRIPTION 3 : KY-EXT-CL ......................11 IGURE CONNECTION DIAGRAM 4 : I SFP+ M ....................13 IGURE NSTALLING AN ODULE INTO A PORT... -
Page 5: Revision History
2 Revision history Version Date Notes 05.01.16 Initial Release 25.12.16 Minor updates and typo repairs 30.01.17 Added Additional configurations 08.04.18 Added SFP+ installation section 14.02.19 Review and minor corrections 04.08.21 Updated LED status indicators (table no.2) Document restructure for better readability 11.10.22 Updated power supply section Table 1 –... -
Page 6: Introduction
3 Introduction 3.1 Safety precautions With your Camera Link Range Extender over Fiber system (KY-EXT-CL) in hand, please take the time to read through the precautions listed below to prevent preventable and unnecessary injuries and damage to you, other personnel, or property. Read these safety instructions carefully before your first use of the product, as these precautions contain safety instructions that must be observed. -
Page 7: Disclaimer
Be sure to discharge static electricity from the body before touching any sensitive electronic components. KY-EXT-CL The electronic circuits in your computer and the circuits on the device are sensitive to static electricity and surges. Improper handling may seriously damage the circuits. In addition, do not let your clothing come in contact with the circuit boards or components. -
Page 8: Key Features
4 Key Features 4.1 Overview KAYA Instruments’ Camera Link Range Extender over Fiber system (KY-EXT-CL) solution provides a Camera Link video interface over fiber optic cable for distances up to 80km in single-mode and up to 300m in multi- mode. Optic fiber is electrically isolated, hence it does not radiate nor is it susceptible to electromagnetic interference, also eliminates the problems associated with grounding. - Page 9 Camera Link cables Fiber cables (Multi or Single mode) SFP+ modules (Multi or Single mode) www.kayainstruments.com Page no. 8 | Key Features...
-
Page 10: System Description
5.1 External View of the KY-EXT-CL system Each KY-CL2F-D/H (device/host) unit is housed in a compact, metal enclosure. Each unit has a power connector, 2 Camera Link connectors (MDR), SFP+ cage, 2 x RJ45 connectors for GPIO and a Mini USB Terminal interface, as shown in Figure 1. - Page 11 SFP+ System status LED Figure 2 : KY-EXT-CL LEDs description The System status LED, located on the Camera link side, always slow pulses in green while the system is ON. While in firmware update mode, this LED slow pulses orange. In any case of system failure, the LED will constantly light orange.
-
Page 12: Installation And Configuration
6 Error! Not a valid bookmark self-reference. 6.1 Installation procedure The KY-EXT-CL system, on the host side (KY-CL2F-H Host Unit) is connected to Camera Link Frame Grabber. On the device side (KY-CL2F-D Device Unit) the system is connected to the camera, as described in Figure 3. Camera Link Range Extender... -
Page 13: Precautions
Please, Contact KAYA Instruments’ representative for any additional module options, distance ranges, etc. 2. The SFP+ module has a bale clasp that used to remove or install the SFP+ module. 3. Close the bale clasp before inserting the SFP+ module. -
Page 14: Connecting The Interface Cable To Sfp+ Module
Figure 4 : Installing an SFP+ Module into a port 6.1.5 Connecting the interface cable to SFP+ Module In order to properly connect the fiber optic cables, the following steps must be taken: 1. Remove the dust cups from the module as shown in Figure 5. 2. -
Page 15: Removing The Sfp+ Module
Figure 6 : SFP+ Module with TX output and RX input marked Figure 7 : Connecting the cable to SFP+ Module 6.1.6 Removing the SFP+ Module In order to remove the SFP+ module, follow these steps: 1. Turn the camera and the computer off. 2. -
Page 16: Completing The Ky-Ext-Cl System Installation
Figure 9 : Removing an SFP+ Module from the port Figure 10 : SFP+ Module with bale clasp open 6.2 Completing the KY-EXT-CL system installation In order to properly complete the KY-EXT-CL system installation, the following steps must be taken: 1. -
Page 17: Reducing The Fiber Optic Cable Count
3. Connect the Power Adaptor to the KY-CL2F-D and KY-CL2F-H power supply connector. The KY-EXT-CL (Host and Device) requires 12V power supply for proper function for camera. Please, refer section 8.2 of this document for exact Power Supply requirements. 4. Connect the power supply to the camera (Regardless of the cameras PoCL support). 5. - Page 18 Camera Link Range Extender Power Device unit supply Camera Link CL cables Camera Link Frame Grabber Fiber cable CL cables Power supply (optional) Camera Link Range Extender Host unit Figure 12 : Bidirectional Camera link connection www.kayainstruments.com Page no. 17 | Error! Not a valid bookmark self-...
