AMERI-KING CORPORATION

17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email:

ameriking9@aol.com

Document number: OM-TS-451 Rev. NC-10

OPERATION MANUAL

FOR 406MHz ELT TEST SET TS-451

TABLE OF CONTENT

1. Coding using BMEP ....................................................................................................................... 8

2. ELT Coding Programming, ID Reader and Maintenance Test ...................................................... 14

3. ELT Maintenance Self-Test ........................................................................................................... 155

4. Functional Test, GPS Position Coordinates Simulation................................................................. 156

5. Table 1: Country codes in Hex format ........................................................................................... 4

6. Table 2: Modified-Baudot Code ..................................................................................................... 6

7. Table 3: Hexadecimal to Binary conversion table.......................................................................... 7

8. Table 4: List of all available Protocols............................................................................................ 152

9. How to transfer 15-digit hex ID from your old ELT to the new Ameri-King ELT ............................ 145

10. Short Message Reprogramming Examples:

Example 1: How to change Country from U.S.A. (369) to Brazil (710)

- Serial User with the same 24-bit address 403C41 (Short message) .............................................. 22

Example 2: How to change Country from U.S.A. (369) to Brazil (710)

- Serial User with the same Serial Number 392 (Short message) ..................................................... 28

Example 3: How to change Country from U.S.A. (369) to Brazil (710)

- Aviation User with the same Tail Number N-13FY (Short message) .............................................. 34

Example 4: How to change from U.S.A. Serial User 24-bit Aircraft Address AF0F0F

to Brazil Serial User with 24-bit address ABCDE9 (Short message)................................................. 40

Example 5: How to change from U.S.A. Serial User 24-bit Aircraft Address AF0F0F

to Brazil Serial User with Serial Number 392 (Short message) ......................................................... 48

Example 6: How to change from U.S.A. Serial User 24-bit Aircraft Address AF0F0F

to Brazil Aviation User with Tail Number ABC-DEF (Short message) ............................................... 56

Table of Contents

Need help?

Do you have a question about the TS-451 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ameri-King TS-451

