Please have your unit’s model number and serial number ready when you call. See previous section to locate this information. You may be asked to enter the serial number in order to process your call. For more details about your unit, visit our website at www.FunRunner.com...
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate or service this vehicle. When you see this symbol - heed its warning.
Page 4
speed limited when going down slopes to take Remove key when vehicle is unattended to advantage of the motor braking action. prevent unauthorized operation. 4. Keep all movement on the slopes slow and gradual. 2. Never allow children under 14 years old to operate Avoid starting or stopping on a slope.
SECTION 2: KNOW YOUR UTILITY VEHICLE NOTE: Reference to right or left hand side of the utility vehicle is observed from the operating position. Ignition Switch 12V Power Outlet Figure 1 Read this operator’s manual, safety labels, and accessories that require a power source with a operating instructions on the vehicle before operating.
Page 6
Brake and Parking Brake Pedal R (Reverse), ON, H (High Speed), L (Low Speed), Charging, Parking Brake, and Lights. See Figure 4. The brake and parking brake pedal is located on the left Speedometer Temperature side of the floor beneath the dash panel. The pedal is Battery Gauge divided into two sections.
Page 7
• Slide the lever to the left and push the seat forward Hazards Headlights/Taillights Horn or back to the desired position. • Release the lever so that it locks the seat in place. WARNING: Make sure seat is in locked position prior to operation and do not try to adjust the seat position while operating the vehicle.
SECTION 3: OPERATING YOUR UTILITY VEHICLE Starting Utility Vehicle • Just releasing accelerator pedal will also slow and gradually stop the vehicle. • Inspect area around vehicle for any items which • After stopping the vehicle, firmly depress parking may be in your path. brake pedal, top left of brake pedal, until it locks.
NOTE: The vehicle cannot be driven when the NOTE: The vehicle batteries cannot be overcharged or extension cord is connected to the charging port. overheated due to prolong charging. It is recommended the vehicle be left in a charge mode to maintain a full •...
NOTE: Do not jack up vehicle on body parts, but use the off position and the key removed from the strong sturdy points; such as the front arm assembly or ignition. rear trailing arm frame assembly. WARNING: Do not tow the vehicle on •...
SECTION 7: TROUBLESHOOTING If you are NOT experiencing one of the below problems and an electrical system error is occurring with the “fault light” flashing or an “audible signal” being heard, perform these corrective actions. 1. Turn ignition key to OFF position or “power down” vehicle and repeat starting procedures. 2.
Page 15
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 731-2343 Steering Wheel Cap 712-3076 Lug Nut 710-0643 Hex Cap Screw 5/16-18 x 1.0 738-0998 Shoulder Screw 3/8-24 x .625 736-0159 Bell Washer 750-1268 Shoulder Spacer .26 ID x .875 OD 731-2342 Steering Wheel 712-0262...
Page 16
Model Series 100 & 101 For Reference Only For Reference Only...
Page 17
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 748-0176 Flange Bearing .63 ID x .62 Lg 712-3027 Hex Flange Nut 1/4-20 649-0125 Steering Column Assembly 735-0686 Rubber Bumper 710-1815 Cap Screw 1/4-20 x .750 710-0641 Hex Cap Screw 1/4-20 x 2.25 649-0129 Seat Plate Mounting Assembly 649-0043...
Page 19
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 634-0207 Rear Wheel Assembly 724-0255 48V Electric Motor 712-0291 Hex Nut 1/4-20 618-0588 Motor Speed Sensor Assembly 736-0270 Flat Washer .265 ID x .750 OD 724-0257 RPM Sensor 710-3296 Hex Cap Screw 1/4-20 x .750 718-0789 Motor Spacer...
Page 20
Model Series 100 & 101 To Controller To Battery...
Page 21
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 710-0627 Hex Cap Screw 5/16-24 x .750 629-1074 Battery Harness Assembly 736-0264 Washer .330 ID x .630 OD 629-1076 Battery Harness Assembly 712-0291 Hex Lock Nut 1/4-20 725-1981 Fuse 710-3013 Hex Cap Screw 1/4-20 x .50 726-0469...
Page 25
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 625-0058 Headlight lamp Assembly - LH 735-0682 Floor Mat 710-1815 Cap Screw 1/4-20 x .750 731-2331 Front Bumper Panel 736-0742 Shoulder Spacer .265 ID x 712-3006 Hex Nut 1/4-20 725-1764 Instruction Panel 707-0160...
Page 27
Model Series 100 & 101 REF. PART REF. PART DESCRIPTION DESCRIPTION 731-2334 Trunk Lid - Silver 736-0176 Flat Washer .265 ID x .938 OD 731-2346 Trunk Lid - Green 750-1267 Shoulder Spacer .380 ID x .620 OD 720-0324 Trunk Key Lock 710-0597 Cap Screw 1/4-20 x 1.0 741-0750...
