Mounting Instructions – Solrif
Ernst Schweizer AG
Bahnhofplatz 11
8908 Hedingen, Switzerland
®
Telephone +41 44 763 61 11
solar@ernstschweizer.ch
www.ernstschweizer.ch
Mounting Instructions – Solrif
®
Technical data subject to change
November 2022
© Ernst Schweizer AG
Page 1/15
Advertisement
Table of Contents
Related Manuals for Schweizer Solrif
Summary of Contents for Schweizer Solrif
- Page 1 Solar systems by Schweizer: Mounting Instructions – Solrif ® Mounting Instructions – Solrif ® Technical data subject to change November 2022 Ernst Schweizer AG Telephone +41 44 763 61 11 © Ernst Schweizer AG Bahnhofplatz 11 solar@ernstschweizer.ch Page 1/15 8908 Hedingen, Switzerland...
-
Page 2: Table Of Contents
Solar systems by Schweizer: Mounting Instructions – Solrif ® Contents Scope of application ��������������������������������������������������������������������������� Exclusion of liability ���������������������������������������������������������������������������� Explanation of symbols ���������������������������������������������������������������������� Requirements for the roof ����������������������������������������������������������������� Hazards due to electrical energy ������������������������������������������������������� Transport and packaging ������������������������������������������������������������������� Supplementary information���������������������������������������������������������������� Mounting inside corners ��������������������������������������������������������������������... -
Page 3: Scope Of Application
These are subject to the laws that were valid at the juncture when the contract was concluded� – Ernst Schweizer AG reserves the right to make technical changes to the system as part of further development to improve performance characteristics and safety�... -
Page 4: Explanation Of Symbols
Solar systems by Schweizer: Mounting Instructions – Solrif ® Explanation of symbols Warning of electric shock Note Follow SPT software report proMSP Use a harness Wear safety goggles Wear working gloves Wear safety shoes Wear a helmet Wear ear protection... -
Page 5: Hazards Due To Electrical Energy
Supplementary information You will find further information at www.solrif.com in the following documents: – Application range of Solrif with regard to watertightness and minimum requirements for the roof underlay – Lightning protection concept – Information sheet for lightning and overvoltage protection with Solrif ®... -
Page 6: Preparation
Solar systems by Schweizer: Mounting Instructions – Solrif ® Preparation Before installation, the following documents must be checked for completeness and taken into account: – Solar�Pro�Tool documentation (SPT), incl� parts list and CAD plan – Electrical planning (cable routing plan) –... -
Page 7: Overview
Solar systems by Schweizer: Mounting Instructions – Solrif ® Overview Solrif batten Eaves profile Flashing profile right Top flashing ® ① ⑤ ⑨ ⑬ Wedge plank Mounting clamp profile Flashing profile left Top flashing joiner ② ⑥ ⑩ ⑭ Supporting batten... -
Page 8: Horizontal And Vertical Section
Illustration: horizontal section Solrif ® Valley sealing strip (06736) Vertical section (if working without an eaves profile). Reference line horizontal: * The height of the Solrif battens must ® Front edge batten be adapted to the tile battens. Roof slope... -
Page 9: Mounting The Solrif
Solar systems by Schweizer: Mounting Instructions – Solrif ® Mounting the Solrif field ® ANSICHT54 (1 : 100) ANSICHT82 (1 : 100) proMSP proMSP Remove tiles and, if necessary, also the tile Assemble Solrif battens, wedge plank and ® battens in the area of the module surface on a supporting batten in accordance with instructions�... - Page 10 Solar systems by Schweizer: Mounting Instructions – Solrif ® ANSICHT122 ( 1 : 10 ) ANSICHT90 (1 : 20) Szene 2, Ansicht 100 Szene 2, Ansicht 88 ANSICHT91 (1 : 2) Szene 2, Ansicht 89 Overview of eaves profile installation.
- Page 11 Solar systems by Schweizer: Mounting Instructions – Solrif ® ANSICHT95 (1 : 5) ANSICHT50 (1 : 10) Szene 2, Ansicht 95 proMSP ANSICHT40 (1 : 2) ANSICHT99 (1 : 2) ANSICHT41 (1 : 3) Szene 2, Ansicht 25 Szene 2, Ansic h t 26 Szene 2, Ansicht 99 Place and screw the last profile fixing.
- Page 12 Solar systems by Schweizer: Mounting Instructions – Solrif ® ANSICHT58 (1 : 50) ANSICHT59 (1 : 20) ANSICHT68 (1 : 2) ANSICHT67 (1 : 2) Close off at the left edge with side flashing and Lay further modules and connect electrically�...
- Page 13 Solar systems by Schweizer: Mounting Instructions – Solrif ® ANSICHT69 (1 : 30) ANSICHT45 (1 : 20) ANSICHT47 (1 : 10) proMSP Insert top flashing. Lay top profile bracket row (‘top row’ position). ANSICHT87 (1 : 10) ANSICHT70 (1 : 10)
- Page 14 Solar systems by Schweizer: Mounting Instructions – Solrif ® ANSICHT72 (1 : 2) ANSICHT71 (1 : 10) Push in the corner plate on the left and fix it Attach sheet metal clamps and fix them with a wide-headed pin� with a wide-headed pin�...
-
Page 15: Maintenance And Cleaning
Solar systems by Schweizer: Mounting Instructions – Solrif ® Maintenance and cleaning Unless otherwise specified by the module manufacturer, it is recommended to check the PV array for damage annually and after severe weather events such as storms or hailstorms� In case of heavy soiling, it is recommended to clean the modules and module drainage channels�...