Page 1: Table Of Contents
7. Table 3: Hexadecimal to Binary conversion table................7 8. Table 4: List of all available Protocols.................... 152 9. How to transfer 15-digit hex ID from your old ELT to the new Ameri-King ELT ......145 10. Short Message Reprogramming Examples: Example 1: How to change Country from U.S.A.
Page 2 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Example 7: How to change from U.S.A. Serial User Serial Number 392 to Brazil Serial User Serial Number 656 (Short message) ..............63 Example 8: How to change from U.S.A.
Page 3 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com This page is intentionally left blank.
Page 4 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Country code Country code Country code Country code Country code Country Binary Binary format format format format in Decimal number...
Page 5 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com This page is intentionally left blank.
Page 6 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com TABLE 2: Modified-Baudot Code...
Page 7 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 0000 0001 0010 0011 0100 0101 0110 0111 1000 1001 1010 1011 1100 1101 1110 1111 TABLE 3: Hexadecimal to Binary conversion table...
Page 8 CODING USING AMERI-KING BEACON MESSAGE ENCODE PROGRAM (BMEP) Beacon Message Encode Program (BMEP) is Ameri-King’s proprietary software used solely for the purpose of encoding and decoding ELT hex codes. Please read the accompanied End-User License Agreement for all the terms and conditions before you start using BMEP.
Page 9 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 3. Choose a location for the installation, or just leave it as is 4. Click “Next”...
Page 10 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 5. Wait for the installation to finish 6. Click “Close”...
Page 11 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Run the software for first time: 1. Click on START Programs PLK Solutions BMEP BMEP (by default) 2. You will be prompted to enter your company’s name and the Key.
Page 12 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 3. Upon successful Licensing activation, you will see the program. How to use BMEP: 1. There are a total of 5 protocols supported in this software. They are as follows:...
Page 13 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 2. For demonstration purposes, let’s say you choose 1 - Non-Location, Serial User Protocol: Beacon Serial Number (Short message). You should get the screen below: 3.
Page 14: Elt Coding Programming, Id Reader And Maintenance Test
These tests should be performed only within an RF Screen Room or Facility providing shielding of RF Emissions. Ameri-King Test Set should include the following: • 2 cables: USB to DB9/Serial cable (“Cable 1”) (gray color) and DB9/Serial to RJ12 (“Cable 2”) (white color)
Page 15 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Windows Vista and Windows 7: a. Install the driver for Cable 1 by running: Serial to USB Cable Driver Win Vista and 7 Driver Installer.exe b.
Page 16 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 2. Run the Hyper Terminal program for the first time a. Go back to the Software CD double click “AK451 Hyper Terminal (Win XP, Win Vista, and Win 7)”...
Page 17 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com b. When the ELT is connected and the Main Switch is at ARM position, the following should display:...
Page 18 Within 20 seconds, type the password then press “Enter” Note 1: Please contact Ameri-King via email, fax or phone for the password. Note 2: If there is no input within 20 seconds, the ELT will enter the Self-Test mode, and you cannot program the ELT.
Page 19 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 3.4 To program ELT: Short message (22-digit hex), type 06 -22 xxxxxxxxxxxxxx Enter Long message (30-digit hex), type 06 -30 xxxxxxxxxxxxxx Enter where xxxxxxxxxxxxxx is the Hex code (see Figure 2 and Figure 3).
Page 20 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Figure 3...
Page 21 • Protocol required (See Table 4 for List of all available Protocols) • 24 Bit aircraft address or Aircraft Tail Number, if applicable Ameri-King shall provide the 22-digit Hex ID (Short Message) or 30-digit Hex Digit ID (Long Message) accordingly.
Page 22: Example 1: How To Change Country From U.s.a. (369) To Brazil (710) - Serial User With The Same 24-Bit Address 403C41 (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 23 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 24 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 25 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: To convert the above template to hex format, there are 2 ways: 1. Manually using “TABLE 3: Hexadecimal to Binary conversion table” on page 7.
Page 26 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 27 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Replace B65FCD with B45139 in the 22-digit hex code. We should get the following: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 28 Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 29 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 30 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 31 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: To convert the above template to hex format, there are 2 ways: 1. Manually using “TABLE 3: Hexadecimal to Binary conversion table” on page 7.
Page 32 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 33 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Replace BECF05 with C13905 in the 22-digit hex code. We should get the following: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 34: Example 3: How To Change Country From U.s.a. (369) To Brazil (710
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 35 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 36 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 37 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 2. Automatically using Calculator program in Windows to convert the binary code to hex format. To use Calculator to convert follow these steps: Step a: Open the Calculator.
Page 38 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 39 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Replace C03C33 with BFCA39 in the 22-digit hex code. We should get the following: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 40: Example 4: How To Change From U.s.a. Serial User 24-Bit Aircraft Address Af0F0F To Brazil Serial User With 24-Bit Address Abcde9 (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 41 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 42 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the 24-bit address to ABCDE9.
Page 43 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your binary 24-bit address into the following template: 0110111 Replace these numbers with 111111101000111111001111 your binary 24-bit address Step 6: Convert the entire template to binary.