Page 28
Model Series 100 & 101 REF. PART DESCRIPTION 757-0387 Seat Assembly 750-1291 Spacer .385 x .600 x .570 710-0946 Machine Screw 1/4-20 x .625 707-0181A Seat Plate 712-3004A Flange Lock Nut 5/16-18 757-0389 Seat Track Assembly 757-0386 Arm Rest Set (If Equipped)
Page 29
Model Series 100 & 101 629-0948 - Main Wire Harness Assembly Horn Switch Dash Panel Lights Switch Hazard Switch 12V Power Outlet Directional Switch Key Switch Left Headlight Assembly Right Headlight Assembly Throttle/Accelerator Assembly Horn Brake Charger Speed Sensor Left Taillight Assembly Controller Connector Right Taillight...
Page 30
Para ubicar esta información, vea la sección previa. Se le puede pedir que ingrese su número de serie a fin de procesar su llamado. Para obtener más detalles sobre su unidad, visite nuestro sitio Web en www.FunRunner.com...
SECCION 1: PRACTICAS IMPORTANTES DE OPERACION SEGURA ADVERTENCIA: Este símbolo señala instrucciones de seguridad importantes que, de no seguirse, pueden poner en peligro la seguridad personal y/o la propiedad, suyas y de terceros. Antes de intentar operar o prestar servicio técnico a este vehículo, lea y siga todas las instrucciones de este manual. Cuando vea este símbolo - preste atención a su advertencia.
Page 32
detenerse en una pendiente. No permita nunca que niños menores de 14 años Sea extremadamente cauto al transportar carga. operen este vehículo. Los niños de 14 años y mayores Puede afectar la estabilidad de la máquina. deben leer y comprender las instrucciones de operación No haga lo siguiente: y las reglas de seguridad de este manual y deben ser capacitados y supervisados por uno de los padres.
SECCION 2: CONOZCA SU VEHICULO UTILITARIO NOTA: La referencia a los lados derecho o izquierdo de su vehículo utilitario se observa desde la posición del conductor Tomacorriente de Conmutador alimentación de 12V de encendido Figura 1 Antes de operar su vehículo utilitario, lea este Manual del comodidad de poder enchufar accesorios que necesiten una Operador y las guías.
Page 34
Pedal de freno y de freno de estacionamiento (la Baja velocidad), el Cobrar, el Aparcamiento del Freno, y Luces. Vea la Figura 4. • El pedal de freno y de freno de estacionamiento está Velocímetro ubicado en el lado izquierdo del piso, debajo del panel de Termómetro Carga de instrumentos.
Page 35
• Deslice la palanca a la izquierda y empuje el asiento Interruptor de luces Advertencia Bocina hacia adelante o hacia atrás, hasta la posición deseada. frontales y traseras • Libere la palanca para que trabe al asiento en su lugar. ADVERTENCIA: Asegúrese de que el asiento esté...
Page 36
SECCION 3: OPERACION DE SU VEHICULO UTILITARIO Puesta en marcha del vehículo utilitario Detención del vehículo utilitario • Inspeccione la zona alrededor del vehículo para • Para detener el vehículo, suelte el pedal del acelerador y verificar que no haya ningún elemento en su deprima el pedal de freno hasta que el vehículo llegue a la detención completa.
• NOTA: Un vehículo totalmente cargado puede funcionar hasta Las baterías del vehículo no pueden ser cobradas 30 millas (48 km) antes de necesitar su recarga, pero no excesivamente o las baterías no pueden sobrecalentar es necesario dejar que la batería se descargue debido prolongar la carga.
• Proximité la roue dingue et vieille se traînant. Placez la debe estar en la posición de reposo y el clave quitados nouvelle roue sur les goujons d'axe et sûr avec traînent des de la ignición. noix. ADVERTENCIA: No remolque el vehículo por •...
SECCION 6: ESPECIFICACIONES Dimensiones y peso de la Velocidad y rendimiento carrocería Velocidad máxima de avance 12 mph (19,3 km/h) Largo total 79 pulg. (201 cm) Max Forward Va Bas à toute vit- 8 m.p.h. (13 km/h) Ancho total 31,5 pulg. (80 cm) esse Distancia entre ejes 48 pulg.
El vehículo no se moverá y la El arranque con el cargador se Cargador de inenchufe para manejar luz de precio(carga) es enchufó. FunRunner. iluminada. El cargador se enchufó después del arranque. "El cobrar" de la luz destella. El cargador se enchufó después...
Page 43
TECNICO AUTORIZADO LOCAL. Para ubicar al concesionario producto anulará esta garantía. Usted asume el riesgo y de su zona, verifique nuestro sitio Web en www.funrunner.com o responsabilidad por las pérdidas, daños o lesiones a usted, su tome contacto con el Departamento de Servicio al Cliente de propiedad y/o a terceros y sus propiedades, que surjan del uso, FunRunner, llamando sin cargo al teléfono 1-866-FUN-RUNR (1-...
Page 44
Service Department by calling Toll Free 1-866-FUN-RUNR inability to use the product. (1-866-386-7867) or writing to MTD/FunRunner P.O. Box 360920, Cleveland, Ohio 44136-9722. This limited warranty shall not extend to anyone other than...
