Summary of Contents for Explorer QRZ-1
- Page 1 User’s Manual Dot-Matrix LCD Display Multiple Key Lock Setting Multi-Display Mode Dual Band Dual Wait Dual Standby 200 Channels Battery Saving CTCSS...
- Page 2 200 channels storage and scanning THANK YOU FM Radio and 24 stations memory Wide/Narrow band selectable VOX 0-7 level setting for purchasing the Explorer QRZ-1 CTCSS and scanning Transceiver. After reading this manual Shortcut menu operation mode you will have an understanding of the features of this radio.
-
Page 3: Table Of Contents
MENU STRUCTURE----------------------------------------------------------------------- 25-28 Tone Mode----------------------------------------------------------------------------- Tone Sel-------------------------------------------------------------------------------- WHAT’S IN THE BOX----------------------------------------------------------------------- Repeater------------------------------------------------------------------------------- CHARGING BATTERY PACK------------------------------------------------------------- Squelch-------------------------------------------------------------------------------- INSTALLATION OF ACCESSORIES---------------------------------------------------- Dual RX-------------------------------------------------------------------------------- THE BASICS---------------------------------------------------------------------------------- Lamp Mode--------------------------------------------------------------------------- Simplex----------------------------------------------------------------------------- Brightness----------------------------------------------------------------------------- Repeaters----------------------------------------------------------------------- 11-12 Beep------------------------------------------------------------------------------------ Transmit Frequency------------------------------------------------------------- Power---------------------------------------------------------------------------------- Offset---------------------------------------------------------------------------- 13-14 Battery--------------------------------------------------------------------------------- Offset Direction------------------------------------------------------------------- VOX------------------------------------------------------------------------------------ CTCSS------------------------------------------------------------------------------ VOX Level----------------------------------------------------------------------------- Squelch----------------------------------------------------------------------------- Scan Mode----------------------------------------------------------------------------... - Page 4 MENU STRUCTURE (CONT.) Time Out------------------------------------------------------------------------------- Step------------------------------------------------------------------------------------- Nar/Wide------------------------------------------------------------------------------- Tone Scan----------------------------------------------------------------------------- Lock Mode----------------------------------------------------------------------------- Disp Mode----------------------------------------------------------------------------- Dual Watch---------------------------------------------------------------------------- Reset----------------------------------------------------------------------------------- Firmware------------------------------------------------------------------------------ KEYPAD LOCK--------------------------------------------------------------------------------- CHANNEL STORAGE AND DELETE-------------------------------------------------- 30-32 SPECIFICATIONS-------------------------------------------------------------------------- 34-35 SAFETY PRECAUTIONS----------------------------------------------------------------- 36-37 WARRANTY--------------------------------------------------------------------------------------...
-
Page 5: What's In The Box
WHAT’S IN THE BOX... - Page 6 Charging Precaution The supplied battery pack of this radio is a high-performance Li-ion with 7.4V standard voltage 1400mAh high capacity in a very compact package. Under normal use, the battery pack has an expected life span of 500 charge cycles. If you have a battery pack that has diminished capacity, replace the battery and dispose of the old one properly.
- Page 7 Charging Operation : Align the two grooves of the battery to the guide rail on the back of the aluminum shell, then push the battery up until the battery latch locks. (Figure1) The light on the charger will indicate the charging status. To remove the battery, make sure the radio is off, then push the battery latch down and slide the battery out from the radio.
- Page 8 Align the two holes in the belt clip with the two holes in the radio and attach 1) Align the threaded end of the antenna and the threaded hole at the top of the using the supplied M2.5x5 screws. (Figure 5) radio, then rotate the antenna clockwise until it is secured.