Page 44 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step b: Paste the template to the calculator in Binary mode Step c: Click on “Hex” to convert the binary code to hex...
Page 45 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step d: Copy the hex code Step 7: Replace 6F5E1E1E with 6F579BD2 in the 22-digit hex code. We have: As we can see, the 24-bit address is now correct (ABCDE9), but Encoded BCH1 and Calculated...
Page 46 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 8: To fix Encoded BCH1 and Calculated BCH1, use the below template: 100000100111001000001 Replace these digits with Calculated BCH1 (bits N/A) Step 9: Convert the entire template to hex format using Calculator.
Page 47 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 11: To program the ELT, we enter: 06 -22 6C66F579BD20166C99DE50 Note: 06 = write ID command -22 = length of ID...
Page 48: Example 5: How To Change From U.s.a. Serial User 24-Bit Aircraft Address Af0F0F To Brazil Serial User With Serial Number 392 (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 49 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 50 Serial Number 392. Step 4: Convert your Serial Number 392 (in decimal format) to binary format using the conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (the same way we convert Country code from decimal to binary).
Page 51 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your 20-digit Serial Number in binary format into the following template: 0110001 11111110100011111100 Replace these numbers with...
Page 52 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step b: Paste the template to the calculator in Binary mode Step c: Click on “Hex” to convert the binary code to hex...
Page 53 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step d: Copy the hex code Step 7: Replace 6F5E1E1 with 6200310 in the 22-digit hex code. We have: As we can see, the Serial Number is now correct (392), but Encoded BCH1 and Calculated...
Page 54 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 8: To fix Encoded BCH1 and Calculated BCH1, use the below template: 100000100111001000001 Replace these digits with Calculated BCH1 (bits N/A) Step 9: Convert the entire template to hex format using Calculator.
Page 55 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 11: To program the ELT, we enter: 06 -22 6C66200310E0166DCDEF50 Note: 06 = write ID command -22 = length of ID...
Page 56: Example 6: How To Change From U.s.a. Serial User 24-Bit Aircraft Address Af0F0F To Brazil Aviation User With Tail Number Abc-Def (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 57 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 58 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the 24-bit address to Tail Number ABC-DEF.
Page 59 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your modified-baudot code into the following template: Replace these numbers with 100011111110100011111100111100001010010000 your 42-digit binary Tail...
Page 60 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step b: Paste the template to the calculator in Binary mode Step c: Click on “Hex” to convert the binary code to hex...
Page 61 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step d: Copy the hex code Step 7: Replace 6F5E1E1E0166 with 3C67731961B0 in the 22-digit hex code. We have: As we can see, the Tail Number is now correct (ABC-DEF), but Encoded BCH1 and Calculated...
Page 62 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 8: To fix Encoded BCH1 and Calculated BCH1, use the below template: 100000100111001000001 Replace these digits with Calculated BCH1 (bits N/A) Step 9: Convert the entire template to hex format using Calculator.
Page 63: Example 7: How To Change From U.s.a. Serial User Serial Number 392
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 64 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 65 392 to 656. Step 4: Convert your Serial Number 656 (in decimal format) to binary format using the conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (the same way we convert Country code from decimal to binary).
Page 66 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your 20-digit Serial Number in binary format into the following template: 0110001 11111110100011111100 Replace these numbers with...
Page 67 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step b: Paste the template to the calculator in Binary mode Step c: Click on “Hex” to convert the binary code to hex...
Page 68 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step d: Copy the hex code Step 7: Replace 6200310 with 6200520 in the 22-digit hex code. We have: As we can see, the Serial Number is now correct (656), but Encoded BCH1 and Calculated...
Page 69 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 8: To fix Encoded BCH1 and Calculated BCH1, use the below template: 100000100111001000001 Replace these digits with Calculated BCH1 (bits N/A) Step 9: Convert the entire template to hex format using Calculator.
Page 70: Example 8: How To Change From U.s.a. Serial User Serial Number 392
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 71 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 72 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the Serial Number 392 to 24-bit address AF0F0F.
Page 73 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your binary 24-bit address into the following template: 0110111 111111101000111111001111 Replace these numbers with your binary 24-bit address Step 6: Convert the entire template to binary.
Page 74 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 75 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 62003100 with 6F5E1E1E in the 22-digit hex code. We have: As we can see, the 24-bit address is now correct (AF0F0F), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 76 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace BECF05 with B8F0DD in the 22-digit hex code. We have: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 77: Example 9: How To Change From U.s.a. Serial User Serial Number 392
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 78 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 79 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the Serial Number 392 to 24-bit address AF0F0F.
Page 80 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your modified-baudot code into the following template: Replace these numbers with 100011111110100011111100111100001010010000 your 42-digit binary Tail...
Page 81 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step b: Paste the template to the calculator in Binary mode Step c: Click on “Hex” to convert the binary code to hex...
Page 82 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step d: Copy the hex code Step 7: Replace 620031000166 with 3C67731961B0 in the 22-digit hex code. We have: As we can see, the Tail Number is now correct (ABC-DEF), but Encoded BCH1 and Calculated...
