TouchTronics PowerTouch 814 Instruction Manual

Remote control receiver with two key chain transmitters and shown with optional oval transmitter
Hide thumbs Also See for PowerTouch 814:

Advertisement

Quick Links

PowerTouch 814
By T ouchT ronics, Inc.
Please r ead entire instruction manual prior to starting the
PowerT ouch Remote Control System Installation.
Special Featur es and Applications
Flexibility
Installer can select polarity of vol t age outputs on two dif ferent channels.
Compact
Receiver is small and easy to install.
Optional T ransmitters
Large, oval transmitters with lar g e buttons can be ordered.
Extra Channels
Two extra channels are available at no extra cost.
Range
Typical antenna range is 60-feet.
PowerTouch Remote Control Systems - 814 Series (2 - 4) Functions
57315 Nagy Dr
Elkhart, IN 46517
814 PowerTouch Remote Control Receiver
With Two Key Chain T ransmitters and
Shown With Optional Oval Transmitter
www.touchtronics.com
NST13308-P814_A
2020-06-10
Page 1
Optional
Oval
Transmitter
800-294-2570
574-294-2570