-
Page 9: The Basics
THE BASICS If you are new to two-way radio, there are some basic concepts that you should be familiar with before using this device. By becoming familiar with these general ideas, you can avoid the improper operation of the device which can be harmful, injurious to health, or possibly illegal. -
Page 10: Repeaters
THE BASICS The difference between an INPUT and and OUTPUT frequency is sometimes called a ‘split’, but more accurately referred to as the repeater’s OFFSET, which is specified as some Radios still work in the forest, but not as well as when you’re on a hilltop. distance, plus or minus, from the repeaters OUTPUT frequency. -
Page 11: Transmit Frequency
This is the offset direction. frequencies, expressed in MHz, is called the offset. To select the offset direction in the Explorer QRZ-1, go to menu #3 (Repeater) by pressing followed by the number 3. Use to choose the offset direction for... -
Page 12: Ctcss
(Repeater Transmit) 447.725 MHz: Your Talk (Repeater Receive) To enter the repeater’s CTCSS information in the QRZ-1, go to menu #1 (Tone Mode) by pressing followed by the number 1 and selecting “TX” mode using , then press to save your change and press the PTT button to exit the menu. -
Page 13: Squelch
Carrier Squelch (Noise Squelch) : This is the most basic form of squelch and operates only on signal strength. In the Explorer QRZ-1, use menu #4 (Squelch) to adjust the received signal strength needed to unmute or break the squelch threshold on the receiver. - Page 14 Power/Volume Knob FLASHLIGHT This jack provides a connection for the Press and hold to optional speaker transmit and release microphone, earpiece to receive. microphone, and programming cable. Pressing this key disables the noise squelching Menu key Menu allowing you to hear very Tone Code Rptr...
- Page 15 You will see various icons shown on the screen when powered on. Battery fully charged Battery fully depleted...
-
Page 16: Working Mode
WORKING MODE Memory Mode (MR) If the operating band is currently in VFO mode, press the to enter MR mode. Radio Frequency Mode (VFO) The channel number will be indicated next to the frequency on the main screen. Use the Press the PTT button to return to the main screen. -
Page 17: Menu Structure
MENU STRUCTURE Select low (1W) medium (2W) or high (5W) TX power. Menu Items 1-10 can be accessed by using Power settings can be stored in each memory location. desired number keys. Displays battery voltage Menu Items 11-27 can be accessed by using Provides automatic transmit/receive switching based on voice input. -
Page 18: Offset
In VFO mode, this funtion sets the magnitude of the Press the "*Lock" button for 2 seconds to All/PTT/Key/Key+S Offset repeater shift lock/unlock the keypad. The options control the Lock Mode behavior of the "*Lock" button. See page 29 for Choose options for the welcome screen that is DC/Message/Off Welcome... -
Page 19: Keypad Lock
KEYPAD LOCK CHANNEL STORAGE AND DELETE Channel Storage Press the button for 2 seconds to lock and unlock the keypad. The lock icon will Under VFO mode, input the desired frequency by keypad directly or select one by pressing be displayed at the top of the LCD when the keypad is locked. and then long-press . - Page 20 Channel Delete Frequency selecting Under FM frequency mode, input the digits directly by keypad or press Under VFO mode, long-press until the digits blink on the right side arrows to choose the desired frequency. Under FM memory of the LCD. mode, press arrows to choose the desired channel.
-
Page 21: Specifications
SPECIFICATIONS General Channel Operating Voltage 7.4VDC Operating Temperature - 10° C ~ +50° C Weight 106g ( battery and antenna included ) Dimension 116x53x36mm SPECIFICATIONS SAFETY PRECAUTIONS Transmitter WARRANTY Frequency 144.000 - 148.000MHz 420.000 - 450.000MHz Power Modulation Type Spurious Power ≤... - Page 22 SPECIFICATIONS SAFETY PRECAUTIONS Receiver 136.000-174.000MHz Frequency WARNING 400.000-480.000MHz 65.000 - 108.000MHz - Do not remove or charge the battery where flammable conditions exist. Sensitivity ≤ 0.2 µV - Turn off the radio in hospitals and healthcare facilities. Occupied Bandwidth ≤ 16KHz - Disconnect any external antennas when near a thunderstorm.
- Page 23 SAFETY PRECAUTIONS ONE YEAR LIMITED WARRANTY This Limited Product Warranty is provided by the Dealer where the QRZ-1 was purchased. - Do not use the radio if any cables, power cords, or connectors are damaged or not fitting The Product Warranty extends only to the original purchaser of the product and is valid for securely.
