VOKKERO GUARDIAN STAFF
FCC
VOKKERO
VOKKERO
VOGO NA (North America)
25 Main Street, 3rd Floor
Tuckahoe, NY 10707
www.vokkerousa.com
VOGO
101, place Pierre Duhem,
Immeuble Les Centuries II,
34000 Montpellier, France
www.vokkero.com
User Guide Version 1.0
211952

Advertisement

Table of Contents
loading

Related Manuals for Vokkero GUARDIAN STAFF FCC

Summary of Contents for Vokkero GUARDIAN STAFF FCC

  • Page 1 VOKKERO GUARDIAN STAFF User Guide Version 1.0 211952 VOKKERO VOKKERO VOGO NA (North America) VOGO 25 Main Street, 3rd Floor 101, place Pierre Duhem, Tuckahoe, NY 10707 Immeuble Les Centuries II, 34000 Montpellier, France www.vokkerousa.com www.vokkero.com...
  • Page 2 QUICK START GUIDE START SETTING UP THE VOKKERO GUARDIAN STAFF SYSTEM WITH THE CONFIGURATOR GUARDIAn C2C GUARDIAn lACe the teRmInAls onneCt the on the ConfIGURAtoR e sURe thAt All ConfIGURAtoR to A poweR soURCe teRmInAls ARe pRopeRly seAteD In the...
  • Page 3 QUICK START GUIDE DISCOVER THE GAME TIME USE OF THE VOKKERO GUARDIAN STAFF SYSTEM THROUGH THE TERMINALS emove the teRmInAls fRom the ConfIGURAtoR poweR yoUR teRmInAl AnD ConneCt the heADset to It To disconnect the headset, grasp the Line up the 2 red marks of the secure connector ring.

  • Page 4: Préambule / Preamble

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 PRÉAMBULE / PREAMBLE • Ce guide décrit les fonctionnalités des produits VOKKERO GUARDIAN STAFF FCC, ses options et ses accessoires. • This guide describes the functionality of the VOKKERO GUARDIAN STAFF FCC products, options and accessories.

  • Page 5: Table Of Contents

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 PRÉAMBULE / PREAMBLE INFORMATIONS DISCLAIMER TECHNICAL SUPPORT COMPLIANCE TO FCC US/CAN ENVIRONMENTAL RECOMMENDATIONS WARNINGS DISPOSAL OF WASTE BY USERS IN PRIVATE HOUSEHOLDS INTRODUCTION SYSTEM INSTALLATION PROCEDURE STARTING UP THE TERMINAL 2.1. Screen Icons (by Default) 2.2.

  • Page 6: Informations

    Under no circumstances can the manufacturer, or the distributor of an VOKKERO program, be held liable for any damage caused by the use of the afore- said program. Program names, as well as all copyright relating to programs, are the exclusive property of VOKKERO. Any transfer, granting of licences to a third party, leasing, hire, transport, copying, editing, translation, modification into another programming language or reverse engineering are prohibited without VOKKERO’s prior written authorisation and consent.

  • Page 7: Compliance To Fcc Us/Can

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 COMPLIANCE TO FCC US/CAN This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1). this device may not cause Harmful interference, and (2).
  • Page 8 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 FOR PORTABLE DEVICE USAGE (<20cm from body/SAR needed) Radiation Exposure Statement: This device complies with the FCC and ISED portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual.
  • Page 9 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 OPERATING FREQUENCIES of VOKKERO GUARDIAN STAFF FCC FHSS Mode: 2 Hopping DTS mode: Each device also features 2 channels using digital modulation tables are available techniques (DTS mode). Available Frequency Hopping tables channels are listed below.

  • Page 10: Environmental Recommendations

    WARNINGS Valid for : VOKKERO GUARDIAN - Terminals: VO8320A - VO8320B - VO8320C - VO8320D - VO8320E - VO8320F - VO83020G - VO8320H - VO83020I - VO8320J VOKKERO GUARDIAN - Configurator : VO8118AA VOKKERO GUARDIAN - Charger : VO8139AA Read the instructions in the manual.

  • Page 11: Disposal Of Waste By Users In Private Households

    To fulfill RF exposure limit, the device VO8320A - VO8320B - VO8320C - VO8320D - VO8320E - VO8320F - VO83020G - VO8320H - VO83020I or VO8320J must be attached to belt with the belt-clip provided by Vokkero. DISPOSAL OF WASTE BY USERS IN PRIVATE HOUSEHOLDS This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.

