CARQUEST 3203 Operating Manual

3203_3206_3210man071603 7/16/03

OWNER/USER RESPONSIBILITY

The owner and/or user must have a thorough understanding of
the manufacturer's operating instructions and warnings before
using this jack stand. Personnel involved in the use and operation
of equipment shall be careful, competent, trained, and qualified
in the safe operation of the equipment and its proper use when
servicing motor vehicles and their components. Warning
information should be emphasized and understood.
If the operator is not fluent in English, the manufacturer's
instructions and warnings shall be read to and discussed
with the operator in the operator's native language by the
purchaser/owner, making sure that the operator comprehends
its contents.
Owner and/or user must study and maintain for future
reference the manufacturer's instructions. Owner and/or user is
responsible for keeping all warning labels and instruction
manuals legible and intact. Replacement labels and literature
are available from the manufacturer.

INSPECTION

Visual inspection should be made before each use of the jack
stand. Any stand which appears to be damaged in any way,
found to be worn, or operates abnormally MUST BE REMOVED
FROM SERVICE. If the stand is subjected to an abnormal load or
shock it must be inspected by a manufacturer's authorized
repair facility immediately. It is recommended that an annual
inspection of the stand be made by a manufacturer's authorized
repair facility and missing decal or warning labels be replaced
with manufacturer's specified parts.
A list of authorized repair facilities is available from the
manufacturer.

MAINTENANCE

Oil all release handle moving parts and be sure they continue to
work properly.

ASSEMBLY

Remove both stands and ratcheting posts from box. Insert posts
into stands. Bend in tab on side of collar using a punch and
hammer. Some models may have a screw instead of a tab.
Tighten the screw while still allowing the post to move freely.
Lift release lever and lift ratcheting bar to desired height.
Check to make sure the dog engages each tooth properly on the
ratcheting post.
DO NOT OVERLOAD STAND. OVERLOADING CAN CAUSE DAMAGE TO, OR FAILURE OF,
THE STAND.
PLACE LOAD IN THE CENTER OF THE SADDLE ONLY.
USE STANDS IN PAIRS, ON HARD, LEVEL SURFACES CAPABLE OF SUSTAINING THE LOAD.
LOAD AND STANDS SHALL BE STABLE. USE ON OTHER THAN HARD, LEVEL SURFACES MAY
RESULT IN POSSIBLE LOSS OF LOAD.
INSPECT EACH STAND TO BE SURE IT IS IN GOOD CONDITION BEFORE USE.
NO ALTERATIONS TO THE STAND SHALL BE MADE.
3203/3206/3210 — OPERATING MANUAL AND PARTS LIST
3:12 PM Page 1
3203 / 3206 / 3210
3, 6, and 10 Ton Capacity Jack Stands
THIS OPERATING MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
READ CAREFULLY AND UNDERSTAND ALL INFORMATION BEFORE
OPERATING TOOL. SAVE THIS MANUAL FOR FUTURE USE.

OPERATING INSTRUCTIONS

Begin by setting parking brake on vehicle and blocking all
wheels. Make sure vehicle is raised to desired height and is
stable. Extend the post to height close to the support member.
Check the load locking and release handle to insure that the dog
portion has engaged a tooth on the post. Make sure both jack
stands are at an equal height and will support the load equally
when the lifting device is removed. Place jack stands carefully
under support points specified by vehicle manufacturer. Do not
crawl under vehicle when placing or removing stands! SLOWLY
lower the load onto the jack stands and check to insure the load
is located on the center portion of the post saddle. Check the
load for stability. If the load is NOT located on the center of
the post saddle, or if the load is not stable, re-lift the load and
reposition the jack stands to insure proper loading before
continuing with work or repairs. When removing stands,
carefully raise vehicle enough to clear the stands, making sure
the vehicle remains stable. Remove stands, being careful not to
crawl under vehicle while doing so. Carefully lower vehicle
to floor.
Specifications
3203
Capacity . . . . . . . . . . . 3 ton . . . . . . . . . . . . . . 6 ton . . . . . . . . . . . . 10 ton
Low Height . . . . . . . . 11-3/4" . . . . . . . . . . . . . 15-3/4" . . . . . . . . . . . 19-1/2"
High Height . . . . . . . . 18-1/2" . . . . . . . . . . . . . 25-1/4" . . . . . . . . . . 30-13/16"
Base Length . . . . . . . . 9-1/4" . . . . . . . . . . . . . 12-7/8" . . . . . . . . . . . 14-1/2"
Base Width . . . . . . . . 7-1/4" . . . . . . . . . . . . . 10-1/2" . . . . . . . . . . 12-13/16"
USE SUPPORT POINTS SPECIFIED BY VEHICLE MANUFACTURER.
DO NOT CRAWL UNDER VEHICLE WHEN PLACING/REMOVING STANDS.
ENSURE BOTH STANDS ARE SET AT SAME HEIGHT AND HOLDING DOGS ARE
FULLY ENGAGED.
READ, STUDY & UNDERSTAND THE OPERATING MANUAL PACKED WITH THIS STAND
BEFORE USING STAND. FAILURE TO HEED THESE WARNINGS MAY RESULT IN LOSS OF
LOAD, DAMAGE TO STAND, AND/OR FAILURE RESULTING IN PROPERTY DAMAGE,
PERSONAL OR FATAL INJURY.
1
3206 3210
rev. 07/16/03
