- Page 1 INSTALLATION MANUAL Weiser Protect AKOTEC S O L A R T H E R M I E...
- Page 2 Technology and Nature in Harmony...
- Page 3 INSTALLATION MANUAL WEISER PROTECT Notes pages 4 - 5 Technical data pages 6 - 7 Installation pages 8 - 13 Interconn ec tion pages 14 - 15 Ch ecklist pages 16 - 18 page 3...
- Page 4 Please also refer to the planning and commissioning instructions and the data sheet. Both can be downloaded f rom our website. https: //www.akotec.eu/english/downloads/ Safety in general: Installation may only be carried out by qualif ied personnel in accordance with the applicable regulations and standards. Improper installation can lead to damage to the collectors and the entire system.
- Page 5 Warranty: The statutory warranty claims apply. Furthermore, you have the possibility to extend the warranty to 20 years. To do this, register your system at https://www.akotec.eu/english/infos/garantie/ Please also note the current warranty conditions at https://www.akotec.eu/english/downloads page 5...
-
Page 6: Occupational Health And Safety
Occupational health and safety: wear helmet, hearing protection and safety glasses create fall protection handle glass tubes with gloves only Tools: drilling machine measuring tape (folding rule) spirit level open-end wrench SW 13 socket wrench SW 13 hammer angle grinder Mounting types: pitched roof flat roof (with elevation) -
Page 7: Technical Data
Technical data Dimensions of the Weiser Protect collectors length width weight excl. weight incl. gross area collector (m²) (mm) (mm) reflector (kg) reflector (kg) with 10 hp 2159 27,9 33,6 1,61 tubes with 20 hp 2159 1495 51,8 64,0 3,23... - Page 8 collector foot part page 8...
-
Page 9: Installation
Installation For all mounting types Please also observe the corresponding mounting instructions of the mounting system. Mounting the collector fasten collector with washer / nut align and tighten the nuts please make sure that the housing does not lie completely on top, otherwise the housing cover cannot be removed Mounting the foot part fasten foot part with washer and nuts... - Page 10 Mounting the vacuum tubes put on gloves (cotton) spray the pipe penetration and the lower part of the tube with a washing-up liquid mixture mount tube into the foot part with a slight turning movement insert the vacuum tube into the receptacles provided in the collector while rotating it.
- Page 11 Mounting the foot section cover mount the cover of the foot part again put on the lid and turn it downwards until the lid audibly clicks into place Mounting the foot section side cover mount the left and right side covers to the base using the screws provided Mounting of the connection (rigid piping or corrugated hose)
- Page 12 Attention The f ixed point of the pipeline should be determined when using rigid piping so that suff icient expansion of the collector header pipe is possible. The rigid piping must NOT be shortened. The continuing connections must be supported after a length of max. 15 cm. Notes on the continuing pipeline Do not solder on the collector and the supplied terminals.
- Page 13 Line up collectors & Connecting the collectors f irst align a collector mount, then tighten fastening screws attach the following collector with the HP collector connector to the mounted collector couple with slight twisting movements and light pressure check the locking by pulling lightly it maybe necessary to couple the respective following collector turned 90°...
- Page 14 P = 2.5 bar. The inlet pressure of the MAG should be set 0.3 - 0.5 below the system pressure P in the depressurized state. This is only a rough guide. Please use the easy system planner for the design, which you can download at www.akotec.eu. page 14...
-
Page 15: Connection Options
Interconn ec tions Collector circuits hp collectors Note: Always install the sensor on the flow side! Connection options: One collector sensor sensor Multiple horizontal collectors in series (max. 90 tubes) sensor page 15... - Page 16 Multiple horizontal collectors in series and parallel (max. 90 tubes) sensor Multiple vertical collectors in series and parallel (max. 90 tubes) sensor sensor Hint: When connecting collector areas in parallel, ensure that the partial fields are of equal size (number of vacuum tubes) and that the connection is "clean" according to Tichelmann.
- Page 17 Ch ecklist Important points in the overview, which are to be considered absolutely 1. Insert the vacuum tube into the collector with a rotary motion S praying the tubes with a mixture of washing-up liquid and water makes tube assembly easier. C heck locking by pulling lightly.
- Page 18 Note for the Weiser Protect 800, 1600 and 2400 The Weiser Protect without reflector also has absorbing vacuum tubes on the back. The yield of the collectors can be increased by a reflective background on site, e.g. a light-colored wall or reflective roof ing.
- Page 19 THE SUPERPOWER OF NATURE...
- Page 20 AKOTEC S O L A R T H E R M I E AKOTEC Produktionsgesellschaft mbH I Grundmühlenweg 3 I D - 16278 Angermünde T: +49 (0) 3331 25 716 30 I F: +49 (0) 3331 25 599 96 I M: info@akotec .eu I W: akotec .eu Misprints and technical changes reserved.