Page 83 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 8: To fix Encoded BCH1 and Calculated BCH1, use the below template: 100000100111001000001 Replace these digits with Calculated BCH1 (bits N/A) Step 9: Convert the entire template to hex format using Calculator.
Page 84: Example 10: How To Change From U.s.a. Aviation User Tail Number Abc-Def To Brazil Aviation User Tail Number Gfed-Cb (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 85 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 86 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the Tail Number to GFED-CB.
Page 87 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your modified-baudot code into the following template: Replace these numbers with 100011111110100011111100111100001010010000 your 42-digit binary Tail...
Page 88 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 89 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 3C67731961B0 with 35ED864C5D98 in the 22-digit hex code. We have: As we can see, the Tail Number is now correct (GFED-CB), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 90 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace FDEE79 with 8B0909 in the 22-digit hex code. We have: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 91: Example 11: How To Change From U.s.a. Aviation User Tail Number Abc-Def To Brazil Serial User 24-Bit Address Af0F0F (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 92 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 93 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 22-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change Tail Number ABC- DEF to 24-bit address AF0F0F.
Page 94 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Convert the entire template to binary. You can use the Calculator in Windows to convert. Step a: Open the Calculator. Then go to View -> Scientific...
Page 95 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 96 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 3C677319 with 6F5E1E1E in the 22-digit hex code. We have: As we can see, the 24-bit address is now correct (AF0F0F), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 97 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace FDEE79 with D1C9E9 in the 22-digit hex code. We have: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 98: Example 12: How To Change From U.s.a. Aviation User Tail Number Abc-Def To Brazil Serial User Serial Number 392 (Short Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 99 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 100 DEF to Serial Number 392. Step 4: Convert your Serial Number 392 (in decimal format) to binary format using the conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (the same way we convert Country code from decimal to binary).
Page 101 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Copy and paste your 20-digit Serial Number in binary format into the following template: 0110001 Replace these numbers with...
Page 102 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 103 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 3C677319 with 6200310 in the 22-digit hex code. We have: As we can see, the Serial Number is now correct (392), but Encoded BCH1 and Calculated BCH1 are not yet identical.
Page 104 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace FDEE79 with BB1439 in the 22-digit hex code. We have: Since the values of Encoded BCH1 and Calculated BCH1 are exactly the same, the above 22- digit hex is valid.
Page 105: Example 13: How To Change Country From U.s.a. (369) To Brazil (710
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 106 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 107 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 30-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 108 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: To convert the above template to hex format, there are 2 ways: 1. Manually using “TABLE 3: Hexadecimal to Binary conversion table” on page 7.
Page 109 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 110 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Replace E24B0B with B45139 in the 30-digit hex code. We should get the following: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 111: Example 14: How To Change Country From U.s.a. (369) To Brazil (710
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 112 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 113 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 30-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 114 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: To convert the above template to hex format, there are 2 ways: 1. Manually using “TABLE 3: Hexadecimal to Binary conversion table” on page 7.
Page 115 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 116 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Replace FCA3D3 with 8355DB in the 30-digit hex code. We should get the following: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 117: Example 15: How To Change Country From U.s.a. Standard Location With 24-Bit Address Af0F0F To Brazil Standard Location With 24-Bit Address Abcde9 (Long Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 118 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 119 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 30-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change the 24-bit address...
Page 120 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 4: Replace AF0F0F in the 30-digit hex with ABCDE9. We have: As we can see, the 24-bit address is now correct (ABCDE9), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 121 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: To convert the above template to hex format, there are 2 ways: 1. Manually using “TABLE 3: Hexadecimal to Binary conversion table” on page 7.
Page 122 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 123 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace E24B0B with D6E267 in the 30-digit hex code. We should get the following: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 124 Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 125 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 126 AF0F0F to Serial Number 392. Step 4: Convert your Serial Number 392 (in decimal format) to binary format using the conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (the same way we convert Country code from decimal to binary).
Page 127 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Use the below template: 0100 Replace these digits with your 0010110011 14-digit binary Serial Number 01111100001111 Step 6: Use Calculator program in Windows to convert the above template to hex format.
