MFP44T
Tilt Movement
This TV Wall Mount allows you
to tilt your TV up and down
Compatible TV Size
17–55"
(43–139cm) TV screens
Maximum Mounting Pattern
This TV Wall Mount has a mounting
400x400
mm
hole pattern up to 400x400mm (WxH)
Maximum TV Weight
HOLDS
This TV Wall Mount supports TVs
50
kg
weighing up to 50kg
Hardware Kit Contents
M6 x 12mm Screws
M6 Nut
Tools Required
DRYWALL INSTALLATION (TIMBER SUPPORTS):
· Adjustable spanner/socket set
· Long handled philips screwdriver
· Power drill
· High speed 5mm drill bit
SAFETY FIRST
1. Inst allation of this TV Wall Moun t will be easier with two people.
2. Some images in this guide may vary slightly from the actual
components supplied.
3. Ensure this instruction manual is completely read and
understood before attempting installation.
4. This TV Wall Mount MUST NOT be installed solely in
5. This TV Wall Mount MUST be installed in sound supporting
structures such as those made of timber, steel or masonry
using appropriate fasteners.
6. The supporting structure must be capable of sustaining
the combined weight of the TV Wall Mount and the display
otherwise the structure must be reinforced.
7.
into timber and masonry only. If installing into a supporting
structure made of steel, appropriate fasteners must be used
and sourced from an appropriate supplier.
8. Use appropriate tools and safety equipment and ensure
adequate ventilation during installation.
9. If uncertain about any aspect of installation, contact
The Crest Company or an installation professional.
10.
Please retain these instr uctions for futu r e reference.
W-A
M6 x 60mm Lag Bolt
W-B
8 x 40mm Anchor
W-C
W-D
W-E
VESA Adaptor Arms
4
4
4
MASONRY INSTALLATION:
· Adjustable spanner/socket set
· Long handled philips screwdriver
· Power drill with hammer function
· 8mm Masonry drill bit
· Spirit level and pencil
· Hammer
2
2
6
4
Advertisement
Table of Contents
Related Manuals for Crest Audio MFP44T
Summary of Contents for Crest Audio MFP44T
- Page 1 SAFETY FIRST MFP44T 1. Inst allation of this TV Wall Moun t will be easier with two people. 2. Some images in this guide may vary slightly from the actual components supplied. 3. Ensure this instruction manual is completely read and Tilt Movement understood before attempting installation.
- Page 2 Step 1: Attach Lag Bolts to Wall A. INSTALLING IN DRYWALL (TIMBER SUPPORTS) WARNING: If attaching this TV Wall Mount using this method, you MUST position the wall plate over a wall stud. The Crest Company will not accept any damages that may occur and holds no responsibility for incorrectly installed TV Wall Mounts.
- Page 3 Step 2: Attach TV Wall Mount to TV (VESA Pattern 200x200 or less) 1. Using a second person for assistance, lay your TV face down on something soft so as not to scratch the TV screen. ng pattern. snugly (the bolt must turn at least 3 full turns, do not tighten). If you feel resistance stop immediately and select a smaller bolt.
- Page 4 Step 5: Tilt Adjustment 1. You may now adjust the angle of your TV for the best viewing angle. Gently push or pull your TV from the top or bottom of the TV screen. The tilt angle can be adjusted between 10˚ down and 10˚ up (see Figure 8). Check your TV Wall Mount is secure and safe to use at regular intervals (at least every three months).
