Summary of Contents for Compulite Vector Black PC Wing
- Page 1 Vector Black PC Wing Getting Started Connecting Vector Black PC Wing Document Version 1.0...
- Page 2 No part of this product or document may be reproduced in any form by any means without the prior express written authorization of Compulite Systems (2000) Ltd. and its licensors (if any). Information contained herein is subject to change without...
- Page 3 Vector Black PC Wing. Introduction The Vector Black PC Wing can be used as an attachment to Vector PC or as a Remote Wing with a console. Vector Black PC Wing is not a standalone wing, panel or console, and can only be used as a parallel hardware attachment, as it draws its processing power from a Vector PC or Vector Console.
- Page 4 Getting Started Showing available console IPs When selecting a console, the IP is displayed by the LEDs on the buttons of the PBs. These LEDs display the third number of the IP (the Console ID) by using the three rows of the PB buttons. Each row is a digit of the third number of the IP.
- Page 5 Black PC Wing To Connect Vector 1. Make sure the Vector software is running. 2. Using the supplied power cable connect the Vector Black PC Wing to a 110-220V power output. Do NOT turn wing ON. 3. Using a RJ-45 network cable, connect one end to the Ethernet port on the...
- Page 6 Getting Started Black PC Wing Vector Operation The Vector Black PC Wing can only be used as a Parallel hardware attachment and not a standalone unit. Parallel Behavior The following applies to the Wing behavior in parallel mode: Changing the fader mode on the Vector console changes it on the Wing and vice-versa.