Page 128 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 129 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 3AF0F0F with 42CC188 in the 30-digit hex code. We should get the following: As we can see, the Serial Number is now correct (392), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 130 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace E24B0B with 8355DB in the 30-digit hex code. We have: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 131: Example 17: How To Change Country From U.s.a. Standard Location With Serial Number
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 132 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 133 392 to 656. Step 4: Convert your Serial Number 656 (in decimal format) to binary format using the conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (the same way we convert Country code from decimal to binary).
Page 134 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Use the below template: 0100 Replace these digits with your 0010110011 14-digit binary Serial Number 01111100001111 Step 6: Use Calculator program in Windows to convert the above template to hex format.
Page 135 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 136 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 42CC188 with 42CC290 in the 30-digit hex code. We should get the following: As we can see, the Serial Number is now correct (656), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 137 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace FCA3D3 with DCEEDF in the 30-digit hex code. We have: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 138: Example 18: How To Change Country From U.s.a. Standard Location With Serial Number 392 To Brazil Standard Location With 24-Bit Address Abcde9 (Long Message)
Step a: Convert your desired country code (in this example 710) from decimal format to binary format: Use the included conversion tool “451 OM-TS-451 Decimal and Binary Conversion Tool.mht” or go to http://acc6.its.brooklyn.cuny.edu/~gurwitz/core5/nav2tool.html (Internet browser is required) to convert your desired country code (in decimal format) to binary format NOTE: You must click on “Try it again!”...
Page 139 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Enter your desired country code in decimal format here Your desired country code in binary format will appear here Click on this button to...
Page 140 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Input the 30-digit hex code into the 406 MHz Decode Program provided. See below: As we can see, the country code is now correct (710). Next, we must change Serial Number 392 to 24-bit address ABCDE9.
Page 141 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 6: Use Calculator program in Windows to convert the above template to hex format. To use Calculator to convert follow these steps: Step a: Open the Calculator.
Page 142 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step c: Click on “Hex” to convert the binary code to hex Step d: Copy the hex code...
Page 143 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 7: Replace 42CC188 with 3ABCDE9 in the 30-digit hex code. We should get the following: As we can see, the 24-bit address is now correct (ABCDE9), but BCH1 Encoded and BCH1 Calculated are not yet identical.
Page 144 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 10: Replace FCA3D3 with D6E267 in the 30-digit hex code. We have: Since the values of BCH1 Encoded and BCH1 Calculated are exactly the same, the above 30- digit hex is valid.
Page 145 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com How to transfer 15-digit hex ID from your old ELT to the new Ameri-King ELT Step 1: Determine whether your 15-digit hex represents Long Message or Short Message Protocol. To...
Page 146 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com If bit 26 reads 0, your 15-digit hex represents Long Message (see below): Step 2: Connect your new Ameri-King ELT to Hyper Terminal software and switch the ELT to ARM position...
Page 147 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 3: Quickly enter the password within 20 seconds (please contact us for the password). If successful you should see the following screen:...
Page 148 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 4: a. If your 15-digit hex represents Short Message, enter the following command: 06 –s xxxxxxxxxxxxxxx Your 15-digit hex...
Page 149 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com b. If your 15-digit hex represents Long Message, enter the following command: 06 –l xxxxxxxxxxxxxxx Your 15-digit hex You should see the Success screen if you do it correctly. Please see the sample below:...
Page 150 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Step 5: Make sure your new Ameri-King ELT has been successfully programmed with your old 15-digit hex, enter the following command: ENTER...
Page 151 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com If your 15-digit hex represents Long Message you should see the following screen:...
Page 152 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com TABLE 4. List of all available Protocols ELT Non- Location Protocols...
Page 153 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com User Location Location Protocols Protocols...
Page 154 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Standard Location Protocols Location Protocols National Location Protocols http://www.cospas-sarsat.org/BeaconsTutorial/tutorial_map.htm...
Page 155 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com 3. ELT Maintenance Self-Test: To perform ELT Maintenance Self-Test: Use command “ 05 “ Figure 6: Maintenance Self-Test Maintenance Test includes the following tests: VHF: PLL locked PLL locked in F3 or F1 or F2 at fault (9 flashes) VHF: Power output level F1/F2 VHF RF power level <...
Page 156 4. Functional Test, GPS Position Coordinates Simulation: (Ref.: E6557-CS Annex-E, Page 7) (Table F-D-2) In this example, the “Ameri-King GPS Location” file is on the desktop which contains the coordinate of a location. Note: You can use Notepad Editor Program to modify the coordinate of this location.
Page 157 Ameri-King GPS Location.) Set the switch of the ELT to “ON” position. Single-Click on “Open” button to insert the coordinate of Ameri-King GPS Location to the ELT. DO NOT turn the ELT off. Wait for 50 seconds and you will receive 30 Hex digits (Ignore the first 6 digits) coming from the ELT that contains the coordinate of the Ameri-King GPS Location (See Figure 10).
Page 158 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com • To verify the coordinate in the 30 Hex digits message: o Double-click on “406MHz Decode” Icon to open up the 406MHz Decode Program (See Figure 11) o Enter last 30Hex digits (last 30 digits of 36) into the 406 MHz Decode Program.
Page 159 AMERI-KING CORPORATION 17881 Sampson Lane, Huntington Beach, CA 92648 - Tel (714) 842-8555 - Fax (714) 842-4235 - Email: ameriking9@aol.com Figure 11 NOTE: BCH 1 Encoded and BCH 1 Calculated MUST have the same value BCH 2 Encoded and BCH 2 Calculated MUST have the same value...
