NETGEAR ProSafe FWAG114 Installation Manual

ProSafe Dual Band Wireless VPN Firewall FWAG114

Installation Guide

Follow these quick steps to install your firewall.
Before you begin, locate the broadband Internet configuration settings from
your Internet Service Provider. You can also consult the Install Assistant on
the ProSafe Dual Band Wireless VPN Firewall CD.
1 Connect the Firewall
1
a. Turn off your computer and broadband modem.
b. Disconnect the Ethernet cable from your computer (A) which
connects to your broadband modem.
A
Broadband modem
c. Connect the Ethernet cable from your broadband modem to the
Internet port (A) on the FWAG114.
A
Internet 4 3 2 1
12VDC, 1.0A
Reset
Model FWAG114 Wireless
ProSafe VPN Firewall
Broadband modem
d. Connect the Ethernet cable which came with the router from a
Local port on the router (B) to your computer.
A B
Internet 4 3 2 1
12VDC, 1.0A
Reset
Model FWAG114 Wireless
ProSafe VPN Firewall
Broadband modem
e. Turn on the broadband modem and wait about 30 seconds.
f. After the lights on the modem stop blinking, turn on
the FWAG114.
g. Now, turn on your computer.
h. Verify the following:
• When your turn the firewall on, the power light goes on.
• The test light turns on within a few seconds, and then goes
off after approximately 10 seconds.
• The local lights are lit for any connected computers.
• The Internet light is lit, indicating a link has been
established to the broadband modem.
Note: For wireless placement and range guidelines, and wireless
configuration instructions, please see the Reference Manual on
the ProSafe Dual Band Wireless VPN Firewall CD.
2 Log in to the Firewall
2
Note: To connect to the firewall, your computer needs to be configured
to obtain an IP address automatically via DHCP. For instructions on
how to do this, please see Appendix C in the Reference Manual on the
ProSafe Dual Band Wireless VPN Firewall CD.
a. Connect to the firewall by typing http://192.168.0.1 in the
address field of Internet Explorer or Netscape
b. For security reasons, the firewall has its own user name and
password. When prompted, enter admin for the firewall user
name and password for the firewall password, both in lower
case letters.
Note: The user name and password are not the same as any user
name or password you may use to log in to the Internet.
® Navigator.
