Summary of Contents for SUPERNOVA MOD-1614D
- Page 1 © 2023 Order #XXXXX MOD-1614D Double-Sided Lightbox 10’ 20’ Plan View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
-
Page 2: General Setup Instructions
© 2023 Order #XXXXX General Information General Setup Instructions - Read entire setup instruction manual prior to WARNING unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly. - Page 3 © 2023 Order #XXXXX CEI152 Frame Assembly Slide both connectors across seam of extrusions. Disassembly Tighten all knobs. Straight Connection 1) Loosen all knobs. Straight Connector When assembling frame, first attach all straight 2) Slide connectors off of one extrusion. connectors, then attach corner connectors.
- Page 4 © 2023 Order #XXXXX SEG Installation Graphic Removal Corner A Corner B Corner D Corner C Step 1 Step 2 Step 3 It is important to first insert To remove the graphic from Insert corner A. Turn edge of Repeat Step 1 for opposite Once all corners are inserted, graphic into each alternate the frame, locate the fabric...
- Page 5 © 2023 Order #XXXXX Case Packing Top View of Each Level 9A,9 8,8A 1,1,1 Level 1 Level 2 Level 3 (Bottom level) Case 1 of 3...
- Page 6 © 2023 Order #XXXXX Case Packing Top View of Each Level Graphics Setup Hardware Level 1 Level 2 (Bottom level) Case 2 of 3...
- Page 7 © 2023 Order #XXXXX Case Packing Top View of Each Level Graphics Level 1 Level 2 (Bottom level) Case 3 of 3...
-
Page 8: Front View
© 2023 Order #XXXXX Lightbox Assembly Steps: Item Qty. Description Base Plate Refer to the CEI152 Frame Assembly general information page. 2/2A 47.5” CEI152 Horizontal Extrusion 1) Attach U-Channels to horizontals [2,6]. See U-Channel Attachment detail. 3/3A 45” CEI152 Horizontal Extrusion 2) Assemble horizontals [2-3-4-5-6], [2A-3A-4A-5A-6A] &... - Page 9 Lightbox Attachments Steps: Light to Light Attachment Light to Transformer Attachment PR63 Attachment 1) Attach power cords to Supernova lights as shown. 2) Attach PR63 conduit to extrusions for wire managment. 1) Run cords through PR63 plastic conduit. Male Female...
