Summary of Contents for Projoy Electric PEDH Series
- Page 1 User Manual PEDH Series Molded Case DC Switch www.projoy-electric.com V1.0 20220720...
-
Page 2: Table Of Contents
PEDH Series Molded Case DC Switch CONTENTS Molded Case DC Switch User Manual 1 General 2 Usage Information 3 Product Overview 4 Certificates 5 Product Model 6 Product Features 7 Technical Parameters 8 Dimensions PEDH-315/2P 160~315A PEDH-315/3P 160~315A PEDH-315/4P 160~315A... -
Page 3: General
3 Product Overview The PEDH series isolation switch is developed and designed by Projoy Electric Co., Ltd. using the modular concept. The switch body is assembled with special modules and new appearance design which reduces the exposed metal parts of the switch body and improves the safe operation performance;... -
Page 4: Product Model
PEDH Series Molded Case DC Switch 5 Product Model PEDH 1500 Projoy Electric Rated Voltage DB Dinrail Board Rated Current Number of Poles High Current 1000/1500V DC Door Clutch 160/200/ N=2,3,4 250/315A 6 Product Features Safe isolation 1) Visualization window: The opening and closing positions of the moving contacts are clearly visible, providing a higher level of safety assurance;... -
Page 5: Dimensions
PEDH Series Molded Case DC Switch 8 Dimensions PEDH-315/2P 160~315A a) The mechanism is in the middle b) The mechanism is on the left PEDH-315/3P 160~315A a) The mechanism is in the middle www.projoy-electric.com... -
Page 6: Pedh-315/4P 160~315A
PEDH Series Molded Case DC Switch PEDH-315/3P 160~315A b) The mechanism is on the left PEDH-315/4P 160~315A a) The mechanism is in the middle b) The mechanism is on the left www.projoy-electric.com... -
Page 7: Pedh-630/2P 315~500A
PEDH Series Molded Case DC Switch PEDH-630/2P 315~500A a) The mechanism is in the middle b) The mechanism is on the left PEDH-630/3P 315~500A a) The mechanism is in the middle www.projoy-electric.com... -
Page 8: Pedh-630/4P 315~500A
PEDH Series Molded Case DC Switch PEDH-630/3P 315~500A b) The mechanism is on the left PEDH-630/4P 315~500A a) The mechanism is in the middle b) The mechanism is on the left www.projoy-electric.com... -
Page 9: Wiring Diagram
PEDH Series Molded Case DC Switch Parallel Cooper Bar a) PEDH-315 160~315 b) PEDH-630 315~500 9 Wiring Diagram Wiring method 1 Wiring method 2 Wiring method 1 Wiring method 2 Wiring method 1 Wiring method 2 Wiring method: 2 circuits... -
Page 10: Attachment
PEDH Series Molded Case DC Switch Wiring Auxiliary switches are two sets of one normally open and one normally closed contact. The lead wire is 1.5mm2 copper wire, and the wire length is 150mm. 11 Attachment Installation dimension of operating handle outside the cabinet (mm) φ31...