  • Page 12: Introduction

    (Optional) Charger extension (1 to 4 maximum) All the operating settings of the VOKKERO Guardian system are managed by the configurator which gives access to the Settings menu via a touchscreen. The configurator must be connected to the power unit (otherwise it will not work) and up to 4 extensions can be associated with the configurator.
  • Page 13 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 1.1. General Technical Specifications 1.2. Antenna Headset connector Flexible radio antenna. Connect to a headset (must be compatible with the terminal). Device on and Network «Volume» selector connection. Trigger Button to adjust the vo- lume of the headset loudspeaker.
  • Page 14 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 Battery Charging without the terminal Screen Configurator display screen. Terminal charge Extension connection : no terminal or defective terminal Up to 4 extensions can be connected Orange : terminal charging Vert : terminal charged...

  • Page 15: Starting Up The Terminal

    Off. 2.2. Setting up Audio Conference You can set up a VOKKERO audio conference. The first step consists in attributing the Master role (M1) to a single terminal. This role is used to synchronize the other terminals. The Master role (M1) is automatically attributed to the terminal located in the first slot of the configurator during a quick configuration (see §4.2).

  • Page 16: Connecting A Headset

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2.3. Connecting a headset Several types of headsets from the VOKKERO range can be connected to VOKKERO Guardian. The headset is automati-cally detected by the terminal when the headset is plugged in.

  • Page 17: Terminal Operation

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2.4. Terminal operation 2.4.1. Volume Adjust the terminal volume with the Volume trigger button. • Push the trigger upwards to increase the volume • Push the trigger downwards to decrease the volume When you increase or decrease the volume, you will hear a beep.

  • Page 18: Micro" Button (Latch Mode By Default)

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2.4.4. “Micro” button (Latch mode by default) Adjust the Microphone setting using the Micro button. The microphone can be configured in various modes using the configurator; for full information on available modes, refer to §4.3.1.

  • Page 19: Side Tone

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2.4.7. Side Tone By default, the side tone is disabled. To activate the side tone, press and hold the centre of the volume knob. The product then displays the side tone menu. To choose among the following options toggle the trigger: •...

  • Page 20: Settings

    The configurator can also be used to download products. Immediately upon starting up the system, the configurator displays the VOKKERO logo, with the firmware version of the configu- rator, followed by the Home Screen.

  • Page 21: Settings

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 Start the configuration by selecting “GO” on the screen, and then validating the confirmation screen; the configuration starts. If the configuration completes successfully, the indication “DONE” displays. Alternatively, the indication “ERROR” displays if a problem is encountered.

  • Page 22: Configuring The Terminal

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 3.3.1. Configuring the terminal This screen indicates the terminals present on the configurator. The charge status as well as the name of each terminal displays. The terminals display in their order of presence on the configurator, going from the closest (position 1) to the furthest away.
  • Page 23 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2 - Microphone action The central button can have a number of operating modes: - Latch: press to switch the microphone from Microphone On to Microphone Off; the microphone status displays on the terminal LCD - Push to talk: the microphone is On for as long as the button is pushed and held.
  • Page 24 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 5- Advanced settings Provides access to the following options: - Assign buttons: to change the functions of the buttons on the terminal - Alarm button: to change the press mode of the alarm button - Expert mode: Users cannot access this mode as it has settings that can disrupt the smooth-run- ning of your VOKKERO®...
  • Page 25 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 6 - Version Shows you the factory version of the terminal used. 7 - Factory settings This menu returns, to the factory setting, a product or all products connected to the configurator.

  • Page 26: System Configuration

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 3.3.2. System configuration In this screen you can see all the settings related to the system configuration. The set- tings in this menu apply to all the terminals present on the configurator.
  • Page 27 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 2 - Encryption The encryption key is used to make communications within a given system secure. Only the devices using the same encryption key are authorized to communicate on the network. Several options are available: •...
  • Page 28 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 4.1 - Updating terminals To update terminals you have to use a USB key. Contact your vendor to obtain the most recent software version. The USB key used must be < or = 4Go.
  • Page 29 VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 4.2 - Updating the configurator To update the configurator you have to use a USB key. Contact your vendor to obtain the most recent software version. The USB key used must be < or = 4Go.

  • Page 30: Configuring The Configurator

    VOKKERO GUARDIAN STAFF FCC - User Guide V1.0 3.3.3. Configuring the configurator Use this setting to adjust the screen. In this area, you can adjust the screen lighting, calibrate the touchscreen, and lock the configurator. 1 - Adjusting the screen lighting Slide the cursor from left and right to decrease and increase, respectively, screen lighting.

  • Page 31: Resetting The Configurator Functions

    In order to put the configurator back in factory mode (and thus cancel all the configuration changes made previously), do the following: Unplug the configurator Reconnect the configurator When the configurator is switched on, on the first home screen, consisting of the «VOKKERO®» logo: press the 2nd «O” of VOKKERO®. Then you can restore the default settings of the configurato Confirm The configurator parameters have been reset.
