Please first read this manual carefully.
front side - Installing a G-Motion motor unit on
a Qurails 6200 curtain rail system.
back side - Setting end positions.
1
Overview components
slide lock
gear,
connects to
curtain track
pulley
slide out
cover for
cabling:
LED
cover : remove to access connector-area
and basic controlling buttons
2
Identification motor type
i
- click -
GM-1xx-xxxx / xxxxx
IP40
RoHS
CID:
SW:
HW:
PD:
100-240V ~1.5A 50-60Hz
Made in the Netherlands
(example)
"1"
("4" or "6" : see other Quickmanual GM4 / GM6)
3
Connector area
connector for
Light sensor
connector for
- IR receiver
- switch / dry contact
- GM-Bus
4
Adjust blocking positions
( Split stack: )
5
Mounting motor unit
1.
connectors for
Tandem
(optional add-on)
3.
2 basic controlling
buttons
6
Powering
( If needed )
First use: if NOT mounted on a 6200 rail system,
!
the motor unit runs in one direction only.
2.
4.
Set end
positions