-
Page 19: Firmware
7 Firmware 7.1 Terminal control A Mini USB port is available for individual link & general information status and firmware update. The port uses a Silabs CP2101 chip. A driver from the Silabs website might have to be installed on certain PCs to gain access terminal port. -
Page 20: Ky-Cl2F-H Host Unit Configuration
NOTE: The commands are not case sensitive. 7.2.3 KY-CL2F-H Host Unit configuration In order to format the system, choose the required command sequence: Command Description Available options 1- Base mode 2- Medium mode mode 3- Full mode format 4- Deca10(8Taps) mode 5- Deca8(10Taps) mode 1- AreaScan type... -
Page 21: Io Connector
6. At this point all the LEDs will turn off and the “System status LED” will slow pulse orange indicating the extender is ready to receive the firmware binary file. Under “File” tab use the terminal “transfer” capability using the XMODEM protocol to initiate the firmware update. Choose “Send” and the firmware version: cl_ext_device_x_xx.rbf or cl_ext_host_x_xx.rbf, depending on the chosen extender, when x_xx is the version number. - Page 22 Figure 13 : Serial RJ45 connector diagram www.kayainstruments.com Page no. 21 | Firmware...
-
Page 23: Electrical Specifications
8 Electrical Specifications 8.1 Absolute maximum ratings Specification Values Power supply voltage 10V to 14V Storage Temperature -40°C to 85°C Operating Temperature 0°C to 50°C (Commercial) -40°C to 70°C (Industrial) (optional) Opto Isolated input voltage -6V to 60V Opto Isolated output voltage -7V to 70V Opto isolated output current 150mA max... - Page 24 Symbol Parameter Condition Typical Units = 100 Ω (RS422) Differential Output Voltage = 54 Ω (RS485) Change in Magnitude of VOD for ∆V Complementary = 100 Ω / 54 Ω 0.01 Output States Change in Magnitude of VOS for ∆V Complementary = 100 Ω...
-
Page 25: Mechanical Specifications
9 Mechanical Specifications 9.1 Dimensions Each KY-EXT-CL unit is housed in a metal enclosure. The exact dimensions of the enclosure are as shown in the images below: Figure 14 : External dimensions of the KY-EXT-CL Camera Link side panel Figure 15 : External dimensions of the KY-EXT-CL Fiber side panel www.kayainstruments.com Page no. -
Page 26: Weight
Figure 16 : External dimensions of the KY-EXT-CL enclosure box 9.2 Weight Each KY-EXT-CL unit weights 356g. (metal enclosure weights 235g.) www.kayainstruments.com Page no. 25 | Mechanical Specifications... -
Page 27: Appendices
10 Appendices 10.1 Camera Link cables Camera Link® is a robust communications link using a dedicated cable connection and a standardized communications protocol. Camera Link is a hardware specification that standardizes the connection between cameras and frame grabbers. It defines a complete interface which includes provisions for data transfer, camera timing, serial communications, and real time signaling to the camera. -
Page 28: Ordering Information
Fiber cable (*) KY-FCA-XX.X Table 18 : Ordering Information (*) Please contact KAYA Instruments for exact Part Number or refer to our website at: www.kayainstruments.com/category/products/cables-assembly/ We are offering variety of modules and customized cable assembly, to fit your application exact needs.
