BESPOKE POWER
BP-C9WY-6973-U Installation Guide
Congratulations on your purchase of your new state-of-the-art taillight sequencer.
sequencer is a universal fit for any vehicle with 2-3 taillights for each side of the vehicle.
What's in the Box:
1. 1 – BP-C9WY-6973-U with color coded connectors
2. Mating cables with flying leads
3. 6 - Wire splices
4. 3 – sheet metal screws

Tools Required

1. Small bladed screwdriver (for any adjustments)
2. Needle nose pliers
3. Regular pliers for wire splices
4. Wire cutters
5. Drill w/1/8" bit
Installation

Part 1 - Mounting the Unit

1. Find a suitable location for mounting the sequencer housing at the rear of the vehicle. The ideal
location will adequately support the housing and not be subject to water spray. Mounting is not
sensitive to orientation.
2. Identify and locate the existing wires that power the Stop/TL circuits. A wiring diagram and service
manual will be a great help for this.
3. Drill 2 mounting holes in the vehicle for the self-tapping screws that secure the flanges on the
sequencer housing. Install and tighten the screws being careful not to crack the plastic flanges.
4. Drill another hole for securing the ground connection to the chassis of the vehicle. Install the
screw through the ring terminal and tighten for a good ground connection. A poor ground
connection will affect sequencer operation.
5. The solid green wire is for connection to a separate brake signal if one is present. Vehicle not
originally designed for a sequencer does not usually have this connection. If unused, the green
wire may be grounded or left open.
5/3/22 Rev01 Visit our website for the latest documentation
https://bespokepower.com
This

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP-C9WY-6973-U and is the answer not in the manual?

Questions and answers

Summary of Contents for Bespoke BP-C9WY-6973-U

  • Page 1 2-3 taillights for each side of the vehicle. What’s in the Box: 1. 1 – BP-C9WY-6973-U with color coded connectors 2. Mating cables with flying leads 3. 6 - Wire splices 4.
  • Page 2 10. Your sequencer is now installed and ready to use or adjust as needed. Adjustments There are 2 adjustments (3 if the green brake signal is used) on the BP-C9WY-6973-U. The user may independently adjust the left and right sequence rate of the bulbs. Temporarily remove the housing cover to access the adjustments and/or view the diagnostic LEDs.
  • Page 3 BESPOKE POWER Sequence Rate Adjustment The sequence rate is set to 300ms at the factory but has an adjustment range of 150ms to 720ms. LED bulb and incandescent bulbs have different characteristics (see BPWP-001 for a detailed explanation) and will have different settings.
  • Page 4 BESPOKE POWER Left 1157 (Clear) Taillights Taillight Outer TS/Stop 1157 (Clear) Taillight TS/Stop 1157 (Clear) Left Stop/Turn Signal Taillight Inner TS/Stop 1157 (Clear) Right Stop/Turn Signal Taillight Inner TS/Stop 1157 (Clear) Taillight TS/Stop 1157 (Clear) Taillight Outer TS/Stop Right Figure 1. Typical Stock Vehicle Wiring 5/3/22 Rev01 Visit our website for the latest documentation https://bespokepower.com...
  • Page 5 BESPOKE POWER Figure 2. Sequencer Wiring 5/3/22 Rev01 Visit our website for the latest documentation https://bespokepower.com...
